2.4.5 Peripherals Connections to the 4-Port PoweredUSB Hub

This figure illustrates the cable routing from the 4-Port PoweredUSB Hub to the Dell Retail
Integrator.
CyberData 4-Port PoweredUSB Hub
Operations Guide
Figure 2-9. Top view of Hub PoweredUSB cable routing
930103D
Installing and Using the 4-Port PoweredUSB Hub
+24V PoweredUSB Connector
+12V PoweredUSB Connectors
