Elatec TWN4 MultiTech 2 Series User Manual page 12

TWN4 MultiTech 2 M
RFID modules of 1
st
generation
RFID modules of 2 nd
generation
It is strictly prohibited to take the BLE SAM card out of the SAM slot on the module. Removing the BLE SAM card is considered
4
as an unauthorized product modification and improper use of the product, which may result in the loss of product certifications.
ELATEC excludes any liability in case of unauthorized product modification or improper use of the product.
© 2024 – ELATEC GmbH – TWN4 MultiTech 2 family – user manual – DocRev01 – EN – 05/2024
MTBF 500,000 hours
Weight Approx. 10 g / 0.35 oz (without cable)
Frequencies
Dimensions: 28.00 x 28.00 mm / 1.10 x 1.10 inch
Antennas
Dimensions: 42.00 x 44.00 mm / 1.65 x 1.73 inch
Integrated BLE chip
Dimensions
76.00 x 49.00 x 9.00 mm
(L x W x H)
2.99 x 1.93 x 0.35 inch
Power
Current
consumption
Temperature Operating: -25 °C up to +80 °C / -13 °F up to +176 °F
ranges Storage: -40 °C up to +85 °C / -40 °F up to +185 °F
Relative
humidity
LF and HF: up to 100 mm / 4 inch, depending on
R/W distance
MTBF
Weight
RFID modules of
1 generation
st
125 kHz (LF) / 13.56 MHz (HF) / 2.4 GHz (BLE)
Integrated RFID LF antenna
Number of turns: 151
Integrated RFID HF antenna
Number of turns: 3
Bluetooth Low Energy
Approx.
USB: 4.3 V - 5.5 V
Generic interface (X1): 3.3 V ± 5%
RS-232: requires 5 V external power supply
ES1/PS2 classified power source according to
IEC 62368-1, short-circuit current < 8 A
RF field on: 120 mA typically + 16 mA (BLE)
Sleep: 500 μA typ.
5% to 95% non-condensing
environment and transponder
BLE: up to several meters/feet
500,000 hours
Approx. 15 g / 0.53 oz (without cable)
RFID modules of
2 generation
nd
Plug-in BLE SAM card
Approx.
76.00 x 49.00 x 10.00 mm
2.99 x 1.93 x 0.39 inch
