G7L
Characteristics
Contact resistance
Operate time
Release time
Max. operating frequency
Insulation resistance
Dielectric strength
Impulse withstand voltage
Vibration resistance
Shock resistance
Life expectancy
Ambient temperature
Ambient humidity
Weight
Note: The values given above are initial values.
4
50 m" max.
30 ms max.
30 ms max.
Mechanical: 1,800 operations/hr
Electrical: 1,800 operations/hr (under rated load)
1,000 M" min. (at 500 VDC)
4,000 VAC min., 50/60 Hz for 1 min between coil and contacts
2,000 VAC, 50/60 Hz for 1 min between contacts of same polarity
2,000 VAC, 50/60 Hz for 1 min between contacts of different polarity (DPST-NO model)
10,000 V between coil and contact (with 1.2 x 50 's impulse wave)
Destruction: 10 to 55 Hz, 1.5-mm double amplitude
Malfunction: 10 to 55 Hz, 1.5-mm double amplitude
2
Destruction: 1,000 m/s
2
Malfunction: 100 m/s
Mechanical: 1,000,000 operations min. (at 1,800 operations/hr)
Electrical: 100,000 operations min. (at 1,800 operations/hr under rated load)
Operating: --25#C to 60#C (with no icing)
Operating: 35% to 85%
Quick-connect terminal models: approx. 90 g
PCB terminal models:
Screw terminal models:
approx. 100 g
approx. 120 g
