Lay table surface upside down on soft surface to protect. Insert the 16
shoulder screws into the top (see diagram).
2.
Place laminate bases 1 in place then tighten all camlocks (see diagram). Place
adhesive cover over visible hardware (see diagram). Insert the 8 glides leaving 1/4
inch of adjustment.
1
Assembly Instructions
Conference Table Laminate Base
16
1
Metal
Inserts
Inside
Orenda
Casegoods
TM
Do not turn over table using
the laminate bases. Insert a
piece of packaging under
surface to facilitate handling.
Floor
Supplied with
laminate bases
2
1
Align arrow
1
orientation
to insert part
2
Lock
Supplied with
laminate bases
Supplied with
laminate bases
AKLLA
AKLLB
AKLLR
16
16
8
