- Page 1 TWN4 MULTITECH LEGIC TWN4 LEGIC NFC USER MANUAL...
-
Page 2: Table Of Contents
SCOPE OF DELIVERY ..............................3 1.2.1 COMPONENTS AND ACCESSORIES ........................ 3 1.2.2 SOFTWARE ................................. 3 ELATEC SUPPORT ................................ 3 REVISION HISTORY ..............................3 INTENDED USE .................................. 4 SAFETY INFORMATION ..............................5 TECHNICAL DATA ................................7 MODE OF OPERATION ..............................8 OPERATING MODE ............................... -
Page 3: Introduction
ELATEC SUPPORT In case of any technical questions, refer to the ELATEC website (www.elatec.com) or contact ELATEC technical support at support-rfid@elatec.com In case of questions regarding your product order, contact your Sales representative or ELATEC customer service at info-rfid@elatec.com... -
Page 4: Intended Use
2 INTENDED USE ELATEC TWN4 family of transponder readers and writers allows users to read and write to almost any 125 kHz and 13.56 MHz tags and/or labels – it supports all major transponders from various suppliers like ATMEL, EM, ST, NXP, TI, HID, LEGIC, etc. and ISO standards like ISO 14443A/B (T=CL), ISO 15693, ISO 18092 / ECMA-340 (NFC). -
Page 5: Safety Information
The user is liable for the use of spare parts or accessories other than the ones sold or recommended by ELATEC. ELATEC excludes any liability for damages or injuries resulting from the use of spare parts or accessories other than the ones sold or recommended by ELATEC. - Page 6 If you are unsure about any part of the safety information above, contact ELATEC support. Any failure to comply with the safety information given in this document is considered improper use. ELATEC excludes any liability in case of improper use or faulty product installation.
-
Page 7: Technical Data
Dimensions: 29 x 32 mm / 1.14 x 1.26 inch Number of turns: 164 For more information, refer to the related product data sheet or other technical documents. © 2022 ELATEC GmbH – TWN4 MultiTech LEGIC user manual DocRev3 – 02/2022 Page 7 of 15... -
Page 8: Mode Of Operation
• Short-circuit current < 8 A Once TWN4 MultiTech LEGIC is connected to the host, it detects the type of communications cable (e.g. USB or RS-232), with which it is connected to the host. In case of RS-232: Additionally, the RS-232 is sending a version string via RS-232 to the host device. -
Page 9: Suspend Mode
Once the host is resuming to normal operation mode, this is also signaled via the USB bus. Therefore, the reader will resume to normal operation too. © 2022 ELATEC GmbH – TWN4 MultiTech LEGIC user manual DocRev3 – 02/2022 Page 9 of 15... -
Page 10: Compliance Statements
6 COMPLIANCE STATEMENTS TWN4 MultiTech LEGIC is in compliance with the EU directives and regulations as listed in the respective declaration of conformity (cf. TWN4 LEGIC NFC EU Declaration of Conformity). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 11: Rf Exposure Compliance
(stations); 准划设的射电天文台、气象雷达站、卫星地球站（含测 控、测距、接收、导航站）等军民用无线电台（站）、 (5) Should the product cause harmful interference on other legal 机场等的电磁环境保护区域内使用微功率设备，应当遵 radio transmitters (stations), product use must be discontinued 守电磁环境保护及相关行业主管部门的规定； © 2022 ELATEC GmbH – TWN4 MultiTech LEGIC user manual DocRev3 – 02/2022 Page 11 of 15... -
Page 12: Morocco
UNITED KINGDOM TWN4 MultiTech LEGIC complies with the requirements of the UK legislations and other regulations as listed in the respective UK declaration of conformity (cf. TWN4 LEGIC NFC UK Declaration of Conformity). The importer is responsible for applying the following information to the packaging of the product: •... -
Page 13: Brazil
(2) Este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada. 6.8.3 TAIWAN (ROC) 注意! 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及 功能。低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時 方得繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及 醫療用電波輻射性電機設備之干擾。 6.8.4 THAILAND © 2022 ELATEC GmbH – TWN4 MultiTech LEGIC user manual DocRev3 – 02/2022 Page 13 of 15... -
Page 14: Appendix
B – RELEVANT DOCUMENTATION ELATEC documentation • ELATEC quick start guide • TWN4 MultiTech LEGIC data sheet • TWN4 MultiTech OEM PCBs handbook © 2022 ELATEC GmbH – TWN4 MultiTech LEGIC user manual DocRev3 – 02/2022 Page 14 of 15... - Page 15 Elatec reserves the right to change any information or data in this document without prior notice. Elatec declines all responsibility for the use of this product with any other specification but the one mentioned above. Any additional requirement for a specific customer application has to be validated by the customer himself at his own responsibility. Where application information is given, it is only advisory and does not form part of the specification.
