Dimensions of Connectable Devices
DCN1-1C T-branch Tap (Single Branch)
Mounting holes or taps
DCN1-2C and DCN1-2R T-branch Taps (Single Branches)
Mounting holes or taps
DCN1-1
T-PORT TAP
90
97
Two, 3.5 dia. or M3
97±0.3
DCN1-2
T-PORT TAP
90
97
Two, 3.5 dia. or M3
97±0.3
7
All dimensions are in mm.
7
All dimensions are in mm.
