- Page 1 DF Series Instruction Manual V2014.4 Tank Blanketing Regulators April 2014 DF Series Tank Blanketing regulators Manual www.emersonprocess.com/regulators...
-
Page 2: Table Of Contents
DF Series Tank Blanketing regulators DF Series Tank Blanketing Regulators Contents 1. Introduction ............3 2. -
Page 3: Introduction
DF Series are self-contained, direct-operated pressure regulators designed for low setpoint pressure control. They use the fluid's pressure to drive the actuator and automatically stabilize the outlet pressure. DF Series have large capacity and fast reponse, they can maintain stable pressure control and achieve tight shutoff which make them ideal choices for industrial tank blanketing systems. -
Page 4: Construction And Principle Of Operation
Process Management Regulator Technologies, Inc. (Regulator Technologies) instructions. If the regulator vents gas or a leak develops in the system, service to the unit may be required. -
Page 5: Selection Of Actuator And Spring
JJJJ43CXT07 7. Flow Curve To ensure the high accuracy, stability and flow capacity of the DF Series, many tests were performed under different inlet pressure and outlet pressures. InITIAL SeTPOInT = 7 kPa / 1.015 psig AT 20,000 SCFH / 536 nm... - Page 6 4 to 6 times of the diameter of the pipe. An external line can be installed to sense the tank pressure directly. (Refer to Figure 3) Figure 3. DF Series Installation Schematics GAuGE SHuTOFF VALVE...
-
Page 7: Startup
1. Run a test on DF Series lock-up pressure at least once every 3 months: Install a gauge near the regulator outlet and turn it on, slowly close the outlet ball valve, record the lock-up pressure value after 5 minutes to check if it is in the normal range. -
Page 8: Troubleshooting
DF Series Tank Blanketing Regulators DF Series Tank Blanketing Regulators Troubleshooting PROBLeM POSSIBLe CAuSeS POSSIBLe CORReCTIVe MeASuReS The inlet pressure is too low. Choose the right regulator. The outlet pressure of the The actual gas flow exceeds the designed capacity of the regulator. - Page 9 DF Series Tank Blanketing Regulators DF Series Tank Blanketing Regulators Figure 5. DF Series Assembly...
- Page 10 DF Series Tank Blanketing Regulators DF Series Tank Blanketing Regulators Figure 5. DF Series Assembly (continued) Parts List (continued) PART nAMe PART nAMe Washer, Spring Washer O-ring Bolt, Hex Nut, Hex (Actuator) Holder Diaphragm Casing, Lower Spring Seat, upper Bushing, Pipe...
-
Page 11: Model Description
We reserve the right to modify or improve the designs or specifications of such products at any time without notice. Emerson Process Management Regulator Technologies, Inc. does not assume responsibility for the selection, use or maintenance of any product. - Page 12 Chennai 600117, India Tel: +91 44 6608 6600 Emerson Process Management Regulator Technologies Inc. All rights reserved. Emerson Process Management and its design are trademark or service logo of Emerson Process Management group. All other logos are their owners' propertities respectively.
