- Page 1 Operating instructions Heating actuator 6-gang with controller Order no. 2139 00 Product image non-binding...
-
Page 2: Table Of Contents
Heating actuator 6-gang with controller Table of Contents Safety instructions ...................... 3 Device components ...................... 4 Function .......................... 5 Operation .......................... 7 As-delivered state ...................... 10 Information for electrically skilled persons .............. 11 Mounting and electrical connection.............. 11 Commissioning .................... 13 6.2.1 Safe-state mode and master reset ............ -
Page 3: Safety Instructions
Heating actuator 6-gang with controller Safety instructions Electrical devices may be mounted and connected only by electrically skilled persons. Serious injuries, fire or property damage are possible. Please read and follow the manual fully. Danger of electric shock. Always disconnect before carrying out work on the device or load. -
Page 4: Device Components
Heating actuator 6-gang with controller Device components Figure 1: Front view Supply of electrothermal valve drives Connection of electrothermal valve drives (A1 to A6) Status LEDs for outputs Button field for manual operation Programming button and LED Bus connection If all of the status LEDs (3) are flashing (2 Hz), the device is indicating that there is no power supply to the electrothermal valve drives (1). -
Page 5: Function
Valve drives controllable with 24 V or 230 V rated voltage. – Manual control of the outputs. – Programming and commissioning with the Gira Project Assistant (GPA), ver- sion 5 or higher. – Updating via the Gira Project Assistant (GPA). - Page 6 Heating actuator 6-gang with controller – Overload: Status LED of the identified output flashes continuously (approx. 2 Hz): Test cycle completed. – Short-circuit: Status LED of the identified output flashes continuously (approx. 1 Hz): Test cycle completed. 82406412 17.05.2024 6 / 17...
-
Page 7: Operation
Heating actuator 6-gang with controller Operation Figure 2: Operating elements Status LEDs for outputs ǃ button – Manual operation LED - On: permanent manual operation mode active Open button – Open valve LED – On: valve opened, manual operation mode Close button – Close valve LED –... - Page 8 Heating actuator 6-gang with controller Switching on temporary manual operation mode Operation is not disabled. ￭ Press the ǃ button briefly. Status LED A1 flashes, LED ǃ flashes. After 5 seconds without button actuation, the actuator returns automatically to bus mode. Switching off temporary manual operation mode The device is in short-term manual mode.
- Page 9 Heating actuator 6-gang with controller The LEDs Open and Close indicate the valve status. Short-term manual mode: After running through all of the outputs the device exits manual mode after another brief actuation. Operating all outputs simultaneously The device is in permanent manual operation mode. ￭...
-
Page 10: As-Delivered State
Heating actuator 6-gang with controller As-delivered state In the as-delivered state, the device enables manual operation on the device itself, provided that the voltage supply to the valve drives and the bus voltage are switched In the as-delivered state, all the valve outputs are configured as follows: –... -
Page 11: Information For Electrically Skilled Persons
Heating actuator 6-gang with controller Information for electrically skilled persons Mounting and electrical connection DANGER! Mortal danger of electric shock. Disconnect the device. Cover up live parts. Mount device – Enter or scan the device certificate and add it to the project. A high resolution camera should be used to scan the QR code. - Page 12 Heating actuator 6-gang with controller Figure 3: Connection for AC 230 V actuators (connection examples) Left: Neutral conductor of the actuators run separately to the actuator Right: Shared neutral conductor for actuators ￭ Connect AC 24 V valve drives according to the connection diagram (see figure 4).
-
Page 13: Commissioning
Heating actuator 6-gang with controller Commissioning The device is commissioned with the Gira Project Assistant (GPA) version 5 or higher. 6.2.1 Safe-state mode and master reset Safe-state mode The safe-state mode stops the execution of the program. Only the system software of the device is still functional. Diagnosis functions and programming of the device are possible. -
Page 14: Technical Data
Heating actuator 6-gang with controller Technical data Rated voltage DC 21 ... 32 V SELV Current consumption 4.5 ... 10 mA Heating outputs Contact type Semi-conductor (Triac), ε Switching voltage AC 24 / 230 V ~ Mains frequency 50 / 60 Hz Switching current 5 ... -
Page 15: Troubleshooting
Heating actuator 6-gang with controller Troubleshooting Valve drives of an output or all outputs do not switch Cause: An output is overloaded. Determine cause of the overload switch-off. Eliminate short-circuits, replace defective valve drives. Check number of valve drives connected to the output, reduce if necessary. -
Page 16: Parameter List
Heating actuator 6-gang with controller Parameter list The following parameters are available for the individual buttons or rockers, depend- ing on the set operating concept. The default settings change in accordance with the set operating concept. Valve in voltage-free state (direction of open action) closed... -
Page 17: Warranty
Please submit or send faulty devices postage paid together with a fault de- scription to your responsible salesperson (specialist trade / installation company / electrical specialist trade). They will forward the devices to the Gira Service Center. Gira Giersiepen GmbH & Co. KG...
