- Page 1 User Manual 3KVA INVERTER / CHARGER Version: 1.0...
-
Page 2: Table Of Contents
Table Of Contents ABOUT THIS MANUAL ............................. 1 Purpose ................................1 Scope ................................1 SAFETY INSTRUCTIONS ..........................1 INTRODUCTION ............................... 2 Features ................................2 Basic System Architecture ..........................2 Product Overview ............................. 3 INSTALLATION ..............................4 Unpacking and Inspection..........................4 Installation ................................ -
Page 3: About This Manual
ABOUT THIS MANUAL Purpose This manual describes the assembly, installation, operation and troubleshooting of this unit. Please read this manual carefully before installations and operations. Keep this manual for future reference. Scope This manual provides safety and installation guidelines as well as information on tools and wiring. SAFETY INSTRUCTIONS WARNING: This chapter contains important safety and operating instructions. -
Page 4: Introduction
INTRODUCTION This is a multi-function inverter/charger, combining functions of inverter, AVR, solar charger and battery charger to offer uninterruptible power for office and home appliances. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications. -
Page 5: Product Overview
Product Overview 1. Operation panel 2. Output sockets 3. USB charger ports 4. AC input 5. PV input 6. Battery connectors 7. Circuit breaker 8. USB and RS232 communication ports... -
Page 6: Installation
INSTALLATION Unpacking and Inspection Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the following items inside of package: The unit x 1 User manual x 1 Software CD x 1 ... -
Page 7: Battery Connection
Battery Connection CAUTION: For safety operation and regulation compliance, it’s requested to install a separate DC over-current protector or disconnect device between battery and inverter. It may not be requested to have a disconnect device in some applications. However, it’s still requested to have over-current protection (typical 120A) installed. - Page 8 Suggested cable requirement for AC wires Model Gauge Torque Value 3KVA 10 AWG 1.2~ 1.6 Nm Please follow below steps to implement AC input/output connection: 1. Before making AC input/output connection, be sure to open DC protector or disconnect first.
-
Page 9: Pv Connection
To reduce risk of injury, please use the proper recommended cable size as below. Model Typical Amperage Cable Size Torque 3KVA 12 AWG 1.4~1.6 Nm PV Module Selection: When selecting proper PV modules, please be sure to consider below parameters: 1. -
Page 10: Communication Connection
Insert striped cable into male terminal and crimp male terminal as shown below. Insert assembled cable into male connector housing as shown below. Then, use spanner to screw pressure dome tightly to female connector and male connector as shown below. 4. -
Page 11: Operation
OPERATION Power ON/OFF Once the unit has been properly installed and the batteries are connected well, simply press On/Off switch to turn on the unit. Operation and Display Panel The operation and display panel, shown in below chart, is on the front panel of the inverter. It includes three LED indicators, three function keys and a LCD display, indicating the operating status and input/output power information. -
Page 12: Lcd Display Icons
LCD Display Icons Icon Function description Input Source Information Indicates the AC input. Indicates the PV input Indicate input voltage, input frequency, PV voltage, charger current (if PV in charging for 3K models), charger power, battery voltage. Configuration Program and Fault Information Indicates the setting programs. - Page 13 In battery mode, it will present battery capacity. Load Percentage Battery Voltage LCD Display < 1.85V/cell 1.85V/cell ~ 1.933V/cell Load >50% 1.933V/cell ~ 2.017V/cell > 2.017V/cell < 1.892V/cell 1.892V/cell ~ 1.975V/cell Load < 50% 1.975V/cell ~ 2.058V/cell > 2.058V/cell Load Information Indicates overload.
-
Page 14: Lcd Setting
LCD Setting After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “SCROLL” button to select setting programs. And then, press “ENTER” button to confirm the selection or ESC button to exit. Setting Programs: Program Description Selectable option... - Page 15 If selected, the transfer time is within 10ms between battery mode and line mode AGM (default) Flooded Battery type User-Defined If “User-Defined” is selected, battery charge voltage and low DC cut-off voltage can be set up in program 26, 27 and 29. Restart disable Restart enable (default)
- Page 16 25.5V 26.5V 27V (default) 27.5V 28.5V If this inverter/charger is working in Line, Standby or Fault mode, charger source can be programmed as below: Solar first Solar energy will charge battery as first priority. Utility will charge battery only when solar energy is not available.
