Full-size PICMG 1.3 CPU card supports LGA1150 Intel® Xeon® E3/
Core™ i3/Pentium® and Celeron® per Intel® C226, DDR3,
VGA, IDP, Dual Intel® PCIe GbE, SATA 6Gb/s, mSATA,
mini PCIe, RS-232, HD Audio, iRIS-2400 and RoHS
SPCIE-C2260-i2
Quick Installation Guide
Version 1.0
Nov. 13, 2015.
Package List
SPCIE-C2260-i2 package includes the following items:
1 x SPCIE-C2260-i2 single board computer
1 x Dual RS-232 cable
2 x SATA cable
1 x USB cable
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Integration corp.
All rights reserved.
1
Advertisement
Related Manuals for IEI Technology SPCIE-C2260
Summary of Contents for IEI Technology SPCIE-C2260
- Page 1 SPCIE-C2260-i2 Quick Installation Guide Version 1.0 Nov. 13, 2015. Package List SPCIE-C2260-i2 package includes the following items: 1 x SPCIE-C2260-i2 single board computer 1 x Dual RS-232 cable 2 x SATA cable 1 x USB cable 1 x Utility CD 1 x QIG (Quick Installation Guide) ©2006 Copyright by IEI Integration corp.
-
Page 2: Specifications
Specifications CPU: LGA1150 Intel® Xeon® E3/Core™ i3/Pentium® or Celeron® processor supported PCH: Intel® C226 Memory: Four 240-pin 1600/1333MHz dual-channel DDR3 & DDR3L SDRAM ECC and non-ECC unbuffered DIMMs support up to 32GB BIOS: UEFI BIOS Graphic Engine: Intel® HD Graphics Gen 7.5 support for DX11.1 and OpenCL 1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode Display Output: VGA (Up to 1920x1200 @ 60 Hz) - Page 3 4 x USB 3.0 (2 on rear IO, 4 by pin header) Watchdog Timer: Software programmable support 1~255 sec. system reset FAN: 1 x 4-pin CPU fan connector 1 x 3-pin system fan connector Front Panel: 1 x Front Panel (Power LED, HDD LED, Speaker, Power Button, Reset Button) LAN LED: 2 x 2 Pin for LAN1 LED, LAN2 LED (Active) TPM: 1 x 20-pin (2x10) header...
-
Page 4: Ordering Information
Ordering Information SPCIE-C2260-i2-R10: Full-size PICMG 1.3 CPU card supports LGA1150 Intel® Xeon® E3/Core™ i3/Pentium® and Celeron per Intel® C226, DDR3, VGA, IDP, Dual Intel® PCIe GbE, SATA 6Gb/s, mSATA, RS-232, mini PCIe, HD Audio, iRIS-2400 and RoHS 32200-074800-RS: RS-422/485 cable, 200mm 19800-010500-100-RS: USB 3.0 cable with bracket... -
Page 5: Jumpers Setting And Connectors
Jumpers setting and connectors LABEL FUNCTION J_ATX_AT1 AT/ATX mode select switch J_CMOS1 Clear CMOS button PCIE x16 Power PCIEX16 channel mode setting USB SW1, USB SW2 USB power setting MSATA_SW1 M-SATA switch auto-detect J_FLASH1 Flash descriptor security override J_AUDIO1 Audio source connector BAT1 Battery connector CHASSIS1... - Page 6 JSPI2 Flash EC ROM connector SYS_FAN1 System fan connector TPM1 TPM connector USB1, USB2 Internal USB 2.0 connectors Internal USB 3.0 connector LAN1, LAN2 RJ45 LAN connectors CN5, CN6 External USB 3.0 ports VIDEO1 VGA connector J_ATX_AT1: AT/ATX mode select switch PIN NO.
- Page 7 PCIE x16 Power: PCIEX16 channel mode setting PCIE x16 DESCRIPTION 1 x16 PCIE 1 x16 PCIE (default) 2 x8 PCIE 2 x8 PCIE 1 x8 , 2x4 PCIE 1 x8 , 2x4 PCIE Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset Auto Power Button Status [Disabled(ATX)]...
