Page 1 Cat. No. H201-E1-01 E5AR-T E5ER-T Programmable Digital Controller USER’S MANUAL...
Page 2: Introduction
• This product is designed for use by qualified personnel with a knowledge of electrical systems. • Read this manual carefully and make sure you understand it well to ensure that you are using the E5AR-T/ER-T Programmable Digital Controllers correctly.
Page 3: Read And Understand This Manual
The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be suitable for the products.
Page 4: Disclaimers
PERFORMANCE DATA Performance data given in this manual is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application requirements.
Page 5: Precautions
Precautions Definition of Safety Notices and Information The following notation is used in this manual to provide precautions required to ensure safe usage of the product. The safety precautions that are provided are extremely important to safety. Always read and heed the information provided in all safety precautions.
Page 6 Doing so may occasionally result in minor injury due to electric shock. Do not touch the terminals or the electronic components or pat- terns on the PCB within 1 minute after turning OFF the power sup- ply. Doing so may occasionally result in minor injury due to electric shock.
Page 7: Precautions For Safe Use
Digital Controllers are mounted closely side by side or one on top of the other. If this type of mounting is used, use forced cooling, e.g., use a fan to blow air onto the Digital Controllers.
Page 8: Precautions For Correct Use
To prevent inductive noise, separate the wiring for the product's terminal block and connector from high-voltage, high-current power lines. Do not run the wiring parallel to or in the same cable as power lines. The influence of noise can also be reduced by using separate wiring ducts or shield lines.
Page 9: About This Manual
Explains calibration procedures that can be performed by the user. Troubleshooting Section 10 Troubleshooting Explains what to do when you encounter a problem. Appendix Provides product specifications and lists of parameters. Can be used to make a copy of your parameter settings. VIII...
Page 10 Engineering units* Fixed SP * Data after scaling is shown in engineering units such as °C, m, and g. “EU” is used to indicate the minimum increment of such a quantity. For example, the minimum increment of 50.02 m is 0.01 m, and thus 1 EU would be equal to 0.01 m.
Page 11: Revision History
● Revision History The revision code of this manual is given at the end of the catalog number at the bottom left of the back cover. The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.
Page 12: Table Of Contents
TABLE OF CONTENTS Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - I Precautions on Using the Product - - - - - - - - - - - - I...
Page 13 Program Setting Example ..............4-25 Performing ON/OFF Control ..............4-31 ON/OFF Control ................4-31 Settings ..................... 4-32 4.10 Determining the PID Constants (AT or Manual Settings) ......4-33 Auto-tuning (AT) ................4-33 Limit Cycle ..................4-35 Manual Settings ................4-36 4.11 Using Auxiliary Outputs ................
Page 14 MV at PV Error .................. 5-17 Display and Key Adjustment Functions ............ 5-18 Display Scan ..................5-18 PF Settings (Function Keys) ............. 5-20 Other Display and Key Adjustment Functions ........5-22 Protecting Settings ................... 5-23 Protection ..................5-23 Alarm Adjustment Functions ..............5-25 Alarm Hysteresis ................
Page 15 Reading Monitor Values ..............6-17 Reading Set Values ................6-18 Composite Read from Variable Area ..........6-19 Writing Set Values in Protect Level ..........6-21 Writing Set Values ................6-21 Set Value Compound Write .............. 6-23 Composite Read Registration ............6-24 Composite Read Registration Confirmation ........
Page 16 8.10 Approximation Setting Level (l.tec) ............8-46 8.11 Input Initial Setting Level (l.0) ..............8-49 8.12 Control Initial Setting Level (l.1) .............. 8-55 8.13 Control Initial Setting 2 Level (l.2) ............8-63 8.14 Alarm Setting Level (l.3) ................8-74 8.15 Display Adjustment Level (l.4) ..............8-80 8.16 Communications Setting Level (l.5) ............
Page 17 10.2 Error Messages ..................10-3 10.3 Inferring Causes from Conditions: Abnormal Measured Values ....10-4 The Measured Value Is Abnormal or Measurement Is Not Possible 10-4 10.4 Inferring Causes from Conditions: Abnormal Control ....... 10-6 The PV Does Not Increase ............... 10-6 The Measured Value Increases Above the SP .........
Page 18 Section 1 Overview Main Features of the E5AR-T and E5ER-T ....... 1-2 Part Names and Functions ..........1-4 I/O and Main Functions ............. 1-8...
Page 19: Main Features Of The E5Ar-T And E5Er-T
Analog inputs: Current inputs: 4 to 20 mA or 0 to 20 mA Voltage inputs: 1 to 5 V, 0 to 5 V, or 0 to 10 V ● Multiple Inputs • The E5AR-T is available with either 2 input or 4 input channels.
Page 20: Outputs
1.1 Main Features of the E5AR-T and E5ER-T • PID sets can be selected not only by directly specifying the PID set number in a program, but they can also be selected automatically according to the present value, deviation, or set point.
Page 21: Part Names And Functions
Section 1 Overview 1.2 Part Names and Functions ■ Front Panel ● E5AR-T Operation Indicators SUB1 SUB2 SUB3 SUB4 WAIT FSP Channel Indicator 8.8.8.8.8 Program Status Indicators Display No. 1 8.8.8.8.8 Bar Graph Display No. 2 8.8.8.8 PRG. Display No. 3...
Page 22: Interpreting The Display
It is always OFF on models with only one input. The E5ER-T indicates the channel using the CH2 operation indicator. ● Bar Graph Shows a bar graph of the set item, such as the program time remaining or output level. ● Program Status...
Page 23 – : Indicates that the model does not support the function. 2.When the control output is a current output, the indicator turns OFF when the MV is 0% or less and turns ON when the MV is greater than 0%.
Page 24: Using The Keys
Mode Key Hold down to change the parameter backward (one change per second). Each time the U Key is pressed, the value of the No. 2 display increases. Hold Up Key down the key to increase the value quickly. The key is also used to scroll forward through the setting items.
Page 25: I/O And Main Functions
Channel 1 Segment No. Output SEG.1 Channel 1 Segment Output/ Time Signal PEND.1 Channel 1 Program End Models with more than one input have the same setting data for channels 2 to 4, depending on the number of input points.
Page 26: Main Functions
1.3 I/O and Main Functions ■ Main Functions ● Inputs First, set the input type switch for each input to specify using either a temperature input (thermocouple (TC) or resistance thermometer (PT)) or an analog input (current input or voltage input), and then set the Input Type parameter.
Page 27: Control Modes
(When the present value (PV) is lower than the set point (SP), the MV is increased in proportion to the (heating) difference between the PV and the SP.) • When pulse outputs are used, the control period must be set for each channel. 1-10...
Page 28 Position-proportional Control Models. Floating control enables position-proportional control without a feedback potentiometer. ● Control/Transfer Parameters can be used to assign the type of data that is output from Output each output. For the models with more than one input, assignments...
Page 29 Section 1 Overview For linear current outputs, 0 to 20 mA or 4 to 20 mA can be selected. Pulse voltage outputs are 12 VDC, 40 mA. Outputs Multi-output output type OUT1 Linear current output, output type Pulse Voltage Output...
Page 30: Model Number Structure
Multi-input + multi-input Communications method None Blank CompoWay/F The above information on the model number structure is based on functionality. Models may not actually be available for all possible combinations of features. Please check the catalog for availability before ordering. 1-13...
Page 31 Section 1 Overview 1-14...
Page 32 Section 2 Preparations Installation ................. 2-2 Using the Terminals ............2-4...
Page 33: Installation
Section 2 Preparations 2.1 Installation ■ Dimensions ● E5AR-T 11.5 SUB1 SUB2 SUB3 SUB4 WAIT 8 8.8.8.8.8 8.8.8.8.8 8.8.8.8 PRG. MANU OUT1 OUT2 OUT3 OUT4 HOLD RUN/RST ● E5ER-T 11.5 SUB1 SUB2 SUB3 SUB4 WAIT 8.8.8.8.8 8.8.8.8.8 8.8.8.8 PRG. MANU...
Page 34: Installation Procedure
● Pulling Out the Normally there is no need to pull out the Controller. However, it can be Controller pulled out if needed for maintenance purposes. When pulling out the Controller, place a cloth over the screwdriver to...
Page 35: Using The Terminals
Section 2 Preparations 2.2 Using the Terminals Verify the layout of the terminals (labeled beginning from A and from 1) using the markings on the top and sides of the case. ■ Terminal Arrangements ● E5AR-T E5AR-TQ4B E5AR-TC4B 24 VAC/DC...
Page 36 (Current) (Voltage) (Thermocouple) (Platinum resistance thermometer) Note: With the E5AR-T, the power supply voltage must be 100 to 120 V for UL compliance. With the E5AR-T, the power supply voltage must be 100 to 240 V for CE marking compliance.
Page 37 (Current) (Voltage) J, K (Platinum resistance thermometer) Note: With the E5AR-T, the power supply voltage must be 100 to 120 V for UL compliance. With the E5AR-T, the power supply voltage must be 100 to 240 V for CE marking compliance.
Page 38 (Current) (Voltage) (Thermocouple) (Platinum resistance thermometer) Note: With the E5AR-T, the power supply voltage must be 100 to 120 V for UL compliance. With the E5AR-T, the power supply voltage must be 100 to 240 V for CE marking compliance.
Page 39 (Switched by output type setting.) Note: With the E5AR-T, the power supply voltage must be 100 to 120 V for UL compliance. With the E5AR-T, the power supply voltage must be 100 to 240 V for CE marking compliance.
Page 40: Precautions When Wiring
(Switched by output type setting.) Note: With the E5AR-T, the power supply voltage must be 100 to 120 V for UL compliance. With the E5AR-T, the power supply voltage must be 100 to 240 V for CE marking compliance.
Page 41: Wiring
24 VDC (no polarity) 10 W ● Inputs (Terminals) • For input 1 (IN1), connect terminals K4 to K6 on the E5AR-T, or E4 to E6 on the E5ER-T according to the input type, as shown below. E5AR-T • For a Controller with more than one input, connect inputs 2 to 4 (IN2 to IN4) in the same way according to the number of input points.
Page 42 OUT1 OUT2 OUT3 OUT4 OUT1 OUT3 • If terminals 5 and 6 are used for a pulse voltage output, approxi- mately 2 V are output when the power is turned ON (load resistance: 10 k max. for 10 ms). • If a linear current output is used, approximately 2 mA are output for 1 second when the power is turned ON.
Page 43 • On the E5AR-T@E@@, auxiliary outputs 1 to 5 (SUB1 to SUB5) SUB1 SUB6 SUB7 SUB2 output to terminals B1 to B6, and auxiliary outputs 6 to 10 (SUB6 to SUB8 SUB3 SUB10) output to terminals C1 to C6. SUB4...
Page 44 2.2 Using the Terminals • On the E5ER-T@4@@, auxiliary outputs 1 to 4 (SUB1 to SUB4) output to terminals B1 to B6. E5ER-T@4@@ SUB1 SUB2 SUB3 SUB4 • Relay output specifications are as follows: 250 VAC 1 A • On the E5ER-T@T@@ auxiliary outputs 1 and 2 (SUB1 and SUB2) output to terminals D3 to D6.
Page 45 • To use event inputs on the E5ER-T, connect event inputs 1 and 2 (EV1 and EV2) to terminals E1 to E3 and event inputs 3 to 6 (EV3 to EV10 EV6) to terminals numbers B2 to B6. The number of event input points depends on the model.
Page 46 2.2 Using the Terminals • The number of input points for each model is as follows: E5AR-T@@@B, E5ER-T@@@B: 2 points, EV1 and EV2 E5AR-T@@D@, E5ER-T@@D: 4 points, EV3 to EV6 E5AR-T@@M@: 8 points, EV3 to EV10 E5AR-T@@MB: 10 points, EV1 to EV10...
Page 47 RS-485 RS-485 A( ) A( ) • The connection type is 1:1 or 1:N. With a 1:N installation, up to 32 RS485 Controllers, including the host computer, can be connected. • The maximum total cable length is 500 m. • Use a shielded twisted-pair cable (AWG28 min.).
Page 48 2.2 Using the Terminals Insulation Blocks As shown in the following diagram, the function blocks of the E5AR-T/ ER-T are electrically insulated. Functional insulation is provided between all of the following: <Inputs>, <event inputs/voltage outputs/current outputs>, and <communica- tions>. Basic insulation is provided between all of the following: <Inputs/event inputs/voltage outputs/current outputs/communications>, <relay...
