StarTech.com UNISLDSHF192 Instruction Manual

Instruction Manual
2U Vented Adjustable Sliding Rack Shelf with Cable Management
UNISLDSHF19x
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x Shelf Assembly
• 2 x Ear Hook and Slide Assembly (Left / Right)
• 2 x Ear Hook Bracket (Left / Right)
• 1 x Cable Management Assembly
• 1 x Instruction Manual
Product Overview
Ear Hook and Slide
Assembly (Left/Right)
Shelf Assembly
For the most up-to-date information, please visit: www.startech.com
Installation
1. Loosen the screws along the Ear Hook and Slide Assembly and
adjust the rail to the depth of your rack.
2. Install the Ear Hook and Slide Assembly into your rack, tightening
the screws loosened in the previous step, and fasten to the front
of the rack with the Ear Hook Bracket (one per side).
3. Slide the shelf assembly onto the rails.
Note: The bezel position can be adjusted on the shelf as shown in
the diagram
Cable Management
Assembly
Ear Hook Bracket Attach the Cable Management Assembly to the back of the rack as
(Left/Right) shown.
Bezel
Adjustment
Manual Revision: 03/05/2014
