Software Configurator - CD Automation REVEX PA User Manual

REVEX
PA from 35A to 90A
2

Software Configurator

Software Configurator download link:
https:/ /www.cdautomation.com/wp-content/uploads/ThyristorConfigurator_ver6.zip
To connect the unit at the PC, it's necessary to use the micro USB
2.0 Modbus RTU cable.
USB connection need a driver to work properly, you can find it
from our site.
However the configuration software installer will install as default
the correct driver.
Micro USB
Thyristor configurator software is free and is
possible download it from our site.
If the Order Code is in line with requirement,
then unit has been already configured in
Factory and it's ready to use.
You need the software only to modify the
ordered configuration. Anyway we suggest
to check the unit on the machine with the
"Test unit" section.
For install the software, launch the program
and follow the instructions on the screen.
Run the software configurator and set the
correct serial port number by menu setting-
serial com – port number.
