- Page 1 TWN4 MULTITECH 3 M INTEGRATION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION .................................. 3 ABOUT THIS MANUAL ..............................3 ABOUT TWN4 MULTITECH 3 M ............................3 ELATEC SUPPORT ................................3 SAFETY INFORMATION ..............................4 INTEGRATION INSTRUCTIONS ............................5 GENERAL ..................................5 LIST OF APPLICABLE RULES ............................5 SPECIFIC OPERATIONAL USE CONDITIONS ......................5 LIMITED MODULE PROCEDURES ..........................5 TRACE ANTENNA DESIGN ............................5... -
Page 3: Introduction
TWN4 MultiTech 3 M key features include a powerful SDK for writing apps that are executed directly on the module, the possibility to upgrade the firmware in the field, a direct chip-commands support, and a powerful BLE module. Additionally, the module can simultaneously read more than 60 RFID technologies from low (LF) and high frequency (HF) bands, including NFC. -
Page 4: Safety Information
ELATEC technical documentation related to the product, as well as the technical documentation related to the host device. In particular, the instructions and safety information given in the user manual of TWN4 MultiTech 3 M should be read carefully and... -
Page 5: Integration Instructions
GENERAL TWN4 MultiTech 3 M may be installed in any host devices, as long as it is operated under the operational conditions stated in the user manual and other technical documents (e.g. data sheet). TWN4 MultiTech 3 M is equipped with 2 integrated antennas. Thus, no antenna installation is required. -
Page 6: Label And Compliance Information
ADDITIONAL TESTING, PART 15 SUBPART B DISCLAIMER TWN4 MultiTech 3 M is only FCC authorized for the specific rule parts (i.e., FCC transmitter rules) listed on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. -
Page 7: Electrical Connection
3.12 ELECTRICAL CONNECTION 3.13 PROGRAMMATION/SOFTWARE INTEGRATION © 2023 ELATEC GmbH – TWN4 MultiTech 3 M integration manual – DocRev01 – EN – 07/2023 Page 5 of 13... -
Page 8: Compliance Statements
4 COMPLIANCE STATEMENTS Hereby, ELATEC GmbH declares that TWN4 MultiTech 3 M is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: elatec.com/approvals RF exposure statement TWN4 MultiTech 3 M complies with EU radiation exposure limits set forth for an uncontrolled environment under the following conditions: The equipment should be installed and operated such that a minimum separation distance of 7.5 cm is maintained between... -
Page 9: Taiwan
UNITED KINGDOM TWN4 MultiTech 3 M complies with the requirements of the UK legislations and other regulations as listed in the respective UK declaration of conformity. The importer is responsible for applying the following information to the packaging of the product: •... -
Page 10: Integrator And Host Requirements
Using a permanently affixed label, TWN4 MultiTech 3 M must be labeled with its own FCC and IC identification numbers. In case this label is not visible anymore after integration of TWN4 MultiTech 3 M in the host device, it is necessary to bring a label on the host... -
Page 11: Appendix
Development Canada (LE-LAN) Devices Title 47 of the Code of Federal FCC’s rules and regulations Federal Communications Commission Regulations (CFR) © 2023 ELATEC GmbH – TWN4 MultiTech 3 M integration manual – DocRev01 – EN – 07/2023 Page 9 of 13... -
Page 12: C - Revision History
For more information about this integration manual or TWN4 MultiTech 3 M, go to www.elatec.com or contact ELATEC. C – REVISION HISTORY CHANGE DESCRIPTION EDITION VERSION First edition 07/2023 (replaces TWN4 MultiTech 3 M BLE integration manual) © 2023 ELATEC GmbH – TWN4 MultiTech 3 M integration manual – DocRev01 – EN – 07/2023... - Page 13 Elatec reserves the right to change any information or data in this document without prior notice. Elatec declines all responsibility for the use of this product with any other specification but the one mentioned above. Any additional requirement for a specific customer application has to be validated by the customer himself at his own responsibility. Where application information is given, it is only advisory and does not form part of the specification.
