9.4.2 Setup Menu
This section describes each item on the setup menu. Use this menu to configure the power controller for the
load. The password to access this menu is 2.
Parameter Name
Set the percentage by which the set point is
Out Scale
scaled. For example, if a 0 to 10V analog input
providing the set point is 5V and output scaling is
80% then the effective set point is 40%
100
80
60
40
20
0
0 20 40
Parameter Name
Set the maximum percent of the
I Limit SP
nominal current that the power control
allows. This parameter indicates RMS
current by default.
When parameter 52 is set to 1, this
parameter indicates peak current
Nom Line V
Set the nominal value for the line
voltage input
Nominal I
Set the nominal load current
Set the duration of the soft start in
Soft Start
increment of 100mSec. The power
controller ramps set to point changes
over the time set here. For more
information see "Firing type" page:
Soft Start with Burst Firing and Soft
Start with Phase Angle
SP select
Choose the source for the remote set
point
Description
60 80 100
Input
Description
Option Value
Analog In 1
Analog In 2
Default
100%
220V
Maximum
current
100
(10 sec)
0
0
1
30