- Page 8 MSATA_SW1: M-SATA switch auto-detect PIN NO. DESCRIPTION Open Auto Detect M-SATA (default) Short M-SATA Enable J_FLASH1: Flash descriptor security override PIN NO. DESCRIPTION Short 1 - 2 Disabled (default) Short 2 - 3 Enabled J_AUDIO1: Audio source connector PIN NO. DESCRIPTION PIN NO.
- Page 9 CPU12V1: +12V power connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V DIO1: Digital I/O connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 DP1: Display port connector PIN NO.
- Page 10 CN3: EC debug connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_EPP_STB# EC_EPP_AFD# EC_EPP_PD0 EC_EPP_PD1 EC_EPP_INIT# EC_EPP_PD2 EC_EPP_SLIN# EC_EPP_PD3 EC_EPP_PD4 EC_EPP_PD5 EC_EPP_BUSY EC_EPP_PD6 EC_EPP_KSI5 EC_EPP_PD7 EC_EPP_KSI4 F_PANEL1: Front panel connector DESCRIPTION DESCRIPTION BEEP_PWR SPKR IPMI ID_LED+ IPMI LED IPMI ID_LED- PWRBTN_SW# PC_BEEP SPKR EXTRST-...
- Page 11 CN1: I2C Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCH_GP38 (I2C_DAT) PCH_GP39 (I2C_CLK) KB_MS1: Keyboard and mouse connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MSDATA MSCLK KBDATA KBCLK LED_LAN1: LAN1 link LED connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V LAN1_LED_LNK#_ACT LED_LAN2: LAN2 link LED connector PIN NO.
- Page 12 LPT1: Parallel port connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 ACKNOWLEDGE# BUSY PAPER EMPTY PRINTER SELECT AUTO FORM FEED # ERROR# INITIALIZE# PRINTER SELECT LN#...
- Page 13 CN4: M-SATA card connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# +3.3V 1.5V MSATA_CLK# MSATA _CLK PLTRST_N +3.3V PLTRST_N SATA_RX+ +3.3V SATA_RX- 1.5V SMB_CLK SATA_TX- SMB_DATA SATA_TX+ USB_DATA- USB_DATA+ +3.3V +3.3V +3.3V CLINK_CLK CLINK_DATA 1.5V CLINK_RST# MSATA_DET +3.3V...
- Page 14 COM1, COM3, COM4, COM5: RS-232 serial port connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION COM2: RS-422/485 serial port connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RXD485# RXD485+ TXD485+ TXD485# SATA1, SATA2, SATA3, SATA4, SATA5, SATA6: SATA 6Gb/s drive connectors PIN NO. DESCRIPTION PIN NO.
- Page 15 SPDIF1: SPDIF connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPDIFOUT SPDIFIN JSPI1: Flash SPI ROM connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CS# SPI_SO SPI_CLK SPI_SI JSPI2: Flash EC ROM connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CS# SPI_SO SPI_CLK SPI_SI...
- Page 16 TPM1: TPM connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCLK LFRAME# LRERST# LAD3 LAD2 +3.3V LAD1 LAD0 SB3V SERIRQ GLKRUN# LPCPD# LDRQ# USB1, USB2: Internal USB 2.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA+ USB_DATA+ USB_DATA- CN7: Internal USB 3.0 connector PIN NO.
- Page 17 LAN1, LAN2: RJ45 LAN connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDIA3- MDIA3+ MDIA2- MDIA2+ MDIA1- MDIA1+ MDIA0- MDIA0+ CN5, CN6: External USB 3.0 ports PIN NO. DESCRIPTION PIN NO. DESCRIPTION VBUS STDA_SSRX_N STDA_SSRX_P GND_DRAIN STDA_SSTX_N STDA_SSTX_P VIDEO1: VGA connector PIN NO.
- Page 18 Board Layout: Jumper and Connector Locations (Unit: mm)