Page 49 Section 2 Preparations 2-18...
Page 50: Typical Control Examples
Section 3 Typical Control Examples Standard Control ............... 3-2 Coordinated Electric Oven Operation ........ 3-7...
Page 51: Standard Control
Section 3 Typical Control Examples 3.1 Standard Control This section introduces an example of program control of an electric oven as a basic control example. ■ Application ● Connection The following connections are used to control an electric oven using Configuration the E5AR-T.
Page 52: Wiring
TC. PT. TC.PT TYPE ANALOG 2. Turn ON the power and then hold down the L Key for at least 3 seconds to Input Initial Setting Level move from the Operation Level to the Input Initial Setting Level. i1-t Input 1...
Page 53 Section 3 Typical Control Examples 3. Press the L Key for less than 1 second to move from the Input Initial Control Initial Setting Level Setting Level to the Control Initial Setting Level. o1-t (Output 1 Type) will o1-t Output 1 be displayed.
Page 54: Program Settings
3. Press the M Key to select seg.n (Segment Editing). Change from end to seg.n Segment Editing 01.00 4. Press the M Key to select sp (Segment Set Point). Press the U Key to set Segment the set point to 200.0. Set Point 200.0...
Page 55: Adjustment
7. Press the M Key to return to seg.n (Segment Editing). The segment seg.n Segment Editing number will automatically change to 2. 01.02 8. Press the M Key to select sp (Segment Set Point). Press the U Key to set Segment the set point to 800.0. Set Point 800.0 01.02...
Page 56: Coordinated Electric Oven Operation
3.2 Coordinated Electric Oven Operation With Models with Four Input Channels, coordinated operation can be performed based on channel 1. Operation is programmed using the same program for all channels. Offsets can be set for channels 2 to 4. ■ Application Traditionally, three programmable temperature Controllers were required to control electric ovens in three zones.
Page 57: Settings
4. l.adf 4. Press the L Key twice for at least 1 second to return to the Input Initial Setting Level, and then press the L Key for at least 1 second to return to the Operation Level.
Page 58 Setting Output Parameters ..........4-20 Program Settings ............. 4-23 Performing ON/OFF Control ..........4-31 4.10 Determining the PID Constants (AT or Manual Settings) . 4-33 4.11 Using Auxiliary Outputs ........... 4-37 4.12 Starting and Stopping Operation ........4-41 4.13 Manual Operation ............4-47 4.14 Changing Channels ............
Page 59: Setting Levels And Key Operations
The parameters are grouped into levels and the values that are set for the parameters are called set values. On the E5AR-T/ER-T, the parameters are grouped into 19 levels as shown below. When the power is turned ON, all indicators will light for 1 second. The initial level after turning ON the power is the Operation Level.
Page 60 Initialization of settings and PF Key settings. Level Expansion Control Setting Advanced control settings and position-proportional Level control settings. Calibration Level Calibration by the user. * To move to the Advanced Function Setting Level, set the Initial Setting Protection parameter in the Protect Level to 0.
Page 61: Changing Parameters
• The first parameter will be displayed if the M Key is pressed when the last parameter is being displayed. • To change a setting, use the U and D Keys to change the setting and then either wait for 2 seconds or press the M Key to save the change.
Page 62 Adjustment, Communications Settings, Advanced Function Settings, Expansion Control Settings and Calibration. Control will stop on all channels as soon as you move to any of these levels. Display No. 3 shows the current level. The characters and the corre- sponding levels are as follows: Display Level No.
Page 63: Set Values
Section 4 Settings Required for Basic Control 4.2 Set Values The value selected for each parameter is called the set value. There are two types of set values: numbers and characters. Set values are displayed and changed as follows: Changing a Numeric Set Value 1.
Page 64: Initial Setting Example
This section describes how to make the initial settings for the sensor input type, alarm type, control period, and other parameters. Use the L Key and M Key to move through the displays. The parameter that is displayed next depends on how long the key is held down.
Page 65 2 0: Pt100(1) 200.0 to 850.0 C and D keys. (P. 4-10). Press less than 1 second. Display No. 3 will show l. 1 (Control Initial Setting Level). Control Initial Setting Level 2. Refer to output o1-t Check the output...
Page 66 Alarm Set 1, Alarm Value 1 value 1 with the 200.0 0.0 200.0: 200.0 C U and D keys l.alm 8. Trial operation At least 1 second to start operation. RUN/RST Refer to AT Less than 1 second (Auto Tuning) Adjustment Level (P. 4-33) l.adj...
Page 67: Setting The Input Type
When using a Controller with more than one input, also set input type switches 2 to 4 and the Input 2 to 4 Type parameters according to the number of input points.
Page 68 Setting the Display to Show 0.0 for an Input Value of 5 mA and 100.0 for 20 mA When the Input 1 Type Parameter Is Set to 4 to 20 mA. 1. Hold down the L Key for at least 3 seconds to move from the Operation 25.0...
Page 69: Input Type
0 to 5 0 to 10 V 0 to 10 The operation of E5AR-T/ER-T control functions and alarms is based on the input value. If a value greater than inp.2 (Scaling Input Value 2 is set for inp.1 (Scaling Input Value 1...
Page 70 The upper-limit alarm and lower-limit alarm will be inverted. Therefore, set an alarm type and alarm values that invert the upper limit or lower limit of the display value. For example, if an absolute-value upper limit is set for the alarm type, operation will be as shown in the following figure.
Page 71: Selecting The Temperature Unit
Section 4 Settings Required for Basic Control 4.5 Selecting the Temperature Unit When the input type is set to a temperature input (input from a thermocouple or a platinum resistance thermometer), either °C or °F can be selected for the temperature unit.
Page 72: Selecting The Control Mode
4.6 Selecting the Control Mode 4.6 Selecting the Control Mode The control mode allows various types of control to be performed. The control mode is set to standard control by default. ■ Standard Control • Standard heating or cooling control is performed. The Direct/ Reverse Operation parameter is used to select heating (reverse operation) or cooling (direct operation).
Page 73: Standard Control With Remote Sp
• Proportional control is set in the Analog Parameter 1 (control rate) parameter. • If the input type set for input 1 and input 2 are different, the units for input 1 and input 2 must be adjusted. Settings must be made for the...
Page 74: Cascade Standard Control
■ Cascade Standard Control • Cascade control can be performed using standard control (heating control or cooling control). • Input 1 is for the primary loop (channel 1) and input 2 is for the secondary loop (channel 2). ● AT with Cascade...
Page 75: Position-Proportional Control
If the PV is within the PV dead band, control is performed as if the PV is the same as the SP. The PV dead band is set in the PV Dead Band parameter. This function is useful to prevent unnecessary outputs when the PV approaches the SP.
Page 76 The Operation at Potentiometer Input Error parameter is used to select Potentiometer the operation to perform if an error occurs with the potentiometer during closed control. The selections are to stop control or switch to Input Error floating control and continue.
Page 77: Setting Output Parameters
Set point Direct Operation Reverse Operation • For example, when the present value (PV) is less than the set point (SP) during heating control, the manipulated valuable (MV) is increased in proportion to the difference between the PV and SP. As such, heating control is “reverse operation.”...
Page 78: Output Type
The following are multi-outputs: output 1 of the E5AR-TQ@@@@ and E5ER-TQ@@@, and outputs 1 and 3 of the E5AR-TQQ@@. • A linear current output can be set to 4 to 20 mA or 0 to 20 mA in the Linear Current Output * Type parameter.
Page 79 Section 4 Settings Required for Basic Control Control- Control- Controllers with Out- Control/Transfer output Control mode lers with 1 lers with 4 2 inputs assignment input inputs OUT1 Channel 1 Control Output (Heating) OUT2 Channel 2 Control Output (Heating) Standard...
Page 80: Program Settings
4.8 Program Settings 4.8 Program Settings ■ Outline of Program Functions • Up to 32 programs can be created and each program can have up to 32 segments as long as the total number of segments does not exceed 256.
Page 81 (hours. minutes or minutes. seconds) or between 0.00.0 and 99.59.9 (minutes. seconds.tenths of seconds). The default is 0.00 or 0.00.0. • The first segment is a soak segment. To start from a ramp, set the Segment Time parameter for segment 1 to 0 to create a program that starts from segment 2 (when the Operation at Reset parameter is set to “Control Stop”).
Page 82: Program Setting Example
4.8 Program Settings ■ Program Setting Example In this example, the following program will be created as program 2. Segment 1 Segment 2 Segment 3 Segment 4 100.0 50.0 5:00 8:00 10:00 5:00 Time (h:min) The following table shows the settings required for the Number of Segments, Number of Segments Used, and Program No.
Page 83 Use the following procedure to set the Number of Segments parameter to 8 (thus setting the number of programs to 32). (1) Hold down the L Key for at least 3 seconds to move from the Operation Number of Segments Level to the Input Initial Setting Level.
Page 84 (3) Press the M Key to display the Number of Segments Used parameter for s-no program 2. Use the U and D Keys to set the value to 4. 02.00 (4) Hold down the L Key for less than 1 second to return to the Operation Level. 4-27...
Page 85 Use the following procedure to set the Segment Set Point and Segment Time parameters for segments 1 to 4 for program No. 2. (1) Hold down the L Key for less than 1 second to move from the Operation Segment Set Point Level to the Program Setting Level.
Page 86 U and D Keys to select the desired segment number.) (7) Press the M Key for less than 1 second to display the Segment Set Point parameter for segment 2. Use the U and D Keys to set the Segment Set 100.0...
Page 87 Section 4 Settings Required for Basic Control (13)Press the M Key for less than 1 second to display the Segment Set Point parameter for segment 4. Use the U and D Keys to set the Segment Set 50.0 Point parameter for segment 4 to 50.0.
Page 88: Performing On/Off Control
SP during control. When the control output turns OFF, the temperature begins to fall, and once it falls to a certain point, the control output turns ON again. This action is repeated around a certain position. ON/OFF control requires setting the Hysteresis (Heating) parameter to the temperature drop from the SP where control output should turn ON.
Page 89: Settings
2. The PID Selection parameter is displayed in the PID Setting Level. If a PID d.pid set number will not be used, use the default setting (1). If a PID set number will be used, select the PID set number for the desired control.
Page 90: Determining The Pid Constants (At Or Manual Settings)
Operation at Reset parameter is set to stop control, or if Manual Mode is entered. • When executing AT, select 0 to execute AT for the PID set that is currently being used for control, or select 1 to 8 as to execute AT for a specific PID set.
Page 91 To stop AT, select off (AT Cancel). Canceling AT l.adj If you attempt to move to the Operation Level and display the PV or SP During AT Execution while AT is being executed, Display No. 2 will flash to indicate that AT Present value (PV) / SP (Display 2) is being executed.
Page 92: Limit Cycle
AT start AT end AT start The amplitude of change of the limit cycle MV can be changed in the Limit Cycle MV Amplitude parameter. For heating/cooling and position-proportional floating control, the limit cycle is as shown below regardless of the deviation.
Page 93: Manual Settings
The PID constants are set in the Proportional Band (P), Integral Time (I), and Derivative Time (D) parameters. • I (integral time) and D (derivative time) can be set to 0 to select a propor- tional action. In the default settings, the Manual Reset Value parameter is set to 50.0% so that the proportional band is centered on the SP.
Page 94: Using Auxiliary Outputs
The default settings are as follows: SUB1 SUB2 SUB3 SUB4 Channel 1 Alarm 1 Channel 1 Alarm 2 Channel 1 Alarm 3 Channel 1 Alarm 4 The E5ER-T@T@@ has only two auxiliary outputs, i.e., they do not have SUB3 and SUB4. 4-37...
Page 95: Alarm Types
∗6 with standby sequence ∗1: Set values 1, 4, and 5: Allow upper and lower limits of alarm to be separately set. The upper and lower limits are indicated by L and H. ∗2: Set value 1: Upper-and lower-limit alarm...
Page 96: Alarm Values
• A group of alarm values is called an alarm set. The Alarm Set Number parameter is set for each program. • Alarm set numbers can be set between 1 to 4. The default is 1. For channels 2 to 4 during coordinated operation and the secondary side (channel 1) during cascade control, however, alarm set numbers can be between 0 and 4.
Page 97 Setting Level. Alarm Value 25.0 7. Hold down the L Key for at least 1 second to move to the Operation Level. 01.01 8. Press the L Key three times (less than 1 second each time) to move to the d.alm...
