One inverter in each phase:
Power Connection
P1
N
L1
L2
L3
N
L1
L2
L3
Communication Connection
1
WARNING: Do not connect the current sharing cable between the inverters which are in different phases.
Otherwise, it may damage the inverters.
5. PV Connection
Please refer to user manual of single unit for PV Connection.
CAUTION: Each inverter should connect to PV modules separately.
P2
P3
2
3
51
