Figure 3. Example of how Colors and Notices Provide Configuration Guidance
EXPORT allows you to save a configuration file as a text file.
Configuration Notices are visible on the Now Viewing panel when there are possible configuration errors or potential
conflicts while configuring. They provide details about conditions required to complete configuration changes.

Device Status

The Device Status panel available on the right side of LoopConnect provides the configuration of the DPC2K alerts.
When open, alerts are configured according to the dashboard where the associated parameter is located.

Device Alerts

An alert is a notification that the instrument has detected a condition that has exceeded the alert conditions. Device
Alerts show the specific reason for the alert condition; when multiple alerts are active, they are displayed in priority
order. Active alerts will be displayed with their NE107 status and recommended action.
Note
In the event of multiple NE107 Alerts being active, the highest priority will be indicated as Device Status. Refer to Table 2 for
NE107 priority.
Active alerts are cleared when the instrument is rebooted; however, alerts will be re-triggered if the condition that activated the
alert is not cleared.
NOW VIEWING PANEL
DPC2K Digital Process Controller
April 2024
DEVICE
STATUS
PANEL
13