Page 98: Starting And Stopping Operation
• When using the Position-proportional Models, fully open, fully closed, or hold status can be selected using the MV at Reset parameter. In open status, only the output on the open side is ON. In closed status, only the output on the closed side is ON. In hold status, the outputs on both the open and closed sides are OFF.
Page 99 (The program moves into Fixed SP Mode.) Control is executed for the remote SP when the program moves into Remote SP Mode. • If the Operation at Reset parameter is set to “fixed control,” the first segment will become a ramp segment. • The following table shows example settings.
Page 100 3: For the Standard Models in Manual Mode at the power inter- ruption. 4: If power is interrupted in Auto Mode, the value set for the MV at Reset parameter will be output, unless the Manual Output Method parameter is set to “Output Initial Value.” If the Manual Output Method parameter is set to “Output Initial Value,”...
Page 101 • Power Interrupted during a Ramp Segment If power is interrupted during a ramp segment, the PV when power is restored will be used as the start point for the present SP and ramp operation will be executed at the ramp slope before the power inter- ruption.
Page 102: Other
• Power Interrupted in Fixed SP or Remote SP Mode Ramp operation is not executed for a fixed SP or remote SP if the power is interrupted in Fixed SP Mode or Remote SP Mode.
Page 103: Settings
(1) Press the M Key several times to select r-r: Run/Reset. 25.0 01.01 01.01 (2) Press the U Key to switch to rst: Reset. The RST indicator will light and the program will stop. To restart the program, use the same procedure to switch to run: 01.01 Run.
Page 104: Manual Operation
Display No. 3. When a potentiometer is not connected, Display No. 2 shows “-----.” • To turn ON the open output, press the U Key. To turn ON the close output, press the D Key. The MV is updated every 50 ms.
Page 105 Section 4 Settings Required for Basic Control • Switching between auto and manual is possible a maximum of 100,000 times. • If switching is performed more than 100,000 times, the auto/manual settings will not be written to EEPROM. 4-48...
Page 106 MV is given below. ◆ Auto/Manual Set for PF1 or PF2 Setting 1. Hold down the PF Key set to switch between auto and manual at least 1 25.0 second. The MANU indicator will light and the mode will change to Manual.
Page 107: Changing Channels
• Only channels that are enabled with the Number of Enabled 8.8.8.0.0 Channels parameter can be displayed. 01.01 PRG. • If the Number of Enabled Channels parameter is set to 2 on a 4- point input type, the display will switch through the channels as OUT1 OUT2 OUT3 OUT4 HOLD...
Page 108: Adjusting Programs
This section describes the vector changes. ■ Changing the SP If the SP is changed during a segment, the present SP will move in a straight line with the changed SP as the target point. Before change...
Page 109: Operating Precautions
Section 4 Settings Required for Basic Control 4.16 Operating Precautions (1) About four seconds is required for the outputs to turn ON after the power is turned ON. Take this into consideration when incorporating the Controller into a sequence circuit.
Page 110 Section 5 Functions and Operations Input Adjustment Functions ..........5-2 Control Functions .............. 5-8 Output Adjustment Functions .......... 5-15 Display and Key Adjustment Functions ......5-18 Protecting Settings ............5-23 Alarm Adjustment Functions..........5-25 Program Operation Functions.......... 5-28 Using Event Inputs............5-39 Using a Transfer Output ...........
Page 111: Input Adjustment Functions
0.00 • Straight-line correction is accomplished by setting the Input Correction 1 parameter to the desired value for the input value set in the Input Value 1 for Input Correction parameter and setting the Input Correction 2 parameter to the desired value for the input value set in the Input Value 2 for Input Correction parameter.
Page 112: Input Adjustment Functions
5. Correction has now been performed at two points, near room temperature and near the SP. If you wish to improve the accuracy near the SP, establish two more correction points above and below the SP. Figure 2 illustrates the...
Page 113 (e.g., 25 C) (e.g., 550 C) Figure 2. Two-Point Correction ● Example of 2-point The following example for a K typing input (1) from 200 to 1300°C. Correction • The temperature of the object is obtained. Input Value 1 for Input Correction i5i.1...
Page 114: First Order Lag Operation
5.1 Input Adjustment Functions ■ First Order Lag Operation First Order Lag • A first order lag operation serves as a filter for an input. For a Operation 1 Enabled Controller with more than one input, the operation is set for each of lag.1...
Page 115: Broken-Line Approximation
Inputs 1 to 20 and Broken-line Approximation 1 Outputs 1 to 20 parameters. Normalized data is used to set the values so that the lower limit of the input setting range for input 1 is 0.000 and the upper limit is 1.000.
Page 116: Extraction Of Square Root
The low- Root 1 Low-cut Point cut point is set for each input using normalized data so that the lower sqrp.1 limit of the input setting range is 0.000 and the upper limit is 1.000.
Page 117: Control Functions
40.0 30.0 ● Alarm Values • The alarm values for alarms 1 to 4 are set according to the alarm Alarm Set 1 Alarm Value 1 type. Alarms for which the Alarm Type parameter is set to 0 (“No 1.al-1 Alarm”) will not be displayed.
Page 118: Sp Limits
SP upper and lower limits can be set within the input setting range. SP Upper Limit If an SP limit is changed so that the SP is outside of the limit, the sl-h previous SP set value will be automatically changed to the new value 1300.0...
Page 119: Pid Sets
50.00 l.pid ● Automatic • One of the PID set numbers 1 to 8 can be set in the PID Set Number Selection of the parameter in the Program Setting Level. If the PID Set Number parameter is set to 0, the PID set will be automatically selected (PID PID Set Set Automatic Selection).
Page 120: Operating Programs Using Multiple Channels
999.9% FS To prevent chattering when changing PID sets, hysteresis can be set in the PID Set Automatic Selection Hysteresis parameter. The PV, DV (deviation), or SP can be set for the PID Set Automatic Selection Data parameter. Default...
Page 121 SP for channels 2 to 4. The present SP or the PV can be set as the program pattern from channel 1. If the PV is set and channel 1 has an input error, an RSP input error will occur for channels 2 to 4.
Page 122: Disturbance Overshoot Adjustment
(The default value of 1 is normally used for the disturbance time constant. If adjustment of the distur- Disturbance Time Constant bance gain alone is not sufficient, this value can be adjusted for fine- dotc tuning.) 1.00...
Page 123 • The Disturbance Rectification Band and Disturbance Judgement Width parameters are set as percentages of FS. As such, if the input type is K (1) (-200.0 to 1300.0°C) and you wish to set the distur- bance judgement width to 15.0°C, 15.0°C/1500.0°C...
Page 124: Output Adjustment Functions
• Upper and lower limits can be applied to the output of the calculated MV Upper Limit 1.ol-h • When using ON/OFF control, the MV will be the value set for the MV 100.0 Upper Limit parameter when the output is ON and the value set for l.pid...
Page 125: Mv Change Rate Limit
• When control is stopped (MV Output at Stop) • During MV Output at PV error • If you wish only to limit the rate of increase in the MV, set the MV Change Rate Limit Mode parameter to 1.
Page 126: Mv At Reset
In heating/cooling control, a negative value is used for the cooling MV. Thus when the MV at Reset parameter is positive, the MV will be sent to the heating output, and when negative the MV will be sent l.adj to the cooling output.
Page 127: Display And Key Adjustment Functions
• If the PF1 Setting or PF2 Setting parameter is set to “CH” (CH Key), Start Display Scan at Power ON the PF1 or PF2 Key can be used as a CH Key. If the CH Key is not sc-m set for a function key, automatic starting of the display scan after turning ON the power is also disabled.
Page 128 2 0 0 0 0 1 0 1 0 1 0 1 Display automatically changes to next channel when the period in Display Scan Period parameter elapses. : Stops display scan Display scan stopped. 1 second or more PV/Present Set Point...
Page 129: Pf Settings (Function Keys)
Program, Monitor/Setting Item, Key. When run or reset operations are set, the key must be pressed for at least 1 second for run, but for at least 2 seconds for reset. 5-20...
Page 130 The PF1 Setting or PF2 Setting parameter can be set to pfdp Item (Monitor/Setting Item) to display monitor/settings using a function key. The content to be displayed is set for each channel in the Monitor/ Setting Item 1 to Monitor/Setting Item 5 parameters of the corre- sponding function key.
Page 131: Other Display And Key Adjustment Functions
Operation Level of the new channel will be displayed. • If the other function key is pressed and it is also set to Monitor/ Setting Items, the first monitor/setting item set for that key will be displayed.
Page 132: Protecting Settings
5.5 Protecting Settings 5.5 Protecting Settings ■ Protection Protection is used to restrict access to settings in order to prevent accidental changes to the settings. The following protection can be set: Operation Adjustment Protection, Initial Setting Protection, Setting Change Protection, and PF Key Protection.
Page 133 Prohibited • When the Initial Setting Protection parameter is set to 2, nothing happens when the Level Key is held down to move to Input Initial Setting Level from Operation Level, Program Setting Level, Adjustment Level, Adjustment 2 Level, Alarm Set Setting Level, PID Setting Level, Time Signal Setting Level, Approximation Setting Level, or Monitor Item Level.
Page 134: Alarm Adjustment Functions
Alarm hysteresis Alarm hysteresis Alarm value Alarm value • Alarm hysteresis can be set separately for each alarm in the Alarm 1 to 4 Hysteresis parameters. • All default values are 0.02 (%FS). ■ Standby Sequence • A standby sequence is used to delay alarm output until the PV Standby Sequence Reset leaves the alarm range once and then subsequently enters it again.
Page 135: Alarm Latch
• The default setting is 0 (Conditions A). ■ Alarm Latch • The alarm latch is used to make an alarm output that has turned ON Alarm 1 Latch remain ON until the power is turned OFF, regardless of the temper-...
Page 136 5.6 Alarm Adjustment Functions ● Alarm Operation • The following example summarizes alarm operation. (In this Summary example, a “Lower Limit Alarm with Standby Sequence” and “Close in Alarm” are selected). Alarm Type: Lower Limit Alarm with Standby Sequence Alarm hysteresis...
Page 137: Program Operation Functions
• The Time Unit of Ramp Rate parameter can be set to 10 hours, hours, minutes, or seconds. The default is minutes. • If the Segment Rate of Rise parameter is set to 0, the ramp segment is skipped and the soak segment is continued.
Page 138 1 SP or from a PV start with slope priority. • With rate of rise programming, the settings are made in blocks of two segments, so the final soak time cannot be set if the Number of Segments Used parameter is set to an even number. Therefore, the...
Page 139: Program Operations
● Changing Set If the rate of rise setting is changed in the middle of a segment, the Values segment time for the ramp period changes as well as the rate of rise for the present SP.
Page 140: Sp Modes
• A back operation resets the segment timer and returns to the beginning of the current segment. • If a back operation is executed during a hold, the hold is continued from the beginning of the current segment. ● Program •...
Page 141: Wait
The wait operation can be enabled and disabled for each segment. • Upper and lower limits can be set for the wait band and these can be set for each program. The wait operation will be disabled if the Wait Band parameter is set to 0.
Page 142: Time Signal
The difference (deviation) between the PV and the present set point are constantly compared during program operation. If the PV is not within the wait band, the present set point is held at the point that the deviation went outside the wait band and the program does not move on.
Page 143: Segment Outputs
Time signal output OFF time • The Time Signal 1 Set Segment 1 to Time Signal 6 Set Segment 3 parameters are used to set the segments in which the time signals will start. The default setting is 0 (disabled).
Page 144 5.7 Program Operation Functions Time Segment Output parameter setting Segment output • Segment outputs are turned OFF during a reset. 5-35...
Page 145: Program Status Outputs
• The program end output is forced OFF if the Run/Reset parameter is changed to “Run” during a reset. • If the Program End ON Time parameter is set to “ON,” the output also remains ON during reset status, i.e., until the Run/Reset parameter changes to “Run.”...
Page 146: Operation At Program Start
The program prior to that position is ignored. PV Start with Time The SP at the start of the program is set to the current PV and the Priority ramp rate is modified accordingly to adjust to the segment time. This means that, in general, the segment 2 ramp rate will change from the rate that is set in the program.
Page 147: End Condition
Section 5 Functions and Operations ● Standby • When a standby is set, the program does not start operating until the standby time (set in hours:minutes) has elapsed after the Run/Reset parameter is set to “Run.” • The following conditions apply to operation during a standby: •...
