Murphy Bed Setup Instructions
Murphy Desk Bed Series 22
Storage Headboard Cabinet
WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE
INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SEVERE PERSONAL INJURY OR DEATH OR
.
DAMAGE TO THE PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT 866-725-6401 FOR ANY QUESTIONS
Rev. .10.23

Advertisement

loading
Need help?

Need help?

Do you have a question about the Murphy 22 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Wilding Wallbeds Murphy 22 Series

Summary of Contents for Wilding Wallbeds Murphy 22 Series

  • Page 1 P a g e Murphy Bed Setup Instructions Murphy Desk Bed Series 22 Storage Headboard Cabinet WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SEVERE PERSONAL INJURY OR DEATH OR DAMAGE TO THE PRODUCT.
  • Page 2 P a g e | ii...
  • Page 3 P a g e | iii Mechanism Box Contents (Left) (Right) Lower Bracket Clevis Pin Threaded Steel Barrel Cotter Pin ” Screw 50mm Bolt Pivot Post Black Flange mm Screw Thin Triangle Plate Heavy Triangle Plate Plunge Lock (12) Piston Ball Stud...

  • Page 4: Additional Hardware

    P a g e | iv Additional Hardware ” Wood Screw Connecting Bolt Pocket Hole Screw x 45mm Connector (60) (43) ” Predrill Bit ” x 20mm Connector ” Wood Screw ” Machine Screw (34-41) 4mm Allen Wrench Square Tip Bit (16) ”...

  • Page 5: Tools Needed

    P a g e Tools Needed: Phillips Head 6 Foot Ladder Screw Driver Power Screw Driver Stud Finder Tape Measure 14mm Wrench...
  • Page 6 P a g e Hardware Connecting Bolts (27) Step 1: Side Board Prep Lay the Right and Left Side Boards down as shown, and screw Connecting Bolts into the holes provided. Note: Screw the Connecting Bolts into the panels until the collar of the Connecting Bolt is seated firmly against the surface of the wood.
  • Page 7 P a g e Hardware Connecting Bolts Step 2: Headboard Prep and Installation Screw 4 Connecting Bolts into the bottom edge of the Headboard. With Help, position the Headboard between the Side Boards and under the Connecting Bolts. Lift the Headboard until the Connecting Bolts are seated inside the Cam-fittings.
  • Page 8 P a g e Step 3: Headboard Bottom Installation Attach the Headboard Bottom to the Side Boards and Headboard, as illustrated. Step 4 Hinged Headboard Top Installation Attach the Hinged Headboard to the Side Boards as illustrated. Note the notch is up Helpful Hint: Slightly lift the center section to get the unit positioned correctly.
  • Page 9 P a g e Step 5: Stretcher Installation Attach the Back Stretcher (5” width) to the back of the Side Boards. Next, attach the Front Stretcher to the lower set of Connecting Bolts as illustrated...
  • Page 10 P a g e Step 6: Bed Stop Installation Attach the Bed Stops at the top of the Side Boards. Note: The Cam-fittings are towards the top of the Bed Cabinet Surround.
  • Page 11 P a g e Step 7 With Help, stand the Bed Cabinet Surround up near the wall where the bed will be installed. Leave approximately 2 feet between your wall and the back of the cabinet.

  • Page 12: Wood Screws

    P a g e Hardware ” Wood Screws Step 8 Lift the Hinged Headboard Top into the open position. Use 2 of the 1 ¼” Screws (on both sides) to secure the Hinged Headboard top to the Side Boards, as shown. ”...
  • Page 13 P a g e Hardware Connecting Bolts Step 9: Bridge Board Prep and Installation Prepare the Bridge Board by screwing Connecting Bolts into each of the holes provided. Attach the Bridge Board to the top of the Side Boards using Cam-fittings.

  • Page 14: Light Kit Installation

    O p t i o n a l L i g h t K i t S e c t i o n P a g e Light Kit Installation This next section contains instructions for installing the optional Light Kit. Since a Light Kit is purchased as an option these steps may not apply to your bed.
  • Page 15 O p t i o n a l L i g h t K i t S e c t i o n P a g e Hardware ” Pan-head Double-lead Can Single-lead Can Screws Light Light Retaining Ring Optional Light Kit Step 1 Insert the Can Lights through the holes cut in the Light Bridge.
  • Page 16 O p t i o n a l L i g h t K i t S e c t i o n P a g e Hardware Push Switch 40mm Black ” Wood Screw Screws (2) Optional Light Kit Step 2 Place the Push Switch in the hole provided in the Light Bridge, as illustrated.
  • Page 17 P a g e | 10 WARNING! THE NEXT STEP MAY REQUIRE PROFESSIONAL HELP. IF YOUR WALLS ARE NOT TRADITIONAL WOOD FRAMING, YOU MAY NEED TO HIRE A HANDYMAN OR CONTRACTOR TO HELP IN ANCHORING THE BED TO YOUR WALL. FAILURE TO PROPERLY ANCHOR THE CABINET COULD CAUSE SEVERE PERSONAL INJURY OR DEATH.
  • Page 18 P a g e | 11 Hardware ¼” Predrill Bit 3 ½” Screw Square Tip Bit Step 11: Securing the Bed Cabinet Surround to the Wall Bridge Back After 3 Studs have been located, use the ¼” drill bit to drill 3 holes through the Bridge Back ONLY corresponding to where studs Bridge Board are located.

