Step 4. Turn on the inverter.
Step 5. Be sure to select battery type as "PYL" in LCD program 5.
If communication between the inverter and battery is successful, the battery icon
flash. Generally speaking, it will take longer than 1 minute to establish communication.
Active Function
This function is to activate lithium battery automatically while commissioning. After battery wiring and
commissioning is successfully, if battery is not detected, the inverter will automatically activate battery if the
inverter is powered on.
4. LCD Display Information
Press " " or " " button to switch LCD display information. It will show battery pack and battery group
number before "Main CPU version checking" as shown below.
Selectable information
Battery pack numbers & Battery
group numbers
LCD display
Battery pack numbers = 3, battery group numbers = 1
60
on LCD display will