Page 148: Using Event Inputs
Event Input 1 Assignment inputs) using the Event Input Assignment 1 to 6 parameters. eV.1 • On a Controller with more than one input, functions can be assigned for channels 2 and higher for the number of supported channels. Event Input Assignments...
Page 149 Communications Writing OFF Communications Writing ON ● Program Number • The program number can be specified using the ON/OFF status of event inputs. • This program number function creates an operation command that applies to all channels for coordinated operation and one specific channel for independent control.
Page 150 Program No. (Bit 0 Weight 10) to Program No. (Bit 1 Weight 20) are used. • Inputs without program number allocations are treated as OFF. • If the program number is 0 or 33 or higher, the program number in EEPROM will be used. 5-41...
Page 151 Section 5 Functions and Operations ● Run (ON)/ • When the event input is ON, operation is performed and the Run/ Reset (OFF) Reset parameter is set to “Run.” • This Run (ON)/Reset (OFF) function creates an operation command that applies to one specific channel.
Page 152 • This function is valid only when using control with a remote SP. Remote SP (ON) • When the event input is ON, the remote SP (RSP) is used as the SP. When the event input is OFF, the program SP (PSP) is used as the •...
Page 153 Section 5 Functions and Operations ● Program SP (OFF)/ • When the event input is ON, the fixed SP (FSP) is used as the SP. Fixed SP (ON) When the event input is OFF, the program SP (PSP) is used as the •...
Page 154 5.8 Using Event Inputs ● Fixed SP • When the event input is ON, the fixed SP (FSP) is used as the SP. The event input must be reset before this function can be activated again. • The Fixed SP function creates an operation command that applies to one specific channel.
Page 155 Section 5 Functions and Operations ● Back • When the event input is ON, the program returns to the start of the current segment being executed. The event input must turn OFF once before this function can be used again.
Page 156: Using A Transfer Output
5.9 Using a Transfer Output 5.9 Using a Transfer Output ■ Transfer Output Settings • For a transfer output, use an output that is not being used as a control output. ● Control/Transfer • A transfer output can be used to output one of the following five...
Page 157 Lower limit: 10 Upper limit: 80 • If the Input Type, Scaling Input Value 1 or 2, SP Upper and Lower Limit, or Temperature Unit parameter is changed, the Transfer Output Upper Limit and Transfer Output Lower Limit parameters will be returned to the upper and lower limits of the setting range.
Page 158: Using Communications
When performing communications with a host computer, a unit number must be set for each Controller to allow the host computer to recognize it. Any number from 0 to 99 can be set. The unit number is set to 1 by default. When using multiple Controllers, make sure that no Controllers have the same unit number or communica- tions will not take place correctly.
Page 159: Communications Writing
Before performing communications, perform the following steps to set the communications unit number, communications speed, and other communications parameters. 1. Hold down the L Key for 3 seconds to move from the Operation Level to the Input Initial Setting Level. Protocol Selection psel 2.
Page 160 Communications Communications Method ........... 6-2 Frames................6-4 FINS-mini Text ..............6-6 Variable Areas ..............6-7 Read from Variable Area ..........6-10 Write to Variable Area............6-11 Operation Commands............6-13 Setting Areas ..............6-15 Commands and Responses ..........6-17 6.10 Program Example ............6-40...
Page 161: Communications Method
Communications are implemented by creating a program on the host computer. The descriptions in this section are therefore from the perspective of the host computer. For example, “reading” and “writing” refer to the host computer reading from and writing to the E5AR-T/ER- ■ Communications Specifications...
Page 162: Transfer Protocol
After receiving a response from the Controller, have the host computer wait at least 5 ms before sending the next command. When writing multiple sets of parameters in a row, such as when writing to the variable area or performing a compound write, control characteristics may be affected.
Page 163: Frames
02H 30H 30H 30H 30H 30H 30H 35H 30H 30H 03H 36H BCC = 30H + 30H + 30H + 30H + 30H + 30H + 35H + 30H + 30H + 03H = 36H +: XOR (exclusive OR) operation...
Page 164: Response Frames
“0F” FINS command error Could not execute the specified FINS command. Sum of bits that are “1” in received data does not agree with the “10” Parity error communications parity. “11” Framing error Stop bit of command frame characters is 0.
Page 165: Fins-Mini Text
Section 6 CompoWay/F Communications 6.3 FINS-mini Text The FINS-mini Command Text and FINS-mini Response Text form the body of command/response communications. FINS-mini Command Text and FINS-mini Response Text are set as described in this section. ● Command Text FINS-mini Command Text consists of a main request code (MRC) and a sub-request code (SRC), followed by the required data.
Page 166: Variable Areas
6.4 Variable Areas The areas used for data exchange when communicating with the E5AR-T/ER-T are called the variable areas. Present values can be read, and set values can be read and written using the variable areas of the E5AR-T/ER-T. Operation commands and reading Controller attributes do not use the variable areas.
Page 167: Addresses
Address (2 bytes) Channel Address in area 00 to 7F: identifier (0 to 3) 128 variables * Bits other than those for the channel identifier and the address in the area are used for variable types DA to F9.
Page 168: Number Of Elements
■ Number of Elements The number of elements is expressed as a 2-byte hexadecimal number. For example, if the number of elements is 0010, the first 16 elements of data (H'10) from the address are specified. The specification range for the number of elements depends on the command.
Page 169: Read From Variable Area
Section 6 CompoWay/F Communications 6.5 Read from Variable Area Read from a variable area by setting the required data in the following FINS-mini command text format. FINS-mini Command Text Command Variable type Read start address Bit position Number of elements "01"...
Page 170: Write To Variable Area
6.6 Write to Variable Area 6.6 Write to Variable Area Write to a variable area by setting the required data in the following FINS-mini command text format. FINS-mini Command Text Command Variable Write start Number of type address Bit position...
Page 171 Description code • Unable to execute because the communications writing function is disabled. • Write to setting area 1 was attempted from setting area 0. • Write to parameters in Protect Level was attempted from a different level. "2203" Operation error •...
Page 172: Operation Commands
6.7 Operation Commands 6.7 Operation Commands Operation commands are sent using the following FINS-mini command text format. FINS-mini Command Text Command Operation Related code information "30" "05" Data name Description MRC/SRC Specify the Operation Command FINS-mini com- mand. Operation code Specify the operation code.
Page 173 Note: When all channels is specified, only enabled channels will respond and processing will begin from channel 1. If an error is detected on any one channel, an operation error will occur. If all channels end normally, a normal end will occur.
Page 174: Setting Areas
When the power is turned ON, setting area 0 is selected. To access setting area 1, use the Move to Setting Area 1 operation command. To return to setting area 0 from setting area 1, turn OFF the power or use the Software Reset operation command.
Page 175 Section 6 CompoWay/F Communications Variable Description Area type Input Initial Setting Level Control Initial Setting Level Control Initial Setting 2 Level Setting area 1 Alarm Setting Level (Operation Display Adjustment Level stopped.) Communications Setting Level Advanced Function Setting Level Expansion Control Setting Level...
Page 176: Commands And Responses
6.9 Commands and Responses 6.9 Commands and Responses The E5AR-T/ER-T provides a set of commands that read from variable areas, write to variable areas, execute operation commands, and execute other services provided by the CompoWay/F communications protocol. The commands supported by the E5AR-T/ER-T are described below.
Page 177: Reading Set Values
When used in setting area 1, the response for the present value and internal SP will be 0 and the response for the status will be as indicated in the notes in E5@R-T Status (Communications) (P. A-8).
Page 178: Setting Areas
Expansion Control Setting Level This command is used to read set values. The number of elements can be set from 0002 to 0019 to allow reading 2 to 25 set values in consecutive addresses. To specify variable types and addresses, refer to Appendix Setting Lists (P.
Page 179 This command can be used in both setting area 0 and setting area 1. If an area type error or a set value error occurs in any of the data being read, no data will be read. Response code...
Page 180: Writing Set Values In Protect Level
This command writes set values in the Protect Level. Refer to 5.5 Protecting Settings (P. 5-23) for information on Protect Level. This command is used in setting area 0. An operation error will occur if it is used in setting area 1.
Page 181 Expansion Control Setting Level This command is used to write set values. The number of elements can be set from 2 to 24 to write set values at consecutive addresses. To specify an address, refer to Appendix Setting Lists (P. A-6).
Page 182: Set Value Compound Write
"0200" to "023B" "0300" to "033B" Multiple set values can be written by sending a single command. Up to 12 items can be written even if the addresses are not consecutive. To specify variable types and addresses, refer to Appendix Setting Lists (P.
Page 183: Composite Read Registration
To specify variable types and addresses, refer to Appendix Setting Lists (P. A-6). The upper limit of an address depends on the variable type. This command can be used in both setting area 0 and setting area 1. Response code Response "01"...
Page 184: Composite Read Registration Confirmation
This command can be used in both setting area 0 and setting area 1. If an area type error or a set value error occurs in any of the data being read, no data will be read. Response code...
Page 185: Communications Writing
Run/Reset operation command. The default setting is “Communications Writing Disabled.” This command can be used in both setting area 0 and setting area 1. Response code Response "30"...
Page 186: At Execute
0. This command is used in setting area 0. An operation error will occur if it is used in setting area 1. An operation error will also occur in the following cases: •...
Page 187: At Cancel
This command cancels AT. This command is used in setting area 0. An operating error will occur if it is used in setting area 1. An operation error will also occur in the following cases: • If the Run/Reset parameter is set to “Reset” for the specified channel •...
Page 188 This command is used to select the Backup Mode or RAM Write Mode. The default setting is “Backup Mode.” This command can be used in both setting area 0 and setting area 1. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 189: Save Ram Data
Approximation Setting Level to EEPROM. For information on these levels, refer to 4.1 Setting Levels and Key Operations (P. 4-2). This command can be used in both setting area 0 and setting area 1. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 190: Move To Protect Level
Use this command to move to Protect Level. Protect Level is described in 5.5 Protecting Settings (P. 5-23). This command is used in setting area 0. An operating error will occur if it is used in setting area 1. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 191: Parameter Initialization
Manual Use this command to select automatic or manual operation. This command is used in setting area 0. An operating error will occur if it is used in setting area 1. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 192: Alarm Latch Cancel
This command cancels the alarm latch. The command is used when the alarm latch function is in use. This command can be used in both setting area 0 and setting area 1. If AT is being executed for the specified channel, an operation error will occur.
Page 193: Hold
"F2" Fixed SP Use this command to select the SP Mode. Refer to SP Modes in 5.7 Program Operation Functions (P. 5-31) for details on the SP Mode. This command can be used in both setting area 0 and setting area 1.
Page 194: Advance
6.9 Commands and Responses This command starts or cancels the hold operation. This command is used in setting area 0. An operation error will occur if it is used is setting area 1. Operation errors will also occur in the following cases: •...
Page 195: Back
This command executes a back operation. Operation will move to the beginning of the current segment. This command is used in setting area 0. An operation error will occur if it is used is setting area 1. Operation errors will also occur in the following cases: •...
Page 196 6.9 Commands and Responses Model Number Bytes 7 to 9 are not used. (1) Size Symbol Size A size E size (2) Fixed/Program Symbol Fixed/program Program (3) Standard/Position-proportional Standard/position Symbol proportional (Blank) Standard Position-proportional 6-37...
Page 197: Controller Status Read
Operating status Operating Error (MV at PV error output) Stopped (including setting area 1) Manual Mode The operating status of each channel is indicated using a 2-bit code. ◆ Related Information Bit position Bit value Bit position Status Not used.
Page 198: Echoback Test
6.9 Commands and Responses Note: The bit value is an OR of all channels set in the Number of Enabled Channels parameter. If the channel does not exist, “No error (0)” is returned. If this command is used in setting area 1, the related information is undefined.
Page 199: Program Example
■ N88Basic This program displays the response from the E5AR-T/ER-T on the screen when command data is entered from the keyboard. Command data from the unit number to the number of elements must be entered. The program was created in N88BASIC.
Page 200 6.10 Program Example ● Operation Example Reading the Present Value of Unit Number 01 SEND DATA:010000101C00000000001 RESPONSE:010000010100000000014F SEND DATA: [STX] 01 00 0 0101 C0 0000 00 0001 [ETX] [BCC] Number of elements Bit position Read start address Variable type...
Page 201 Section 6 CompoWay/F Communications 6-42...
