G7L
Accessories (Order Separately)
Terminals Contact form
Quick-connect SPST-NO
terminals
DPST-NO
Screw terminals SPST-NO
DPST-NO
Applicable Relay
G7L-1A-T/G7L-1A-TJ/G7L-1A-B/G7L-1A-BJ
G7L-2A-T/G7L-2A-TJ/G7L-2A-B/G7L-2A-BJ
G7L-1A-T/G7L-1A-TJ/G7L-2A-T/G7L-2A-TJ
G7L-1A-B/G7L-1A-BJ/G7L-1A-BUB/G7L-1A-BUBJ
G7L-2A-B/G7L-2A-BJ/G7L-2A-BUB/G7L-2A-BUBJ
Model Number Legend
G7L - -
1 2 3 4 , 5
1. Contact Form
1A: SPST-NO
2A: DPST-NO
2. Terminal Shape
T: Quick-connect terminals
P: PCB terminals
B: Screw terminals

Application Examples

!
Compressors for air conditioners and heater switching
controllers.
!
Switching controllers for power tools or motors.
!
Power controllers for water heaters.
!
Power controllers for dryers.
!
Lamp controls, motor drivers, and power supply switching in
copy machines, facsimile machines, and other office equipment.
!
Lighting controllers.
!
Power controllers for packers or food processing equipment.
!
Magnetron control in microwaves.
2
Model R99-07
E-brackets
G7L-1A-T Yes
G7L-1A-TJ Yes
G7L-2A-T Yes
G7L-2A-TJ Yes
G7L-1A-B Yes
G7L-1A-BJ Yes
G7L-2A-B Yes
G7L-2A-BJ Yes
E-bracket
Adapter
Front-connecting Socket
Cover
3. Mounting Construction
Blank: E-bracket
UB: Upper bracket
4. Special Functions
Blank: Standard mode
J: With test button
P7LF-D DIN
Track
Mounting
Adapter
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Name
R99-07
P7LF-D
P7LF-06
P7LF-C
5. Rated Coil Voltage
AC: 12, 24, 50, 100 to 120, 200 to 240
DC: 6, 12, 24, 48, 100
G7L
P7LF-06
Front-con
necting
Socket
Yes
Yes
Yes
Yes
No
No
No
No
Model