- Page 17 3KVA default setting: 29.2V Battery equalization voltage Setting range is from 25.0V to 30V for 3KVA model. Increment of each click is 0.1V. 60min (default) Setting range is from 5min to 900min.
-
Page 18: Display Setting
30days (default) Setting range is from 0 to 90 days. Increment of each click is 1 day Equalization interval Enable Disable (default) If equalization function is enabled in program 30, this program can be set up. If “Enable” is selected in this program, it’s to Equalization activated activate battery equalization immediately and LCD main page immediately... - Page 19 batt voltage 25.5V, Load percent=70% Battery voltage/Load percentage When connected load is lower than 1kVA, load in VA will present xxxVA like below chart. Battery voltage/Load in VA When load is larger than 1kVA (≧1KVA), load in VA will present x.xkVA like below chart. When load is lower than 1kW, load in W will present xxxW like below chart.
-
Page 20: Operating Mode Description
Main CPU version U1.01.01 Main CPU version checking Secondary CPU version U2.01.01 Secondary CPU version checking Operating Mode Description Operation mode Description LCD display Charging by utility. Charging by PV energy. Standby mode Note: No output is supplied by the *Standby mode: The inverter is unit but it still can charge not turned on yet but at this... - Page 21 Charging by utility and PV energy. Charging by utility. The unit will provide output power from the mains. It will Line Mode also charge the battery at line mode. If “solar first” is selected as output source priority and solar energy is not sufficient to provide the load, solar energy and the utility will provide the loads and charge the battery at the same time.
-
Page 22: Fault Reference Code
Fault Reference Code Fault Code Fault Event Icon on Fan is locked when inverter is off. Over temperature Battery voltage is too high Output short circuited or over temperature is detected by internal converter components. Output voltage is abnormal. Overload time out Bus voltage is too high Bus soft start failed Warning Indicator... -
Page 23: Battery Equalization Description
Battery Equalization Description Equalization function is added into charge controller. It reverses the buildup of negative chemical effects like stratification, a condition where acid concentration is greater at the bottom of the battery than at the top. Equalization also helps to remove sulfate crystals that might have built up on the plates. If left unchecked, this condition, called sulfation, will reduce the overall capacity of the battery. - Page 24 However, in Equalize stage, when battery equalized time is expired and battery voltage doesn’t rise to battery equalization voltage point, the charge controller will extend the battery equalized time until battery voltage achieves battery equalization voltage. If battery voltage is still lower than battery equalization voltage when battery equalized timeout setting is over, the charge controller will stop equalization and return to float stage.
-
Page 25: Specifications
SPECIFICATIONS Table 1 Line Mode Specifications INVERTER MODEL 3KVA Input Voltage Waveform Sinusoidal (utility or generator) Nominal Input Voltage 120Vac 95Vac± 3% (UPS) Low Loss Voltage 85Vac± 3% (Appliances) 100Vac± 3% (UPS); Low Loss Return Voltage 90Vac± 3% (Appliances) Boost activation voltage 108Vac±... - Page 26 Table 2 Inverter Mode Specifications INVERTER MODEL 3KVA Rated Output Power 3KVA/2.7KW Pure Sine Wave Output Voltage Waveform 120Vac± 5% Output Voltage Regulation 60Hz or 50Hz Output Frequency Peak Efficiency Overload Protection 5s@≥150% load; 10s@110%~150% load 2* rated power for 5 seconds...
- Page 27 Table 3 Charge Mode Specifications Utility Charging Mode INVERTER MODEL 3KVA Charging Current (UPS) @ Nominal Input Voltage Flooded Battery 29.2 Bulk Charging Voltage AGM / Gel Battery 28.2 Floating Charging Voltage 27Vdc Charging Algorithm 3-Step 2.43Vdc (2.35Vdc) 2.25Vdc Charging Curve...
-
Page 28: Trouble Shooting
TROUBLE SHOOTING Problem LCD/LED/Buzzer Explanation / Possible cause What to do Unit shuts down LCD/LEDs and buzzer automatically will be active for 3 The battery voltage is too low 1. Re-charge battery. during startup seconds and then (<1.91V/Cell) 2. Replace battery. process. -
Page 29: Appendix I: Approximate Back-Up Time Table
Load (VA) Backup Time @ 24Vdc 100Ah (min) Backup Time @ 24Vdc 200Ah (min) 1100 1200 1500 3KVA 1800 2100 2400 2700 3000 Note: Backup time depends on the quality of the battery, age of battery and type of battery.
