Revision History - Omron DEVICENET Operation Manual

A manual revision code appears as a suffix to the catalog number on the front cover of the manual.
The following table outlines the changes made to the manual during each revision. Page numbers refer to
the previous version.
Revision code
1 August 1996
2 June 1997
3 December 1997
4 April 1998
5
6 October 2000
07 August 2002

Revision History

Cat. No. W267-E1-11
Date
Original production
Complete revision to include V1 Master Units.
The manual was revised to include new informa-
tion on network configuration and wiring, and
Temperature Input Terminals.
Section 3: Added to include information on net-
work configuration and specifications.
Page 72: Changes to table.
Pages 72 to 84: Additions made to include
DRT1-AD04H.
Pages 91 to 97: Information added on Temper-
ature Input Terminals.
The manual was revised to correct errors and
include new information on multiple I/O termi-
nals.
Page 6: Table added to include information on
MULTIPLE I/O TERMINAL.
Page 34: Information on MULTIPLE I/O TERMI-
NAL added.
Pages 46, 51, 56, 60, 65, 72, 84, 91: Specifica-
tions corrected.
Pages 47, 53, 58, 62, 67, 68, 76: "Insulated"
corrected to "isolated."
Pages 50, 56, 60, 64, 71, 84, 91, 98: Note on
opening the cover removed.
Page 92: Note on converted data removed.
May 2000 Changes were made throughout the manual to
correct errors and include new information on
CS1-series PLCs, Basic and Special I/O Units,
MULTIPLE I/O TERMINAL Units, and Environ-
ment-resistant Terminals. "CompoBus/D" was
changed to "DeviceNet" and "CV-series" was
amended to "CVM1 and CV-series" throughout
the manual.
Pages 2, 7, 8, 22, 32, 37, 40, 185, 193, 208,
211, 212, 216, 220, 224, 227, 234-236, 239-
242, 252-254, 313, 325, 328-335, 340, 345,
355, 356, 365, 371, 377-379: Information on
CS1-series PLCs added.
Pages 3-6: Major changes to model informa-
tion.
Pages 7, 15, 19, 341-347: Notes changed/
added.
Page 13: Correction made to information on
communications cycle time.
Pages 21, 27: Information on reference sources
added/changed.
Pages 23, 228: Information on communications
setup added.
Sections 5-1 to 5-3: Removed.
Sections 5-4-8 to 5-4-12: Removed.
Page 181: Information on dual power supply
changed.
Reprinted due to error.
Completely redone to separate information on Masters into a separate manual, to add round con-
nectors and other connectors, and to add T-branch Taps and other new products.
Revision code
Revised content
Section 6: Added to include information on the
communications power supply.
Section 7: Extensively revised to include infor-
mation on wiring the network.
Page 267: Information changed in table.
Appendix F: Added to provide information on
connectable devices and current consumption.
Section 5-3: Added to include information on
MULTIPLE I/O TERMINAL.
Section 7-12: Added to include information on
installation and connection of MULTIPLE I/O
TERMINAL
Pages 350 to 352: Information on MULTIPLE I/
O TERMINAL response times and communica-
tions cycle times added.
Pages 363 to 368: Error processing information
for MULTIPLE I/O TERMINAL added.
Page 407: Communications Unit device profile
added.
Page 418: Connectable device information
updated to include MULTIPLE I/O TERMINAL.
Page 184: Torque data changed. Information on
mounting added.
Section 7-2-2: Removed.
Pages 187, 219, 226: Changes to graphics.
Pages 190-192: Torque data changed.
Sections 7-11, 7-12: Removed.
Pages 204, 218, 384, 400, 401: Changes made
to tables.
Pages 234, 246, 253, 259, 260: Information on
explicit messages added.
Page 326: Information on error log data added.
Pages 338-339: Changes made to information
on communications cycle time. Information for
networks with more than one Master moved to
page 347.
Pages 346-349: Equations changed/added.
Section 14-1-3: Removed.
Page 382: Information on troubleshooting for
Analog I/O Units, Temperature Input Terminals,
the C200H I/O Link Unit, and the RS-232C Unit
added.
Page 399: Change to introduction. Information
on connection to other company's Masters
removed.
Pages 402-408: Removed.
Appendix E: Removed.
Appendix F: New model information added.
