10
10
2
1.
Lay worksurface and end panels upside down on soft surface to protect.
Insert all 10 shoulder screws into the top and end panels (see diagram).
Install the shelf supports at the desired height in the end panels (see
diagram).
2.
Place back panel 1 in place then ends 2 , 3 and then tighten all
camlocks (see diagram). Place adhesive cover over visible hardware.
4
2
Assembly Instructions
Orenda
Bookcase Storage Stack On
4
1
Casegoods
TM
2
3
AKSOB
10
4
1
Align arrow
1
orientation
to insert part
2
Lock
10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for KI Orenda AKSOB
Summary of Contents for KI Orenda AKSOB
- Page 1 Assembly Instructions Orenda Casegoods Bookcase Storage Stack On AKSOB Lay worksurface and end panels upside down on soft surface to protect. Insert all 10 shoulder screws into the top and end panels (see diagram). Install the shelf supports at the desired height in the end panels (see diagram).
- Page 2 Assembly Instructions Orenda Casegoods Stack On Bookcase Storage AKSOB For safety reasons, the adhesive mounting tape supplied must be used when installing the stack on bookcase. This one-time use adhesive mounting tape permanently secures the overhead in position to prevent it from tipping over. Do not remove the tape's protective backing before deciding the stack on bookcase's final position.
