- Page 1 MEDICAL DEVICES Volumat MC Agilia QUICK REFERENCE GUIDE...
- Page 2 WARNING: This Quick Reference Guide is not intended to be comprehensive instructions for the set-up and operation of the Agilia System. For complete instructions, warnings and cautions, please refer to the Volumat MC Agilia Instructions for Use. Drug Drug name concentration...
- Page 3 Administration Set Loading & Removal Open the pump door by lifting the door lever. The pump automatically switches on when plugged in. NOTE: If operating on battery, press the key. Auto-test checks the functionality of the pump. When auto-test completes, display indicates Install Set.
- Page 4 Program Basic Infusion 1. Power ON, Select Basic mL/h infusion, press 2. Use arrow keys to program Volume to be Infused (VTBI), press Use the double arrow key to increment VTBI per NOTE: pre-populated levels (1 mL, 10 mL, 20 mL, 50 mL, 100 mL, 250 mL, 500 mL, 1000 mL, ...).
- Page 5 Changing Infusion Parameters Changing rate Adjust rate using arrow keys. Confirm new rate by pressing Changing VTBI Press key. Use arrow keys to select VTBI enter from menu, press Use arrow keys to change VTBI, press STOP or PAUSE an Infusion STOP: Press key.
- Page 6 Program Secondary (Piggyback) Infusion 1. Press to hold Primary infusion. Press key, select option, enter then press 2. Confirm primary infusion parameters and press The screen advances to secondary infusion parameters. 3. Use arrow keys to program secondary infusion parameters, Press to confirm each parameter.
- Page 7 Bolus Dose Administration To access bolus, press Direct Bolus bolus To access direct bolus, press To administer bolus, press and hold key. Monitor volume infused on screen. To stop the bolus, release key. Programmed Bolus To access Programmed Bolus, press prog Use arrow keys to program bolus parameters, press...
- Page 8 Set-up Vigilant Drug’Lib Infusion 1. Power ON. Press to change and select Care Area. 2. Use arrow keys to select Care Area, press 3. Confirm desired Care Area, press Care area loads appropriate drug library. 4. Use arrow keys to scroll to the next drug name, press "If the drug is not found in the predefined drug list, check for "Drug X (mL/h)"...
- Page 9 Program Vigilant Drug’Lib Infusion 1. Use arrow keys to modify VTBI, press When using Vigilant Drug’Lib, symbol is displayed NOTE: during programming and infusion. 2. Use arrow keys to change infusion duration (double arrow for hour, single arrow for minute), press The resulting rate and dose are automatically calculated NOTE: and displayed.
- Page 10 Program Loading Dose Infusion If configured for the selected drug, loading dose screen will appear. Press Yes to program loading dose. Use arrow keys to program infusion parameters and press to confirm. start Press to start the infusion or to change the infusion parameters. Turn Pump Off Press key to stop infusion.
- Page 11 Medium Priority Alarms appear as flashing YELLOW on indicator status. Infusion continues. Message Definition Action “Near End of Remaining VTBI is less -Press key. Infusion alert” than 5% of initial VTBI -Prepare new container or programmed, or 5 mL left, adjust infusion or 5 minutes left.
- Page 12 This document may not be reproduced in whole or in part without the written consent of Fresenius Kabi. Agilia® is a registered trademark by Fresenius Kabi in selected countries. Fresenius Kabi AG D-61346 Bad Homburg v.d.H...