Page 202: List Of Functions
Section 7 Modbus Communications Communications Method ........... 7-2 Frames................7-4 List of Functions ..............7-7 Variable Areas ..............7-8 Read from Variable Area ..........7-11 Write to Variable Area............7-13 Operation Commands............7-15 Setting Areas ..............7-18 Commands and Responses ..........7-20...
Page 203: Communications Method
Communications are implemented by creating a program on the host computer. The descriptions in this section are therefore from the perspective of the host computer. For example, “reading” and “writing” refer to the host computer reading from and writing to the E5AR-T/ER- ■ Communications Specifications Transfer connection...
Page 204: Transfer Protocol
After a receiving a response from the Controller, have the host computer wait at least 5 ms before sending the next command. When writing multiple sets of parameters in a row, such as when writing to the variable area or performing a compound write, control characteristics may be affected.
Page 205: Frames
Modbus (RTU) protocol. The data included in command frames and response frames is described in this section. In the following descriptions, an "H" before a numeric value (for example H’02) indicates that the value is a hexadecimal number. Numbers or letters enclosed in quotation marks (for example "00") are ASCII characters.
Page 206: Response Frames
(5) Steps 3 and 4 are repeated until the contents of the register have been shifted 8 bits to the right. (6) If the end of the message has not been reached, an XOR is taken of the next byte of the CRC register and the message, the result is returned to the CRC register, and the procedure is repeated from step (3).
Page 207: Error Codes
• The slave address in the received command is different from the communications unit number set in the E5AR-T/ER-T. • A parity error, framing error, or overrun error occurred due to a transfer error or other error. • A CRC-16 code error occurred in the received command frame.
Page 208: List Of Functions
7.3 List of Functions 7.3 List of Functions The function codes supported by the E5AR-T/ER-T are listed below. ● Function Codes Function Name Description codes Reads a variable area. Multiple 03 (H'03) Read from Variable Area variables that are consecutive can be read.
Page 209: Variable Areas
7.4 Variable Areas The areas used for data exchange when communicating with the E5AR-T/ER-T are called the variable areas. Present values can be read, and set values can be read and written using the variable areas of the E5AR-T/ER-T. Operation commands do not use the variable areas.
Page 210: Number Of Elements
Expansion Control Setting Level ● Channel Identifier To specify channels 2 to 4 for Controllers with more than one input channel, specify a channel identifier between 1 and 3 to identify the channel. Only 0 (channel 1) can be specified for controllers with only one input channel.
Page 211: Set Values
Example: D'105.0 H'0000041A This variable is an 8-digit number in hexadecimal. Negative values are expressed as a two's complement. The decimal is disregarded. If the PV of the E5AR-T/ER-T is 105.0, it will be read as H'0000041A (105.0 1050 H'0000041A).
Page 212: Read From Variable Area
7.5 Read from Variable Area 7.5 Read from Variable Area Read from a variable area by setting the required data in the following command frame. Command Frame Command Slave Function Read start Number of address code address elements CRC-16 H'03...
Page 213 H'03 Normal end No error. ● Reading Non-display Data Set values can be read even if the parameters are set not to be displayed or are not displayed due to the model. Command/Response Example Reading the PV of Channel 1...
Page 214: Write To Variable Area
7.6 Write to Variable Area 7.6 Write to Variable Area Write to a variable area by setting the required data in the following command frame. Command Frame Command Slave Function Write start Number of Byte Write data address code address...
Page 215 H'10 Normal end No error ● Writing Non-display Data It is possible to write set values even if they are set to not be displayed or are not displayed due to the model. Exercise caution when writing continuously. Command/Response Example Writing the SP Setting Upper Limit and SP Setting Lower Limit param- eters in the Control Initial Setting Level for channel 1.
Page 216: Operation Commands
Write data and related information (see table below). This is the check code calculated from the slave address through the end of the data. For the calcula- CRC-16 tion method, refer to Example of CRC-16 Calculation in 7.2 Frames (P. 7-4).
Page 217 0: CH1, 1: CH2, 2: CH3, 3: CH4, F: All channels Note: When all channels is specified, only enabled channels will respond and processing will begin from channel 1. If an error is detected on any one channel, an operation error will occur. If all channels end normally, a normal end will occur.
Page 218 Unit error, unit change, display unit error, or EEPROM error. H'06 Normal end No error Command/Response Example Operation Command to Channel 2 (slave address: H'01) Channel 2 Operation Command Address: H'0000 Written data: H'0111 (Reset command to channel 2) (CRC-16) Command:...
Page 219: Setting Areas
When the power is turned ON, setting area 0 is selected. To access setting area 1, use the Move to Setting Area 1 operation command. To return to setting area 0 from setting area 1, turn OFF the power or use the Software Reset operation command.
Page 220 7.8 Setting Areas Area Description Area number Input Initial Setting Level Control Initial Setting Level Control Initial Setting 2 Level Alarm Setting Level Setting area 1 (Operation stopped.) Display Adjustment Level Communications Setting Level Advanced Function Setting Level Expansion Control Setting Level...
Page 221: Commands And Responses
Section 7 Modbus Communications 7.9 Commands and Responses The E5AR-T/ER-T provides a set of commands that read from variable areas, write to variable areas, execute operation commands, and execute other services provided by the Modbus communications protocol. The commands supported by the E5AR-T/ER-T are described below.
Page 222: Reading Set Values
This command is used to read set values. The number of elements can be set from H'0004 to 006A (4 to 106) to allow successive reading of 2 to 53 set values in consecutive addresses. To specify the variable type or address, refer to Appendix Setting Lists (P.
Page 223: Writing Set Values In Protect Level
Setting Levels and Key Operations (P. 4-2) for information on Protect Level. This command is used in setting area 0. If used in setting area 1, an error will result. To use this command, first enable using the communications writing...
Page 224: Writing Set Values
Number of elements 2 bytes Data n Data n CRC-16 Most significant Least significant Description Address Set values in setting area 0 H'0600 to 061C Operation Level H'0700 to 074A Adjustment Level H'0800 to 0818 Adjustment 2 Level H'0900 to 096E...
Page 225: Communications Writing
Section 7 Modbus Communications This command is used to write set values. The number of elements can be set from H'0004 to 0068 (4 to 104) to write from 2 to 52 set values at consecutive addresses. To specify the variable type and address, refer to Appendix Setting Lists (P.
Page 226: Run/Reset
When the control mode is set to cascade control, perform the Run/ Reset operation command for channel 2. If "All" is selected for the channel, only the channels that are enabled will be affected by this command. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 227: At Execute
0. This command is used in setting area 0. An operation error will occur if it is used in setting area 1. An operation error will also occur in the following cases: •...
Page 228: At Cancel
This command cancels AT. This command is used in setting area 0. An operating error will occur if it is used in setting area 1. An operation error will also occur in the following cases: • If the Run/Reset parameter is set to “Reset” for the specified channel •...
Page 229: Save Ram Data
Levels to EEPROM. Operation and Adjustment Levels are described in 4.1 Setting Levels and Key Operations (P. 4-2). This command can be used in both setting area 0 and setting area 1. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 230: Software Reset
A software reset causes the same operation as turning the power OFF and ON. This command can be used in both setting area 0 and setting area 1. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 231: Move To Protect Level
Use this command to move to Protect Level. Protect Level is described in 4.1 Setting Levels and Key Operations (P. 4-2). This command is used in setting area 0. If used in setting area 1, an operation error will result.
Page 232: Parameter Initialization
H'F1 Manual Use this command to select automatic or manual operation. This command is used in setting area 0. If used in setting area 1, an operation error will result. To use this command, the communications writing function must be enabled using the Communications Writing operation command.
Page 233: Alarm Latch Cancel
This command cancels alarm latch. The command is used when the alarm latch function is in use. This command can be used in both setting area 0 and setting area 1. If AT is being executed for the specified channel, an operation error will occur.
Page 234: Hold
"F2" Fixed SP Use this command to select the SP Mode. Refer to SP Modes in 5.7 Program Operation Functions (P. 5-31) for details on the SP Mode. This command can be used in both setting area 0 and setting area 1.
Page 235: Advance
This command executes an advance operation. Operation will move to the beginning of the next segment. This command is used in setting area 0. An operation error will occur if it is used in setting area 1. Operation errors will also occur in the following cases: •...
Page 236: Back
This command executes a back operation. Operation will move to the beginning of the current segment. This command is used in setting area 0. An operation error will occur if it is used in setting area 1. Operation errors will also occur in the following cases: •...
Page 237 Section 7 Modbus Communications 7-36...
Page 238 Adjustment 2 Level (l.ad2)..........8-33 Alarm Set Setting Level (l.alm)........8-36 PID Setting Level (l.pid) ..........8-39 Time Signal Setting Level ( ) .......... 8-43 8.10 Approximation Setting Level (l.tec) ....... 8-46 8.11 Input Initial Setting Level (l.0) ......... 8-49 8.12 Control Initial Setting Level (l.1)........
Page 239: Using This Section
Reference ● Conditions for Displaying Parameters A parameter will only appear on the display of the E5AR-T/ER-T when the conditions for use of the parameter are satisfied. (Conditions for use are indicated to the right of the parameter name.) Protected parameters, however, are not displayed regardless of the conditions for use, although they are in effect.
Page 240: Protect Level (L.prt)
8.2 Protect Level ( Protect Level consists of four types of protection: Operation Adjustment Protection, Initial Setting Protection, Setting Change Protection, and PF Key Protection. Each is used to protect the corresponding settings and prevent accidental changes to the settings.
Page 241: Operation Level
This function restricts key operation in Operation Level, Program Function Setting Level, Adjustment Level, Adjustment 2 Level, Alarm Set Setting Level, PID Setting Level, Time Signal Setting Level, Approxi- mation Setting Level, and Monitor Item Level. Operation Level Program Setting...
Page 242 8.2 Protect Level (l.prt) • When the Initial Setting Protection parameter is set to 2, nothing happens when the Level Key is held down for 1 second or more to move to Input Initial Setting Level from Operation Level, Program...
Page 243: Operation Level ( )
Section 8 Parameters 8.3 Operation Level ( ) Display this level to operate the control system. The SP can be set and the PV monitored in this level. ● Level Changes at Startup Up To Operation Level Power ON Power ON...
Page 244 U and D Keys pressing the . On a Position-proportional Control Model, the U Key turns ON the open side and the D Key turns ON the close side. • On a Standard Control Model, Display No. 1 shows the PV and Display No.
Page 245 Mode when the secondary loop is in any of the following conditions, the manual MV is disabled. • The SP mode of the secondary loop is set to “Fixed SP” (cascade open). • The secondary loop is in Manual Mode.
Page 246 8.3 Operation Level ( ) PRG.SEG Present Value (PV)/Present Set Point • Display No. 1 shows the PV and Display No. 2 shows the present set point. Function • The Program SP, Fixed SP, or the Remote SP is shown depending on the selected SP mode.
Page 247 Hold Running • This parameter is used to hold the timer for program operation. • The hold is cleared by executing a reset or executing a clear hold Function command. • The hold is enabled when this parameter is set to •...
Page 248 Back Running • This parameter is used to return the program to the start of the segment being executed. If the back operation is executed during a Function hold, the program returns to the beginning of the segment being executed and the hold status is continued.
Page 249 5.7 Program Operation Functions (P. 5-28) ● Related Parameters Standby Time (Adjustment Level) (P. 8-28) rptm Program Execution Repetition Monitor Running • This parameter is used to monitor the number of times a program has been repeated. Function Monitor range Unit 0 to 9,999...
Page 250 Remote SP Monitor Program SP or Fixed SP Mode with remote SP or Coordinated operation with fixed SP • This parameter is used to monitor the remote SP while in Program SP or Fixed SP Mode. Function • In Remote SP Mode, the remote SP can be monitored on Display No.
Page 251 • This parameter monitors the amount of valve opening during position-proportional control. Function • A potentiometer can be connected and the Motor Calibration parameter can be executed to monitor the amount of valve opening. Control Monitor range Unit Position- propor- 10.0 to 110.0...
Page 252 U and D Keys (Manual) for Manual Mode. When Manual Mode is selected, the MANU indicator lights. Operation • This parameter does not appear if either the PF1 Setting or PF2 setting parameter is set to Auto/Manual. ● Related Information Reference Reference 4.13 Manual Operation (P.
Page 253: Program Setting Level ( )
Section 8 Parameters 8.4 Program Setting Level ( ) The Program Setting Level parameter is used to make the SP, time, rate of rise, and other program settings. The Program Editing parameter, the first parameter displayed under Program Setting Level, is used to move to each program.
