IEI Technology SPCIE-C246 Quick Installation Manual

Hide thumbs Also See for SPCIE-C246:

Advertisement

Table of Contents

Full-size PICMG 1.3 CPU Card supports LGA1151 Intel® Xeon
th
th
8
/9
Gen. Core™ i9/i7/i5/i3/Pentium
ECC & non-ECC DDR4, HDMI, DP, Dual Intel
(5Gb/s), SATA 6Gb/s, M.2, HD Audio, Intel
Quick Installation Guide
Package List
SPCIE-C246 package includes the following items:
1 x SPCIE-C246 single board computer
1 x SATA cable
1 x Mini jumper pack
1 x QIG (Quick Installation Guide)
SPCIE-C246
Version 1.1
September 18, 2020
©2020 Copyright by IEI Integration Corp.
All rights reserved.
®
®
/Celeron
CPU per Intel
®
PCIe GbE, USB 3.2 Gen 1
®
AMT and RoHS
®
E,
®
C246,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPCIE-C246 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology SPCIE-C246

Summary of Contents for IEI Technology SPCIE-C246

  • Page 1 (5Gb/s), SATA 6Gb/s, M.2, HD Audio, Intel AMT and RoHS SPCIE-C246 Quick Installation Guide Version 1.1 September 18, 2020 Package List SPCIE-C246 package includes the following items: 1 x SPCIE-C246 single board computer  1 x SATA cable  1 x Mini jumper pack ...

  • Page 2: Specifications

    Specifications  CPU: ® ® LGA1151 socket supports Intel Xeon E, 8 generation ® ® Core™ i9/i7/i5/i3, Pentium or Celeron processor ®  Chipset: Intel C246  Memory: Four 288-pin 2666MHz dual-channel DDR4 SDRAM unbuffered DIMMs support up to 64GB ECC & non-ECC memory ...
  • Page 3  Audio: Support 7.1 channel HD audio by IEI AC-KIT-892HD kit  Front Panel: 1 x Front Panel (Power LED, HDD LED, Speaker, Power Button, Reset Button)  LAN LED: 2 x LAN LED (1x2 pin)  TPM: 1 x TPM (2x10 pin) ...

  • Page 4: Ordering Information

    IEI Resource Download Center SPCIE-C246 are available on IEI https://download.ieiworld.com Resource Download Center. Type SPCIE-C246 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to view its content.

  • Page 5: Jumpers Setting And Connectors

    SAIDE-KIT01-R10:  SATA to IDE/CF Converter board Jumpers setting and connectors LABEL FUNCTION J_ATX_AT1 AT/ATX Power Mode Setting J_CMOS2 Clear CMOS Button PCIE x16 Power PCIe x16 Channel Mode Setting USB SW1 Power USB Power Setting USB SW2 Power J_FLASH1 Flash Descriptor Security Override F_PANEL1 Front Panel Connector...
  • Page 6 JSPI2 Flash EC ROM Connector LED_LAN1 LAN1 Link LED Connector LED_LAN2 LAN2 Link LED Connector CHASSIS1 Chassis Status Connector J_ATX_AT1: AT/ATX Power Mode Setting PIN NO. DESCRIPTION Short 1 - 2 ATX Mode (default) Short 2 - 3 AT Mode J_CMOS2: Clear CMOS Button PIN NO.
  • Page 7 USB SW1, USB SW2: USB Power Setting USB SW DESCRIPTION +5V DUAL 5V DUAL (default) J_FLASH1: Flash Descriptor Security Override PIN NO. DESCRIPTION Short 1 - 2 Disabled (default) Short 2 - 3 Enabled F_PANEL1: Front Panel Connector DESCRIPTION DESCRIPTION BEEP_PWR SPKR IPMI ID_LED+...
  • Page 8 KB_MS1: 6-pinheader Keyboard/Mouse Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Mouse Data Mouse Clock Keyboard Data Keyboard Clock DIO1: Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0...
  • Page 9 J_AUDIO1: Audio Source Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDA_BIT_CLK HDA_SYNC HDA_SDOUT HDA_SPKR HDA_SDIN HDA_RST# HDA_GND HDA_VCC HDA_GND HDA_+12V HDMI1: HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI_DATA2-1 HDMI_DATA2#-1 HDMI_DATA1-1 HDMI_DATA1#-1 HDMI_DATA0-1 HDMI_DATA0#-1 HDMI_CLK-1 HDMI_CLK#-1 HDMI_SCL-DVI HDMI_SDA-DVI HDMI_HPD-DVI DP1: Internal DisplayPort Connector PIN NO.
  • Page 10 TPM1: TPM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCLK LFRAME# LRERST# LAD3 LAD2 +3.3V LAD1 LAD0 SB3V SERIRQ GLKRUN# LPCPD# LDRQ# I2C1: I C Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCH_GP38 (I2C_DAT) PCH_GP39 (I2C_CLK) SMB1: SMBus Connector PIN NO. DESCRIPTION PIN NO.
  • Page 11 MPCIE1: mSATA Card Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V PCIE_RXN3 PCIE_RXP3 DAS/DSS# PCIE_TXN3 +3.3V PCIE_TXP3 +3.3V +3.3V PCIE_RXN2 +3.3V PCIE_RXP2 PCIE_TXN2 PCIE_TXP2 PCIE_RXN1 PCIE_RXP1 PCIE_TXN1 PCIE_TXP1 DEVSLP PCIE_RXN0 PCIE_RXP0 PCIE_TXN0 PCIE_TXP0 PERST# CLKREQ# REFCLKN PEWAKE REFCLKP Notch Notch Notch Notch...
  • Page 12 SUSCLK PEDET +3.3V +3.3V +3.3V USB3_1, USB3_2: External USB 3.2 Gen 1 Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION VBUS STDA_SSRX_N STDA_SSRX_P GND_DRAIN STDA_SSTX_N STDA_SSTX_P USB3_34: Internal USB 3.2 Gen 1 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA+ USB3_RX- USB_DATA- USB3_RX+ USB3_TX+...
  • Page 13 SATA1, SATA2, SATA3, SATA4, SATA5, SATA6: SATA 6Gb/s Drive Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX- SATA_TX+ SATA RX+ SATA_TX- COM1, COM2, COM3: Internal RS-232 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION COM4: Internal RS-422/485 Serial Port Connectors PIN NO.
  • Page 14 LAN1, LAN2: RJ-45 LAN Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDIA3- MDIA1+ MDIA3+ MDIA2+- MDIA2- MDIA0- MDIA1- MDIA0+ JSPI1: Flash SPI ROM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CS# SPI_SO SPI_CLK SPI_SI JSPI2: Flash EC ROM Connector PIN NO.

  • Page 15: Board Layout: Jumper And Connector Locations

    Board Layout: Jumper and Connector Locations...
