Lay worksurface upside down on soft surface to protect the top. Insert all
10 shoulder screws into the top and end panels.
2.
Place back panel 1 in place then ends 2 , 3 and then tighten all
camlocks (see diagram). Place adhesive cover over visible hardware.
2
Assembly Instructions
Orenda
1
4
Casegoods
TM
Reception Gallery
2
3
AKEGB
AKEGR
10
1
Align arrow
1
orientation
to insert part
2
Lock
10
Advertisement
Related Manuals for KI Orenda AKEGB
Summary of Contents for KI Orenda AKEGB
- Page 1 Assembly Instructions Orenda Casegoods AKEGB Reception Gallery AKEGR Lay worksurface upside down on soft surface to protect the top. Insert all 10 shoulder screws into the top and end panels. Place back panel 1 in place then ends 2 , 3 and then tighten all camlocks (see diagram).
- Page 2 Assembly Instructions Orenda Casegoods AKEGB Reception Gallery AKEGR For safety reasons, the adhesive mounting tape supplied must be used when installing the reception gallery. This one-time use adhesive mounting tape permanently secures the overhead in position to prevent it from tipping over. Do not remove the tape's protective backing before deciding the reception gallery's final position.
