Omron DEVICENET Operation Manual page 154

Current Consumption of DeviceNet Devices
Model
DRT2-ID16SLH
DRT2-ID16SLH-1
DRT2-OD16SLH
DRT2-OD16SLH-1
DRT2-ID32SL
DRT2-ID32SL-1
DRT2-OD32SL
DRT2-OD32SL-1
DRT2-MD32SL
DRT2-MD32SL-1
DRT2-ID32SLH
DRT2-ID32SLH-1
DRT2-OD32SLH
DRT2-OD32SLH-1
DRT2-MD32SLH
DRT2-MD32SLH-1
Note The communications current consumption indicated for Expansion Units is the additional current con-
sumed when the Expansion Unit is connected to a Basic Unit.
For example, the current consumption for a combination of a DRT2-ID16 Basic Unit and an XWT-OD16
Expansion Unit is 60 + 10 = 70 mA.
DRT1-series General-purpose Slaves
Model
DRT1-ID08 50 mA max.
DRT1-ID08-1 50 mA max.
DRT1-ID16 50 mA max.
DRT1-ID16-1 50 mA max.
DRT1-OD08 50 mA max.
DRT1-OD08-1 50 mA max.
DRT1-OD16 50 mA max.
DRT1-OD16-1 50 mA max.
DRT1-MD16 50 mA max.
DRT1-ID16T 90 mA max.
DRT1-ID16T-1 90 mA max.
DRT1-ID16TA (Shares communications power supply.)
DRT1-ID16TA-1 (Shares communications power supply.)
DRT1-OD16T 90 mA max.
DRT1-OD16T-1 90 mA max.
DRT1-OD16TA (Shares communications power supply.)
DRT1-OD16TA-1 (Shares communications power supply.)
DRT1-MD16T 90 mA max.
DRT1-MD16T-1 90 mA max.
DRT1-MD16TA (Shares communications power supply.)
DRT1-MD16TA-1 (Shares communications power supply.)
DRT1-ID32ML (Shares communications power supply.)
DRT1-ID32ML-1 (Shares communications power supply.)
DRT1-OD32ML (Shares communications power supply.)
DRT1-OD32ML-1 (Shares communications power supply.)
Communications current consumption
33 mA max.
32 mA max.
35 mA max.
35 mA max.
100 mA max.
90 mA max.
80 mA max.
75 mA max.
80 mA max.
80 mA max.
100 mA max.
105 mA max.
80 mA max.
85 mA max.
90 mA max.
90 mA max.
Internal current consumption Communications current consumption
30 mA max.
30 mA max.
30 mA max.
30 mA max.
30 mA max.
30 mA max.
30 mA max.
30 mA max.
25 mA max.
30 mA max.
30 mA max.
50 mA max.
50 mA max.
30 mA max.
30 mA max.
50 mA max.
50 mA max.
30 mA max.
30 mA max.
50 mA max.
50 mA max.
50 mA max.
50 mA max.
90 mA max.
90 mA max.
