- Page 1 Installation Guide 406SL Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20230614R1 DATE: ________________...
-
Page 2: Table Of Contents
Oscillating Multi-tool Before You Begin Read all instructions prior to assembling or installing any Holman product. Be sure partition (40660, 40661, 40662, or 40665) is assembled and ready to be installed. Always locate your installation locations prior to performing any work. -
Page 3: Parts List
Instructions – 406SL Parts List Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2... -
Page 4: Step 1 - "B" Pillar Removal And Modification
Instructions – 406SL Step 1 – “B” Pillar Removal and modification. The factory “B” Pillar cover must be cut to gain access to the mounting locations used for the side wings. Remove the coat hook cover and use a T27 socket to remove coat hook. -
Page 5: Step 3 - Bolt Top Wing To Partition
Instructions – 406SL Repeat for the passenger side wing. Snug tighten but allow for movement. Step 3 – Bolt Top Wing To Partition Using six 1/4" x 5/8” flanged hex head bolts and six 1/4” flanged lock nuts, bolt the top wing to the partition in orientation shown. - Page 6 Instructions – 406SL Place partition with wings into van. Have the wings orientated towards the “B” pillars. Press firmly against the “B” pillars and the support across the roof. Square the bottom of the partition. Using seven 5/16” x 3/4” self taping hex head bolts, bolt one of the side wings to the “B”...
