CyberData KS-1000 Specification Sheet

KS1000 Retail Hub
The CyberData KS1000 Retail Hub provides a simple and
affordable POS migration strategy for Retailers. Availability
of 8 powered serial ports allows for the legacy connectivity
of existing peripherals while the availability of 8
PoweredUSB ports allows for future peripheral connectivity.
Requiring only a single, standard USB connection to the
host PC, CyberData's KS1000 Retail Hub is the centerpiece
of a POS migration strategy. This hub-based solution allows
Retailers the ability to upgrade the host PC or peripherals
as time and budgets permit or as new technologies become
available.
The KS1000 Retail Hub also provides these additional
Retail connectivity ports:
PS2 port for keyboard or magnetic stripe reader
Cash Drawer port with +24V power, trigger and status
24V, 3A receipt printer power connector
RS232 with +5V and +12V support
Features
8 PoweredUSB ports
8 powered serial ports
PS/2 port for keyboard and/or magnetic stripe reader
Cash Drawer port with +24V power, trigger and status
Internal power supply
Optional internal USB drive
External LED's to show port power and status
Over current protection
2 AC pass through connections
CyberData Corporation
CyberData Corporation 2555 Garden Road
(831) 373-2601 (831) 373-4193 www.cyberdata.net
CyberData Corporation
KS1000 Retail Hub Specifications
Part Number
PoweredUSB Power Output*
(Standard)
PoweredUSB Ports
RS232 Ports
External LEDs
Power Input
Regulatory Compliance
Dimensions
Warranty
*All ports support standard "A" type +5V USB connection.
Compatibility
IBM PC Windows 2000/XP & WePOS compatible
Apple Computer & Linux also supported
USB Standard 2.0 is fully supported
Monterey, California 93940
010896
1 @ 24V 2.3A
7 @ 12V 1.5A each
8
8 DB9M with power option
Power, link & status
90 - 264AC, 50/60Hz
FCC Class B, UL 60950-1, CE
8.9 x 5.7 x 3.5" (W x D x H)
3 year limited
070109