Page 254 Program Editing CH1 or CH2 for independent operation The Program Editing parameter is used to make program settings. • This parameter is used to set the program number of the program. Function Setting range Unit Default value 1 to 32 See note.
Page 255 Reference Reference 4.8 Program Settings (P. 4-23) wait Wait CH1 or CH2 for independent operation • This parameter is used to set whether or not to use the wait function. Function Setting range Unit Default value : Disabled : Disabled...
Page 256 (PV), deviation (DV), and present SP (SP). The PID set number can be set between 1 and 8. • If this parameter is set to 0 for channels 2 to 4 when using coordi- nated operation or for the secondary side (CH2) when using cascade control, the PID set number selected for channel 1 will be used for the other channels.
Page 257 Function • If this parameter is set to 0 for channels 2 to 4 when using coordi- nated operation or for the secondary side (channel 2) when using cascade control, the alarm set number selected for channel 1 will be used for the other channels.
Page 258 Program Link Destination • The Program Repetitions parameter is used to set the number of times a program is to be repeated. The number of times the program Function is executed will be the set value for this parameter + 1.
Page 259: Adjustment Level L.adj
Section 8 Parameters l.adj 8.5 Adjustment Level ( This level contains settings for adjusting control, such as auto-tuning (AT), enabling/disabling writing parameters with communications, changing the SP mode, adjusting hysteresis, and input correction settings. ● Level Changes at Startup Up To Adjustment Level...
Page 260: Adjustment Level (L.adj)
The PID constants are calculated from the results and the Propor- tional Band, Integral Time, and Derivative Time parameters are automatically set. • Normally this parameter is off. AT is executed by pressing the U Key to select the PID set number. AT cannot be executed while control is stopped.
Page 261 In Remote SP Mode, the remote SP specified by an external input (e.g., 4 to 20 mA) will be the SP. In Fixed SP Mode, the value set for the Fixed SP parameter will be used as the SP.
Page 262 This parameter sets an output dead band for heating/cooling control. A negative value can also be set to create an overlap band. • Set an area centered on the SP where the control amount is 0 during heating/cooling control. Function...
Page 263 2-PID control (Proportional band 0.00), Integral time = 0 • This parameter is used to set an MV for rectification during P and PD control to eliminate an offset. Function • This parameter is displayed only when the proportional band 0.00...
Page 264 (if the connected Function device is a relay) into consideration. • The Control Period (Heating) parameter is used for standard control. • For heating/cooling control, control periods can be set separately for heating and cooling.
Page 265 ● Related Parameters Reference Reference Position-proportional Dead Band (Adjustment Level) (P. 8-27) l.adj Standby Time • This parameter is used to set the time from when the run command is executed until the program starts operation. Function Setting parameter Unit Default value 0.00 to 99.59...
Page 266 MV at Reset (Standard/Heating/Cooling) mv-e MV at PV Error • On a Standard Control Model, the MV at Reset parameter is set to the MV to output when operation is stopped. On a Position-propor- Function tional Control Model, the MV at Reset parameter is set to the position when operation is stopped (Closed/Hold/Open).
Page 267 MV (or the opening on a Position-proportional Control Model) per Function second. If a change occurs in the MV that exceeds this limit, the MV will be changed at the set rate limit until the required change is attained. When set to 0.0, the function is disabled.
Page 268 0.00 *1 The decimal point position depends on the input type. *2 If the input type is changed, the default values of the input value for input calibration will change to the upper and lower-limits of the input range of the sensor type being used.
Page 269 Disturbance overshoot dojw adjustment is enabled Disturbance Judgment Width These parameters are used to adjust overshooting caused by distur- bance. • Disturbance gain is used to adjust the amount of overshooting caused by disturbance. Function Parameter Setting range Unit Default value Disturbance Gain 1.00 to 1.00...
Page 270: Adjustment 2 Level (L.ad2)
Adjustment 2 Level contains supplemental parameters for adjusting control, such as time constants for first order lag operations, movement average count, low-cut point for extraction of square root operations, and parameters for proportional control. These functions appear on the display only if they are enabled in Control Initial Setting 2 Level.
Page 271 ( : 1 to 4) First Order Lag Operation Function is enabled • These parameters are used to set the time constant of the first order filter of each input. Data resulting from the first order lag filter is Function shown below.
Page 272 Extraction of Square Root * Low-cut Point Extraction of Square Root * Function is enabled • These parameters are used to set the low-cut point of each input. Data resulting from the extraction of square root operations is shown Function below.
Page 273 8.7 Alarm Set Setting Level ( The Alarm Set Setting Level is used to make the alarm value settings for each alarm set. The Display Alarm Setting Level parameter, the first parameter displayed under Alarm Set Setting Level, is used to move to each alarm set.
Page 274: Alarm Set Setting Level (L.alm)
(*: 1 to 4) The alarm values for alarms 1 to 4 can be registered for each alarm set. • The Alarm Set 1 to 4 Alarm Value 1 to 4 parameters are used to set the alarm values. Function •...
Page 275 (*: 1 to 4) These parameters are used to set the alarm upper limits and alarm lower limits for Alarm 1 Type to Alarm 4 Type (Alarm Setting Level) for which upper/lower limits have been selected. • These parameters are used to set the upper and lower limits for alarms 1 to 4 in alarm sets 1 to 4.
Page 276: Pid Setting Level L.pid
This level contains the parameters for the PID constants, MV limits, and alarm settings for each PID set. To move to a PID set, use the Display PID Set Number parameter at the beginning of PID Setting Level. ● Level Changes at Startup Up To PID Setting Level...
Page 277 Use this parameter to select the PID set that you wish to display. • Set the number of the PID set that you wish to display. • Up to 8 PID sets (PID Sets 1 to 8) can be used. PID constants, MV Function upper and lower limits, and automatic selection range upper limits are stored in each PID set.
Page 278 • Use the MV Upper Limit and MV Lower Limit parameters to set upper and lower limits for the MV. When the Controller calculates an Function MV that is outside of the upper and lower limits, the upper or lower- limit is output. • MV Upper Limit The setting range differs for standard control and heating/cooling control.
Page 279 PID set. • Set the automatic selection range upper limit for PID Sets 1 to 8. • The limit for PID Set 8 is fixed at 110% of the sensor setting range, Function and thus does not need to be set.
Page 280: Time Signal Setting Level ( )
8.9 Time Signal Setting Level ( ) The Time Signal Setting Level is used to set time signals. This level is displayed if the Program Output Selection parameter in the Control Initial Setting 2 Level parameter is set to “Time Signal.”...
Page 281 CH1 or CH2 (during independent (*: 1 to 6) control) with time signal enabled • Time signals can be set for 6 outputs for each program, with 3 time signals for each output. Function • This parameter is used to set the segments for which time signals are used.
Page 282 (*: 1 to 6) control) with time signal enabled • These parameters are used to set the OFF time for time signals. • Set the interval between the time signal ON and OFF times to 100 Function ms minimum. Unexpected operation may occur if the interval is set to less than 100 ms.
Page 283: Approximation Setting Level (L.tec)
Section 8 Parameters l.tec 8.10 Approximation Setting Level ( This level contains parameters for straight-line and broken-line approximation settings. These parameters only appear if enabled in Control Initial Setting 2 Level. ● Level Changes at Startup Up To Approximation Setting Level...
Page 284 Specify two points: straight-line approximations 1 and 2. Use Function normalized data for the values. • If Input 1 = Input 2, the setting will not be effective and will be regarded as straight-line approximation with input data = output data.
Page 285 Up to 20 points can be specified for one broken line approxi- Function mation. Use normalized data for the values. • If Input n Input n + 1, the setting of point n + 1 will not be effective. Operation result P5 disabled because Input 5 Input 4...
Page 286: Input Initial Setting Level (L.0)
8.11 Input Initial Setting Level (l.0) 8.11 Input Initial Setting Level ( This level contains Initial setting parameters for inputs, including input types, temperature units, and scaling settings. ● Level Changes at Startup Up To Input Initial Setting Level Power ON...
Page 287 • If these parameters are changed, the SP limit settings are returned Function to the Initial settings. Reset the SP Upper Limit and SP Lower Limit parameters as necessary. • Refer to the following table to set the parameters. The default setting is shaded.
Page 288 • The Decimal Point Position parameter is used to specify the decimal point position of the set values (SP, etc.) given in EU. • Scaling settings for inputs 2 to 4 of a Controller with more than one inputs are set for channels 2 to 4. Press the Key to change to the desired analog input channel and then set the scaling.
Page 289 2. For example, if input 2 is set to 4 to 20 mA, the remote SP upper limit is set with respect to 20 mA and the remote SP lower limit is set with respect to 4 mA.
Page 290 PV Decimal Point Display Temperature input This parameter can be used to not show the digits of the PV below the decimal point. • If this parameter is turned OFF, the digits of the PV below the decimal point are not shown. When turned ON, the digits below the Function decimal point are shown according to the input type setting.
Page 291 • This parameter reduce induction noise in the input according to the frequency of the power source. Function • Select 50 Hz or 60 Hz according to the power source used for the Controller. Setting range Unit...
Page 292: Control Initial Setting Level (L.1)
8.12 Control Initial Setting Level (l.1) 8.12 Control Initial Setting Level ( This level contains Initial setting parameters for control, such as the control method, as well as the output types, SP limits, control mode, direct/reverse operation, and closed/floating settings.
Page 293 E5AR-TQQ@@WW-@@@ and 12 VDC, 40 mA for all other models. • When linear current output is selected, use the Linear Current Output Type parameter to select an output of 0 to 20 mA or 4 to 20 mA. Setting range...
Page 294 SP Lower Limit • Use these parameters to set upper and lower limits for the SP setting. The SP can be set only between these limits. If the limits are Function changed and a previously set SP falls outside of the limits due to the change, the SP will automatically change to the upper or lower limit.
Page 295 3: Remote SP heating/cooling 4: Proportional 5: Cascade standard 6: Cascade heating/cooling The setting range is 0 or 1 on a single- or 4-input Controller Model and 0 to 6 on a 2-input Controller Model. ● Related Information Reference Reference 4.6 Selecting the Control Mode (P.
Page 296 • This parameter can be used to select independent or coordinated operation for models with two input channels. Function • If coordinated operation is selected, coordinated operation based on channel 1 is enabled. The program will be the same for channels 1 and 2. Setting range Unit...
Page 297 8, 12, 16, 20, or 32 Setting Program Time Unit • This parameter is used to specify the time unit for the program. • The Program Time Unit parameter specifies the time unit for the Function following parameters. The Program Time Unit parameter must be set before the following parameters can be set.
Page 298 8.12 Control Initial Setting Level (l.1) Time Unit of Ramp Rate Rate of Rise Programming • This parameter is used to set the time unit for the ramp rate when rate of rise programming is used. Function Setting range Unit...
Page 299 Section 8 Parameters rstm Operation at Reset • This parameter is used to set the operation at reset. Function Setting range Unit Default value stop : Stop control stop : Stop control : Fixed control Setting If the Operation at Reset parameter is set to “Fixed Control,”...
Page 300: Control Initial Setting 2 Level (L.2)
8.13 Control Initial Setting 2 Level ( This level contains Initial setting parameters for processing functions, including control/transfer output assignments, event input assignments, auxiliary output assignments, and first order lag operation enable/ disable settings. ● Level Changes at Startup Up To Control Initial Setting 2 Level...
Page 301 CH2 control output (heating) for transfer output (14) CH2 control output (cooling) for transfer output (15) Disable (16) Similarly, CH3 (17 to 24) CH4 (25 to 32) * The default value is set according to the control mode setting. Control/ Control/ Control/ Control/ Input...
Page 302 8.13 Control Initial Setting 2 Level (l.2) If a pulse output is set to operate as a transfer output (3 to 8 for channel 1), the output will be OFF. ● Related Parameters Reference Reference Linear Current Output Type (Control Initial Setting Level) (P. 8-56) Output 1 Type and Output 3 Type (Control Initial Setting Level) (P.
Page 303 Channel 3 (42 to 61) Channel 4 (62 to 81) • If the same setting is selected for different Event Input Assignment parameters, the event input for which ON/OFF is determined last will be effective. When the power is turned ON and the same program number assignment is repeated, the event input with the higher number is given priority.
