Chapter 1 Installing and using the Hub

Connections

Peripherals connections to the CyberData 4-Port PoweredUSB 2.0 Hub

This figure illustrates the cable routing from the CyberData 4-Port PoweredUSB 2.0 Hub to the Dell

Retail Integrator.

Figure 9: Dell Retail Integrator showing Hub PoweredUSB Cable Routing—top view

CyberData 4-Port PoweredUSB Hub

CyberData Corporation Rev C 2/06

010776A

4-Port PoweredUSB 2.0 Hub with Dell Retail Integrator Kit

+24V PoweredUSB Connector

+12V PoweredUSB Connectors