  • Page 19: Lower Bracket

    P a g e | 12 Hardware Lower Bracket Clevis Pin Cotter Pin Step 13: Connecting the Lower Bracket and the Piston Set the Piston in place in the Lower Brackets as illustrated and insert the Clevis Pin through the Lower Bracket and Piston. Once the Clevis Pin is in position, secure it in place using a Cotter Pin.
  • Page 20 P a g e | 13 Hardware ” Barrel Nuts ” Machine Screws Ball Stud (16) (16) Note: If the Lifting Arm does not come with the Ball Stud attached, use a 14mm wrench to attach the ball stud in to the center hole, as shown.
  • Page 21 P a g e | 14 Step 15: Connecting the Piston and the Lifting Arm Manuver the Piston and the Lifting Arm until the socket in the Piston lines up with the Ball Stud on the Lifting Arm. Once aligned, Push together until the Ball Stud snaps inside the Socket of the Piston.
  • Page 22 P a g e | 15 Hardware Threaded Steel 6 1/2mm Machine Thin Triangle Plates Barrels Screws Step 16: Desk Hardware Installation Attach the Thin Triangle Plates to the Desk as shown below. Do not fully tighten the Machine Screws at this point.
  • Page 23 P a g e | 16 Hardware Threaded Steel 6 1/2mm Machine Screws Barrels Step 18: Bed Box Assembly Insert a Threaded Steel Barrel into each side of the Side Rails to the Desk. Then using the last hole in Thin Triagle Plate attach the Side Rails to the Desk.
  • Page 24 P a g e | 17 Hardware Wooden Dowels Step 19 Insert Wooden Dowels into the holes in the Side Rails Mirror pattern on the right Hardware Black Finish 2 ½” Screws Washers (4) 6” ”...
  • Page 25 P a g e | 18 Step 20 Attach the Front Rail to the Side Rails using the Dowels for alignment. Secure the Front Rail in position using 4 (2 on each side) of the 2 ” Wood Screws and Black Finish Washers.
  • Page 26 P a g e | 19 Hardware Connecting Bolts Step 21 Screw 4 Connecting Bolts into the backside of the Side Rails. Move the Back Rail into position and lock it in place using the Cam-fittings.
  • Page 27 P a g e | 20 Locate the pre-drilled Handle Holes in the Face Panels. Step 22: Face Panel Installation Place the Face Panels inside the rails. The face (finished or decorative side) of the Face Panels should be down. The holes around the perimeter of the Bed Face should be resting over the hardwood face support protruding from the Rails.
  • Page 28 P a g e | 21 Hardware 1 ¼” Pocket Hole 1 ¼” Screws Screws (26) (Quantity varies with style) Step 23 Use 26 of the 1 ” Screws around the perimeter to screw the Face Panels to the Rails. Use the 1 ”...
  • Page 29 P a g e | 22 Hardware 1 ¼” Washer-head Screws Elastic Straps Step 24: Elastic Strap Installation IMPORTANT NOTE: Lay the Elastic Straps at approximately a 45-degree angle at the front corners of the bed box. Screw These screws should be through the Elastic Strap and into the Face Panels within 5/8”...
  • Page 30 P a g e | 23 Hardware Pivot Post Black Flange 50mm Bolt Step 26: Pivot Hardware Installation Line up the Pivot Hole in the Side Rail with a cooresponding threaded hole in the Lifting Arm mechanism. Slide the Black Flange into the Pivot Hole. Then, insert the 50mm Bolt through the Pivot Post and thread it into the threaded hole in the Lifting Arm mechanism for now, just start the threads.
  • Page 31 P a g e | 24 Step 27: Connecting the Desk and the Lifting Arm Lift the Bed Box and Desk up and into the closed position. Caution: the Bed Face will fall open if it is not held at this point.
  • Page 32 P a g e | 25 Hardware Plunge Lock ¾” Screws Step 28: Plunge Lock Installation Attach the Plunge Locks to Side Rail on both sides using the ” Screws found in the Hidden Bed Mechanism box.
  • Page 33 P a g e | 26 Hardware Remington Handles Handle Screws Step 29: Bed Handle Installation With help, pull the bed partially down. Then, insert the Handle Screws into the pre-drilled holes in the Face Panel. Attach the Bed Handles to the Bed Face. With help, line the handles up with the screws coming from the inside.