Page 304 8.13 Control Initial Setting 2 Level (l.2) Osbo.* Auxiliary Output Assignment ( : 1 to 10) • Use these parameters to assign output content to auxiliary outputs. Function Setting range Unit Default value Disable (0) CH1 Alarm 1 (1) Setting...
Page 305 Section 8 Parameters *1 The data that is output depends on the setting of the Program Output Selection parameter and will be program output 1 to 10, segment output 1 to 10, segment number output 1 to 6, or time signal output 1 to 6.
Page 306 Upper Limit trl. Transfer Output Lower Limit Transfer output using output assignment ( : 1 to 4) • These parameters can only be used for outputs selected for transfer output using the output assignment parameters. Function Default value Control/ (upper limit/...
Page 307 Section 8 Parameters Olag.* First Order Lag Operation Enabled ( : 1 to 4) • Use these parameters to enable or disable first order lag operation for each input. Function Setting range Unit Default value off: Disable off: Disable on: Enable Setting ●...
Page 308 8.13 Control Initial Setting 2 Level (l.2) Osqr.* Extraction of Square Root Enabled ( : 1 to 4) • Use these parameters to enable or disable the extraction of square root operation for each input. Function Setting range Unit Default value...
Page 309 Approximation 1 Output 20 (Approximation Setting Level) (P. 8-48) calb Motor Calibration Position-proportional Control Model • Use this parameter to execute motor calibration. If you are going to monitor the valve opening, be sure to execute this parameter. Function (During execution the display cannot be changed.) •...
Page 310 8.13 Control Initial Setting 2 Level (l.2) Travel Time Position-proportional Control Model • Set the time from when the valve is completely open to when the valve is completely closed. Function • This parameter is automatically set when the Motor Calibration parameter is executed.
Page 311: Alarm Setting Level
Section 8 Parameters 8.14 Alarm Setting Level ( This level contains parameters for the type and output operation of alarms, including alarm types, close in alarm/open in alarm settings, and latch settings. ● Level Changes at Startup Up To Alarm Setting Level...
Page 312: Alarm Setting Level (L.3)
8.14 Alarm Setting Level (l.3) alt* Alarm Type Alarm set for Auxiliary Output : 1 to 4) Assignment parameter • These parameters are used to select the alarm types for alarms 1 through 4. Function Setting range Unit Default value 0: No alarm function...
Page 313 ON until the power is turned OFF. The latch is canceled if you move to setting area 1. • When the alarm output is set to “Close in alarm,” the closed output is held, and when it is set to “Open in alarm,” the open output is held.
Page 314 Hysteresis : 1 to 4) Alarm set for Auxiliary Output Assignment parameter and Alarm Type parameter not set to “No alarm.” • These parameters are used to enable hysteresis for alarms 1, 2, 3, and 4. Function Setting range Unit Default value 0.01 to 99.99...
Page 315 Alarm output: Conditions A Alarm output: Condition B • After changing the standby sequence reset setting, a software reset must be executed or the power turned OFF and ON to make the change take effect. Setting range Unit...
Page 316 1 to 10. Function • When “Close in alarm” is selected, the state of the alarm output function is output without change. When “Open in alarm” is selected, the state of the output function is inverted before output. The relation between the alarm output function, alarm output, and operation indicator is shown below.
Page 317 Section 8 Parameters 8.15 Display Adjustment Level ( This level contains parameters for adjustment of the display contents, including selection of the bar graph display items, display refresh period, Monitor Item Level settings, and display scan parameters. ● Level Changes at Startup Up To Display Adjustment Level...
Page 318: Display Adjustment Level (L.4)
8.15 Display Adjustment Level (l.4) odsl MV Display Selection Heating/cooling control • This parameter is used to select which MV is displayed when a PF Key is set to “Present value (PV),” “Present set point,” or “MV” during Function heating/cooling control.
Page 319 0.5, 1, 2, 4 Setting monl Monitor Item Level Setting • One of the following levels can be selected as the Monitor Item Level setting: Input Initial Setting Level, Control Initial Setting Level, Function Control Initial Setting 2 Level, Alarm Setting Level, Display Adjustment Level, Communications Setting Level, Advanced Function Setting Level, and Expansion Control Setting Level.
Page 320 • To have display scan start automatically after the power is turned ON, set the Start Display Scan after Power ON parameter to ON. • The display scan period is set in the Display Scan Period parameter. If the period is set to 0, the display scan is disabled.
Page 321: Communications Setting Level
Section 8 Parameters 8.16 Communications Setting Level ( This level contains Initial setting parameters for communications, such as parameters for the protocol selection, communications unit number, and communications speed. ● Level Changes at Startup Up To Communications Setting Level Power ON...
Page 322: Communications Setting Level (L.5)
CompoWay/F mod: Modbus Setting u-no Communications Unit No. • After changing the communications unit number setting, execute a software reset or turn the power OFF and ON to make the change Function effective. Setting range Unit Default value 0 to 99...
Page 323 Section 8 Parameters Communications Data Length Protocol is CompoWay/F • After changing the communications data length setting, execute a software reset or turn the power OFF and ON to make the change Function effective. Setting range Unit Default value 7 to 8...
Page 324 8.16 Communications Setting Level (l.5) sdwt Transmission Wait Time • After changing the transmission wait time setting, execute a software reset or turn the power OFF and ON to make the change effective. Function Setting range Unit Default value 0 to 99...
Page 325 Section 8 Parameters l.adf 8.17 Advanced Function Setting Level ( This level includes parameters for parameter initialization, PF Key assignments, and the number of enabled channels. ● Level Changes at Startup Up To Advanced Function Setting Level Power ON Power ON...
Page 326: Advanced Function Setting Level (L.adf)
Operation l.adf PF1 Setting PF2 Setting • These parameters are used to assign functions to the PF1 and PF2 Keys to enable them to be used as function keys. Function Set value Description Function...
Page 327 Section 8 Parameters • Hold down the PF1 or PF2 Key for at least 1 second to execute the function selected in the PF1 Setting or PF2 Setting parameter. If “Program Selection,” “Monitor/Setting Item,” or “ Key” is selected, the display will scroll through monitor/setting items 1 to 5 each time you press the key.
Page 328 Function key must be set according to the following table. • Each time a PF Key is pressed, the display scrolls to the next monitor/setting item in order from the item set for the Monitor/Setting Item 1 parameter to the item set for the Monitor Setting Item 5 parameter.
Page 329 Number of Enabled Channels Controller with more than one input • This parameter is used to set the number of enabled channels when using multiple channels on a Controller with more than one input. Function Setting range Unit...
Page 330 8.17 Advanced Function Setting Level (l.adf) l.adf cmov Move to Calibration Level This parameter is used to move to Calibration Level. • Use this parameter to enter the password to access Calibration Level. Function Setting range Unit Default value 1999 to 9999 Setting ●...
Page 331: Expansion Control Setting Level (L.exc)
8.18 Expansion Control Setting Level ( This level includes parameters for advanced control settings, such as operation after turning ON power, PID set automatic selection settings, and position-proportional settings. ● Level Changes at Startup Up To Expansion Control Setting Level...
Page 332 • Select “Continue,” “Reset,” “Manual Mode,” “Run Status,” or “Ramp Back” for operation after the power is turned ON. Function • Operation after a software reset or when moving from the Initial Setting Level to the Operation Level is also determined by this parameter.
Page 333 The difference (deviation) between the PV and SP are constantly compared during program operation. If the deviation is not within the wait band the SP is held at the point that the deviation went outside the wait band and the program does not move on. The program moves on as soon as the deviation enters the wait band.
Page 334 Program End ON Time • This function is used to set the pulse width for program end output. • The setting range is ON, 0.0 to 10.0 s. The default is 0.0. Function • When this parameter is set to ON, the ON status continues during a reset until operation starts.
Page 335 Program SP Mode or Remote SP Mode to Fixed SP Mode. Function • When remote SP tracking is enabled (ON), the value of the program SP or remote SP is inherited as the fixed SP. • When remote SP tracking is disabled (OFF), the fixed SP is not affected by the program SP or by the remote SP.
Page 336 Position-proportional Control Model • This parameter is used on a Position-proportional Control Model so that PV = SP when the PV is within the PV dead band. Function • This function prevents unnecessary output when the PV is near the...
Page 337 Setting l.exc pvtr PV Tracking • This parameter is used so have the fixed SP track the PV when in Manual Mode. Function • The setting prevents abrupt changes in the MV when switching from Manual Mode to Auto Mode.
Page 338 These parameters are used to specify how the MV is output when switching from Auto Mode to Manual Mode. • When “Hold MV” is selected, the MV at the time of switching is held, after which it can be changed using the Manual MV parameter (Operation Level).
Page 339 Section 8 Parameters l.exc orlm MV Change Rate Limit Mode • Use this parameter to select Mode 0 or Mode 1 for the MV change rate limit. Function • When Mode 1 is selected, the MV change of rate limit functions only with respect to increases in the MV.
Page 340 Bumpless at RUN Operation at Reset parameter set to “Stop Control” • When the Bumpless at RUN parameter is enabled, an integral MV correction (bumpless) is performed to prevent abrupt changes in the Function MV when switching from reset to run.
Page 341 Operation at Potentiometer Input Error Position-proportional Control Model Closed control • This parameter is used to select whether control is stopped or changed to floating control when a potentiometer error occurs during Function closed position-proportional control. Setting range...
Page 342 Section 9 User Calibration Parameters for User Calibration ........9-2 User Calibration ..............9-4 Thermocouple Input Calibration ........9-5 Analog Input Calibration ............ 9-8 Resistance Thermometer Calibration ......9-10 Output Calibration............9-12 Inspecting Indicator Accuracy.......... 9-14...
Page 343: Parameters For User Calibration
• Calibration is ended by turning OFF the power. • The parameters for input calibration are shown below. (The last digit of Display No. 1 shows the input number. The example below shows 1 for input 1. For input 2, the display would show p390.2.) (Aging Timer) Input Type (See note.)
Page 344 9.1 Parameters for User Calibration If user calibration was performed on any of inputs 1 to 4 or outputs 1 to 6 following purchase of the Controller, user calibration information will be displayed as shown below when you move to Calibration Level.
Page 345: User Calibration
Section 9 User Calibration 9.2 User Calibration The E5AR-T/ER-T is calibrated before shipment from the factory and thus there is normally no need for the user to perform calibration. If user calibration is necessary, use the calibration functions for temperature inputs, analog inputs, and outputs that are provided in the Controller.
Page 346: Thermocouple Input Calibration
• Thermocouples are calibrated in two groups according to thermocouple type: Group 1 (input types 2, 4, 7, 8, 10, 14) and Group 2 (input types 3, 5, 6, 9, 11, 12, 13). • Do not obstruct the bottom of the Controller during calibration. Also, do not touch the input terminals or compensating leads.
Page 347 5. Press the M Key. The display at the left will appear. Input types 2, 4, 7, 8, 10, 14 The count value that was input will be displayed on Display No. 2 in 1t53.1 hexadecimal. Set the STV as follows: d72b3 •...
Page 348 9. Wait until the count on Display No. 2 is sufficiently stable and then press the D Key. This tentatively registers the calibration data at this point. 10. Press the M Key. The display at the left will appear. This display will not str.i1 appear if all of the required data has not been tentatively registered.
Page 349: Analog Input Calibration
E5AR-T/ER-T Input power supply 1. Connect the power supply. 2. Connect the STV and DMM to the input terminals of the analog input as shown above. Different input terminals are used for current input and voltage input. Make sure the connections are correct.
Page 350 8. Wait until the count on Display No. 2 is sufficiently stable and then press the D Key. This tentatively registers the calibration data at this point. 9. Press the M Key. The display at the left will appear. This display will not str.i1 appear if all of the required data has not been tentatively registered.
Page 351: Resistance Thermometer Calibration
5. Press the Key M to display the count value for each input type. Input type 0 At this time, the count value that was input will be displayed on Display No. p390.1 2 in hexadecimal. Set the 6-dial resistance box as follows: 86228 •...
Page 352 8. Wait until the count on Display No. 2 is sufficiently stable and then press the D Key. This tentatively registers the calibration data at this point. 9. Press the M Key. The display at the left will appear. This display will not str.i1 appear if all of the required data has not been tentatively registered.
Page 353: Output Calibration
6. While viewing the output on the DMM, use the U and D Keys to set the oa 4.1 output to 4 mA. In the example at left, 4 mA is displayed at a value 2 digits smaller than before calibration.
