8.0 Service and Maintenance

8.1 Centrifuge Service

The brushless motor in this microcentrifuge requires no routine maintenance. Any required service should be performed by
authorized, qualified personnel only. Repairs performed by unauthorized personnel may void the warranty.

8.2 Cleaning

Always keep the centrifuge housing, rotor chamber, rotor and rotor accessories clean. All parts should be wiped down periodically
with a soft cloth. For more thorough cleaning, use a neutral cleaning agent (pH between 6 and 8) applied with a soft cloth. Excessive
amounts of liquid should be avoided. Liquid should not come into contact with the motor. After cleaning, ensure that all parts are
dried thoroughly by hand or in a warm air cabinet (maximum temperature 50°C).
The rotor should be cleaned after each use. When spinning samples containing phenol or phenol chloroform, the rotor should be
cleaned immediately after use.
Should a spill of infectious materials occur within the rotor or chamber, the unit should be disinfected. This should be performed by
qualified personnel with proper protective equipment.

8.3 Replacing Fuses

Check the fuse when it is recommended (see Troubleshooting Guide section). Disconnect the power cord from the wall socket before
checking the fuses. The fuse holder is located in the power inlet on the rear of the unit. Open the fuse holder drawer by inserting a
small screwdriver under the tab and prying it open. Remove the innermost (operative) fuse from its retaining tabs, and replace the
fuse if necessary. A spare fuse is located in the outermost chamber of the fuse drawer. Replace only with a fuse of exactly the same
value as the original. See Section 3.0 for information on fuse type.

9.0 Troubleshooting Guide

Problem
Centrifuge will not start
Lid lock will not release
Centrifuge cannot be started,
although power is On
bAL (Error Message) indicates
imbalance
Lid (Error Message) lid not
closed
Other Error Messages Er on
Display
Should you have a question about the operation of the Labnet Prism™ Microcentrifuge or if service is required, contact Corning
Customer Service. Do not send in a unit for service without first calling to obtain a repair authorization number. Should the unit
require return for service, it should be properly packed to avoid damage. Any damage resulting from improper packaging shall be the
responsibility of the user.
6 | LABNET PRISM MICROCENTRIFUGE
Possible Cause
No power supply
Blown fuse
Defective lid lock
No power from the PC board
Lid lock is jammed
Centrifuge is not receiving power
Lid is not closed correctly
No speed or time has been selected
Tubes are not inserted symmetrically
in the rotor holes
Sample liquid in the tubes is not
balanced
Defective or improperly adjusted
balance sensor
Lid is not closed completely
Lid lock or sensor is defective
–
Solution
Check if power is being supplied to the outlet.

Check if the power cord is plugged into both the wall

outlet and the back of the centrifuge.
Check if the power cord is damaged.

Check the fuse and replace if necessary.
Open manually, and have the unit serviced.
Call for service.
Call for service.
See "Centrifuge will not start".
Close the lid correctly.
Set the speed and/or time.
Load the tubes symmetrically (see Section 6.4: Loading the
Rotor).
Make sure the same volume of liquid is in each tube.
Call for service.
Close the lid.
Call for service.
Press the time or speed button to clear the error.

Call for service.

