2.5.
Secondary infusion
This programming mode enable the infusion of a secondary line
placed above, automatically followed by the infusion of a primary
bag placed below. The parameters of the primary infusion must be
previously set.
SEC
Antibiotics
0000ml
1.
Place the drop sensor on the primary line.
2.
Select the secondary volume to infuse with
Then, confirm and shift to next item with
3.
Select the secondary infusion duration with
Then, confirm and shift to next item with
4.
Select the drug name (optional) with
Then, confirm and shift to next item with
5.
Select the flow rate with
automatically calculated and readjusted according to displayed flow
rate.
6.
Start secondary infusion by pressing
7.
After the secondary infusion has been delivered, a short beep is
emitted. The pump automatically resumes the primary infusion.
Note that if opening the clamp is forgotten, the drip alarm triggers.
2.6.
Programming pause
1.
Press
twice, or reach programming pause with
2.
Select pause duration in minutes and hours with
and confirm with
auditing signal is emitted.
3.
If required, stop the pause by pressing
infusion.
2.7.
Key locked / Unlocked
1.
Access with the
key.
2.
Select locked or unlocked position with
Note: when locked, the infusion parameters cannot be changed.
1310-4_nu_module_mvp_st_eng_140128.doc
100ml
1h20
670ml/h
.
.
.
.
.
.
. The infusion time is
.
key.
. After the pause has ended, an
, or
to restart the
and press
2.8.
Loading dose
This infusion mode enables the delivery of a volume (e.g. loading dose)
automatically followed by the delivery of the primary infusion.
The parameters of the primary infusion must be previously set according
to paragraph 1.4.
Note that infused loading dose volume is automatically subtracted from
primary volume to infuse.
1.
Select the volume to infuse with
Then, confirm and shift to next item with
2.
Select the drug name (optional) with
Then, confirm and shift to next item with
3.
Select the flow rate with
automatically calculated.
4.
Start loading dose delivery by pressing
2.9.
Ramp up / Ramp down
By setting ramp up duration and ramp down duration, the pump will
automatically increase the flow rate to reach in ten intermediate
steps the plateau flow rate and, at the end of the infusion plateau,
decrease the flow rate down to zero.
1.
Select the volume to infuse with
to next item with
2.
Select total infusion time in minutes with
The sustaining flow rate is then automatically calculated.
3.
Select ramp-up time in minutes with
Then, confirm and shift to next item with
4.
Select ramp-down time in minutes with
Then confirm and shift to next item with
5.
Start infusion by pressing
.
20ml
2min00
600ml/h
0000ml
.
.
.
.
. The infusion time is
.
9h59 200 m l / h 9h59
200 m l
24h00
, then confirm and shift
.
, in hours with
, in hours with
.
, in hours with
.
.
.
.
.
- 5 -
