Omron DEVICENET Operation Manual page 150

Dimensions of Connectable Devices
Terminating Resistors
DRS1-T Terminal-block Terminating Resistor
DRS2-1 and DRS2-2 Shielded Micro-size (M12) Terminators
2
3
M12
Note The terminating resistance (121 Ω ) is connected across pins 4 and 5.
DRS3-1 Shielded Mini-size Terminator
1
2
3
Note The terminating resistance (121 Ω ) is connected across pins 4 and 5.
DRS1-T
20
40
Mounting holes or taps
Two, 4.2 dia. or M4
30±0.2
44.7
1
14.9 dia.
5
4
Wiring
Pin
1
2
3
4
5
4
5
26 dia.
16
62.5
Wiring
Pin
1
2
3
4
5
20
All dimensions are in mm.
8.5 dia. 13.6 dia.
Name
DRAIN : NC
V+ : NC
V− : NC
CAN H :
121 Ω
All dimensions are in mm.
CAN L :
Name
DRAIN : NC
V+ : NC
V− : NC
CAN H :
121 Ω
All dimensions are in mm.
CAN L :
Appendix B
129
