2U Universal Sliding Server Rack Shelf
Product ID
UNISLDSHF19
2
3
1
4
Product Information
For the latest manuals, product information, technical specifications, and declarations of
conformance, please visit:
www.StarTech.com/UNISLDSHF19
Requirements
• Phillips Head Screwdriver
• (Optional) Cage Nut Tool
Package Contents
• Sliding Shelf x 1
• M6 Screws x 8
• M6 Cage Nuts x 8
• Quick-Start Guide x1
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
For additional self-service support options and community forums, please visit: www.StarTech.com/support
1
1
2
3
1
Component
Rail Assembly
1
• Mount the Sliding Shelf to the 4-Post Rack
Mounting Holes
• Used to attach the Sliding Shelf onto the Rear Mounting
2
Rear Brackets x 2
Posts of a Rack
• Used to attach the Sliding Shelf onto the Front
3
Front Brackets x 2
Mounting Posts of a Rack
4
Shelf Surface
• Place Rack Equipment
• Located on both sides of the Sliding Shelf
• Allow to release the locking mechanism to retract or
remove the Sliding Shelf from the Rails
Release Levers x 2
5
(Not Shown)
• The Release Levers operate in opposite directions. One
moves Down and the other Up
• See Figure 2 in Installation
Warnings!
Read the entire Quick-Start Guide and ensure the instructions are fully understood
before assembling and using this product.
Before adding equipment to this product, ensure this product has been properly
mounted.
Do not attempt to operate or install this product if parts are missing or damaged.
Ensure the weight of the equipment does not exceed the weight capacity of this
product. If the weight capacity is exceeded, personal injury or damage to the
equipment is possible. This product can support the following weight: up to 50 lb
(22.7 kg).
All four mounting points must be properly secured to each of the posts on a four-post
rack.
Never exceed the maximum mounting depth specification for this shelf: 29.3in
(744mm).
Quick-Start Guide
Function
Manual Revision: May 3, 2024
