- Page 1 CH146 - INCLINED LOG CLIMBER Installation Instructions 102003-01 274.M12X200 656.M12 274.M12X230 97.M8X180CSK REF: CH146 pg 1 of 8 12.01.17 - PDS...
- Page 2 PARTS REQUIRED CONTINUED... H3-A H3-B H3-B H3-B H3-A TIMBERS REQUIRED REF: CH146 pg 2 of 8 12.01.17 - PDS...
- Page 3 FOUNDATIONS 2115 SOIL POST CONCRETE REF: CH146 pg 3 of 8 12.01.17 - PDS...
- Page 4 SURFACING 5593 1739 REF: CH146 pg 4 of 8 12.01.17 - PDS...
- Page 5 DRY INSTALL UNTIL THE OUTER FRAME IS COMPLETE 274.M12X200 102003-01 274.M12X230 ENSURE ASSEMBLY IS CONSTRUCTED AS SHOWN BELOW PLEASE TAKE EXTRA CARE TO ENSURE POSTS ARE POSITIONED CORRECTLY - GROOVE / FLAT FACES REF: CH146 pg 5 of 8 12.01.17 - PDS...
- Page 6 USING - 274.M12X200 (U1 & U4) / 274.M12X230 (U2 & U3) / 656.M12 / 102003-01 656.M12 274.M12X200 102003-01 274.M12X230 BOLT H3-A TIMBERS TO U5 & U7 TIMBERS USING - 274.M12X230 / 656.M12 / 102003-01 H3-A H3-A REF: CH146 pg 6 of 8 12.01.17 - PDS...
- Page 7 INSTALLATION INSTRUCTIONS SCREW THE OPPOSITE END (H3-A) INTO THE H1 TIMBER USING - 97.M8X180CSK WOOD SCREWS OUTER FRAME COMPLETE ENSURE THE OUTER FRAME IS CONSTRUCTED AS SHOWN H3-A H3-A REF: CH146 pg 7 of 8 12.01.17 - PDS...
- Page 8 USING - 97.M8X180CSK / 274.M12X200 / 656.M12 / 102003-01 H3-B BOLT & SCREW H3-B TIMBER TO H2 & U2 / U3 USING - 97.M8X180CSK / 274.M12X200 / 656.M12 / 102003-01 H3-B H3-B REF: CH146 pg 8 of 8 12.01.17 - PDS...