Page 354 9.6 Output Calibration • If there is another output, connect the output as explained in step 2, and repeat steps 3 to 7. 8. Turn OFF the power to quit Calibration Mode. 9-13...
Page 355: Inspecting Indicator Accuracy
• After calibrating an input, always inspect the indicator accuracy to verify that the input was calibrated correctly. • Operate the E5AR-T/ER-T in the PV/SP state. • Check the indicator at three points: the upper limit, lower limit, and mid-range limit of the indicator range. ■ Thermocouples ● Preparations Connect the required devices as shown below.
Page 356: Analog Inputs
9.7 Inspecting Indicator Accuracy ■ Analog Inputs ● Preparations Connect the required devices as shown below. E5AR-T/ER-T Input power supply ● Operation Set the STV output to the inspection value voltage or current. E5AR-T/ER-T Input power supply 9-15...
Page 357 Section 9 User Calibration 9-16...
Page 358: Section 10 Troubleshooting
10.2 Error Messages ............... 10-3 10.3 Inferring Causes from Conditions: Abnormal Measured Values ..........10-4 10.4 Inferring Causes from Conditions: Abnormal Control ..10-6 10.5 Inferring Causes from Conditions: Abnormal Outputs ..10-9 10.6 Inferring Causes from Conditions: Communications Problems..........10-10 10.7 Inferring Causes from Conditions: Reset Operation ..
Page 359: Troubleshooting Checklist
Section 10 Troubleshooting 10.1 Troubleshooting Checklist If you encounter difficulty with the Controller, use the following checklist to troubleshoot the problem. Check the operating state of the E5AR-T/ER-T as indicated by the display. Check the display Error messages and indicators are described in 10.2 Error Messages (P.
Page 360: Error Messages
10.2 Error Messages 10.2 Error Messages When an error occurs, Displays No. 1 and 2 show error messages. Refer to the following table to check the meaning of the message and troubleshoot the problem. Output state at error Display Display...
Page 361: Inferring Causes From Conditions: Abnormal Measured Values
Section 10 Troubleshooting 10.3 Inferring Causes from Conditions: Abnormal Measured Values ■ The Measured Value Is Abnormal or Measurement Is Not Possible Possible cause Solution The polarity or connections to the temperature Connect the wires correctly. sensor are not correct.
Page 362 Thermocouple: 1) Short-circuit the input terminals of the temperature sensor. 2) If the temperature close to the terminal plate is measured, the E5AR-T/ER-T is operating normally. Analog Input: Use a reference voltage/current generator (e.g., an STV) to supply the specified current or voltage and check the measurement.
Page 363: Inferring Causes From Conditions: Abnormal Control
The heater has a broken wire or has deteriorated. Replace the heater. The heater has a low heat capacity. • Change to a heater with a high heat capacity. • If using two or more heaters, replace any heaters that have broken wires.
Page 364: Overshooting Or Undershooting Occurs
The overlap band is mistakenly set as a dead band Set an overlap band. in heating/cooling control. ■ Hunting Occurs Check connections and settings as explained above in Overshooting or Undershooting Occurs. Possible cause Solution The heat capacity of the heater is too large for the Use a heater with a heat capacity suitable for the heat capacity of the controlled object.
Page 365: Sp Does Not Change As Programmed
Set the Wait Mode, Wait Band Upper Limit, and Wait Band Lower Limit correctly. The SP is being held. Check the HOLD indicator. If it is lit, change the Hold parameter to “OFF.” ■ The Program Is Reset in the Middle...
Page 366: Inferring Causes From Conditions: Abnormal Outputs
The connected load exceeds the output • Do not exceed the specifications. • Repair in the event of a failure. specifications. A load power supply is not connected to a transistor Use a power supply suitable for the output output. specifications and load.
Page 367: Inferring Causes From Conditions: Communications Problems
ON. Unstable signals that occur when the E5AR-T/ER-T Initialize the host system reception buffer at the is turned ON or OFF are read as host system data. following times: • Before sending the first command.
Page 368: Inferring Causes From Conditions: Reset Operation
10.7 Inferring Causes from Conditions: Reset Operation 10.7 Inferring Causes from Conditions: Reset Operation ■ Outputs Are Made While Resetting (Operation Will Not Stop) Possible cause Solution The MV at Reset parameter (Adjustment Level) is Set the MV at Reset parameter to 0.0.
Page 369 Section 10 Troubleshooting 10-12...
Page 370: Appendix
Appendix Specifications................A-2 Sensor Input Setting Ranges and Display/Control Ranges ..A-4 ASCII Table ..................A-5 Setting Lists .................A-6 Parameter Charts...............A-48...
Page 371: Specifications
25 to 65°C (no condensation or icing) Note 1. 100 to 240 VAC and 24 VAC/VDC are on different models. Please specify the desired model when ordering. 2. Multi-inputs. Switch between temperature and analog input using the input type switch.
Page 372: Controller Performance Specifications
3. Ambient temperature: 10 C to 23 C to 55 C Voltage range: 15% to +10% of rated voltage 4. EU stands for Engineering Unit and is the unit after scaling. For a temperature sensor, it is C or F.
Page 373: Sensor Input Setting Ranges And Display/Control Ranges
0 to 10 V 199.99 to 999.99 19.999 to 99.999 1.9999 to 9.9999 • Applicable input type standards are as follows: K, J, T, E, N, R, S, B:JIS C1602-1995 Fe-CuNi, DIN 43710-1985 Cu-CuNi, DIN 43710-1985 W5Re/W26Re, ASTM E988-1990 Pt100:...
Page 374: Ascii Table
ASCII Table ASCII Table Upper Lower SPACE ‘‘ & ‘ < ¥ >...
Page 375: Setting Lists
Monitor and set values can be specified for each channel. Addresses include a channel identifier. The addresses in the variable area maps are for channel 1. To specify addresses of other channels on a Controller with more than one input channel, refer to the table below.
Page 376 Setting Lists...
Page 377: E5@R-T Status (Communications
Appendix ■ E5@R-T Status (Communications) Output Error Not used Bit: Status 0 (OFF) 1 (ON) Not used Not used Not used RSP input error No error Error Potentiometer error No error Error No error Error Display range exceeded Input error...
Page 378 • Control output (heating) type, control output (cooling) type: Updated 2. If the FSP Mode is set to “ON,” the SP Mode parameter setting (RSP/RSP) is ignored. If the FSP Mode is set to “OFF,” the SP Mode parameter setting (RSP/RSP) is valid and the Program SP Mode and Remote SP Mode can be used as required.
Page 379: E5@R-T Program Status (Communications
Appendix ■ E5@R-T Program Status (Communications) Output Bit: 0 (OFF) 1 (ON) Status Segment Output 1/Time Signal 1 Segment Output 2/Time Signal 2 Segment Output 3/Time Signal 3 Segment Output 4/Time Signal 4 Segment Output 5/Time Signal 5 Segment Output 6/Time Signal 6...
Page 380 • Standby: Clear 2. Segment Outputs 1 to 10 and Time Signals 1 to 6 status depend on the setting of the Program Output Selection parameter. 3. The Program End Output status will be ON when the display shows p.end.
Page 381 Appendix A-12...
Page 382 Setting Lists A-13...
Page 383 Appendix A-14...
Page 384 Setting Lists A-15...
Page 385 Appendix A-16...
Page 386 Setting Lists A-17...
Page 387 Appendix A-18...
Page 388 Setting Lists A-19...
Page 389 Appendix A-20...
Page 390 Setting Lists A-21...
Page 391 Appendix A-22...
Page 392 Setting Lists A-23...
Page 393 Appendix A-24...
Page 394 Setting Lists A-25...
Page 395 Appendix A-26...
Page 396 Setting Lists A-27...
Page 397 Appendix A-28...
Page 398 Setting Lists A-29...
Page 399 Appendix A-30...
Page 400 Setting Lists A-31...
Page 401 Appendix A-32...
Page 402 Setting Lists A-33...
Page 403 Appendix A-34...
Page 404 Setting Lists A-35...
Page 405 Appendix A-36...
Page 406 Setting Lists A-37...
Page 407 Appendix A-38...
Page 408 Setting Lists A-39...
Page 409 Appendix A-40...
Page 410 Setting Lists A-41...
Page 411 Appendix A-42...
Page 412 Setting Lists A-43...
Page 413: Initialization Due To Changing Parameter Settings
Appendix ■ Initialization Due to Changing Parameter Settings Parameters that are initialized when the settings of related parameters are changed are listed in the Related parameter column. − : Not initialized, ∆ : Added channels initialized Meaning of Symbols: O: Initialized,...
Page 414 Coordinated Operation Number of Enabled Channels Control Mode (*1) SP Upper Limit SP Lower Limit Scaling Display Value 1 Scaling Display Value 2 Scaling Input Value 1 Scaling Input Value 2 Temperature Unit 1 Temperature Unit 2 Temperature Unit 3...
Page 415 Input Type parameter ( on the previous page). *2: This is the upper and lower limit of the sensor setting range. For a temperature input, this is 4 to 20 mA.
Page 416 Setting Lists A-47...
Page 417 *1 Position-proportional Control Model: Closed/Hold/Open ( 1/0/1) OFF/ON C-O: MV Monitor (Cooling) V-M: Valve Opening Monitor *1: 0 to 4 for channels 2 to 4 for coordinated operation or secondary side for cascade control. R-R: Run/Reset RUN/RST A-M: Auto/Manual AUTO/MANU...
Page 418: Time Signal Setting Level
1/2/4/8/16/32 0 to Number of Segments 19999 to 99999 SI2.2: Straight-line si2.2 Approximation 2 Input 2 MAVP.3: Move Average 3 TON1.6: Time Signal 6 ON Time 1 maVp.3 4.AL1H: Alarm Set 4 1.000 ton1.6 tof1.1 1.999 to 9.999 Move Average Count 1.al1l...
Page 419 0 to 81 0 to 19 mult Independent Operation: MULT/ EV.10: Event Input LAG.4: First Order Lag lag.4 0 to 20 mA (0)/4 to 20 mA (1) eV.10 Coordinated Operation: SNGL Operation 4 Enabled 10 Assignment CO2-T: Linear Current 0 to 81...
Page 420: Parameter Charts
Parameter Charts For Input Initial Setting Level, refer to page A-50. Control starts L key 1 second or more L less than L less than L less than 1 second 1 second 1 second Alarm Setting Display Adjustment Communications Level...
Page 421 Appendix A-52...
Page 422 6-33 CompoWay/F communications 4-50 changing channels 7-32 Modbus communications channel indicator 8-38 Alarm Set * Alarm Lower Limits 5-26 close in alarm/open in alarm 8-38 Alarm Set * Alarm Upper Limits 4-18 closed control 8-37 Alarm Set * Alarm Values...
Page 423 Expansion Control Setting Level 1-11 4-21 8-71 Control/Transfer Output Assignments Extraction of Square Root * Enabled 8-35 Extraction of Square Root * Low-cut Point control/transfer outputs extraction of square root operations 2-11 terminals Controller Attribute Read 6-36 CompoWay/F communications...
Page 424 4-18 6-32 motor calibration CompoWay/F communications 10-3 7-31 motor calibration error Modbus communications 8-34 Move Average * Move Average Count parameters 8-54 Move to Advanced Function Setting Level saving 8-93 Move to Calibration Level part names and functions 5-24 Move to Protect Level...
Page 425 RST operation indicator 8-15 precautions Run/Reset 4-52 6-26 operating precautions CompoWay/F communications 7-25 wiring Modbus communications Present Value (PV)/Present Set Point Run/Reset Key procedures using two-point correction A-39 program data Save RAM Data 8-17 8-44 Program Editing 6-30 CompoWay/F communications...
Page 426 Write via communication 5-25 8-78 Standby Sequence Reset writing 8-28 Standby Time set values 8-83 6-21 Start Display Scan after Power ON CompoWay/F communications 7-23 status Modbus communications communications writing in Protect Level 8-60 Step Time/Rate of Rise Programming set values...
Page 428 Regional Headquarters OMRON EUROPE B.V. Wegalaan 67-69, NL-2132 JD Hoofddorp The Netherlands Tel: (31)2356-81-300/Fax: (31)2356-81-388 OMRON ELECTRONICS LLC 1 East Commerce Drive, Schaumburg, IL 60173 U.S.A. Tel: (1)847-843-7900/Fax: (1)847-843-8568 OMRON ASIA PACIFIC PTE. LTD. 83 Clemenceau Avenue, #11-01, UE Square,...
