Assembly Instructions
Unite
Panel System
®
Worksurfaces
February 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Unite Panel System and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KI Unite Panel System

Summary of Contents for KI Unite Panel System

  • Page 1 Assembly Instructions Unite Panel System ® Worksurfaces February 2021...

  • Page 2: Table Of Contents

    Unite Panel System - Table of Contents ® Rare Earth Magnets used with this product. The magnets can Assembly Instructions be harmful to pacemaker wearers and others with medical devices. Pacemaker wearers should stay at least one foot away from the steel tiles. Unite Panel System ®...

  • Page 3: Worksurface Bracket & Support Overview

    Worksurface Bracket & Support 1. Locate and identify right- and Overview left-hand cantilever brackets The Unite Panel System offers to be used. A right cantilever several methods to support bracket is used on the right side worksurfaces. The...

  • Page 4: Standard Cantilever Bracket Installation

    Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
  • Page 5 Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
  • Page 6 Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.

  • Page 7: Edge Support Bracket With Lock

    29” from top of surface to floor. ” 24 or 30” ADA height range is 28”-34”. worksurface Example: The typical KI worksurface thickness is 1 ”; therefore the installed Unite cantilever bracket should measure ” from top of bracket to the floor.

  • Page 8: Design Bracket Installation

    28”- 34”. ” only, taking care to not drill too deep which may damage the Example: The typical KI worksurface (Figure 8). worksurface thickness is 1.18”; therefore the installed Unite 7. Install worksurface splice plate to...

  • Page 9: Peninsula Surfaces With Add-On Peninsula Attachment Plate

    Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.

  • Page 10: Change-Of-Height Bracket Overview

    Typical worksurface height is 29” from top of surface to floor. ADA height range is 28”-34”. Example: The typical KI worksurface thickness is 1 ”; therefore the installed Unite design bracket should measure ” from top of bracket to the floor.

  • Page 11: Corner Change-Of-Height Brackets

    Typical worksurface height is 29” from top of surface to floor. ADA height range is 28”- 34”. Example: The typical KI “ adjacent ” worksurface thickness is 1 ”;...
  • Page 12 Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.

  • Page 13: Peninsula & Conference End Worksurfaces

    Peninsula and conference end upside down onto a soft, worksurfaces are installed to protective surface. Determine the Unite Panel System with which end of the worksurface to approved brackets on one end install either a pair of post legs or and utilize either a worksurface a worksurface support leg.
  • Page 14 Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.

  • Page 15: Worksurfaces To Panel-Mounted Support Leg

    Unite Panel System - Worksurface Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly. Failure to assemble properly, or to secure parts may result in assembly failure and personal injury.
  • Page 16 If more leveling height is required, 3 " glides are available by contacting KI Customer Service. 4. With all teeth of the support leg set into the notches of the panel, and all support legs installed,...

  • Page 17: Pedestal-To-Panel With Worksurface Installation

    Pedestal-to-Panel with glide away from the drawer body, Worksurface Installation while pressing up on the bottom The Unite Panel System offers of the drawer (Detail F). pedestals and double pedestal lateral files (Figure 21) as support 6. The drawer will now slip free from...

  • Page 18: Panel Support Bracket With And Without Spacer Installation

    Unite Panel System - Worksurface with Pedestal Support Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.

  • Page 19: Typical Corner Intersection With Pedestal Support Installation

    Unite Panel System - Worksurface with Pedestal Support Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
  • Page 20 Unite Panel System - Worksurface with Pedestal Support Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.

  • Page 21: Typical Return Peninsula With Pedestal Support Installation

    Unite Panel System - Worksurface with Pedestal Support Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.

  • Page 22: Typical Rectilinear Worksurface With Adjacent Worksurface And Pedestal

    Unite Panel System - Worksurface with Pedestal Support Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.

  • Page 23: Gallery Panel Worksurface Edge Support Bracket Installation

    Unite Panel System - Worksurface with Gallery Panel Installation ® Assembly Instructions Assemble units as described herein only. To do otherwise may result in instability. All screws, nuts and bolts must be tightened securely and must be checked periodically after assembly.
  • Page 24 1330 Bellevue Street P .O. Box 8100 Green Bay, Wisconsin 54308-8100 1-800-424-2432 www.ki.com KI is a registered trademark of Krueger International, Inc. © 2021 Krueger International, Inc. All Rights Reserved Code KI-AI-000071/KI/PDF/0221...
