7 POWER KEY [ ]
z Hold down for 1 second to turn the receiver ON or OFF. (p. 3)
z When "Screen Capture [PWR] Key" is set to "ON," push to capture the receiver
screen onto a microSD card.
([MENU] > SET > Function > Screen Capture [PWR] Key)
8 ENTER KEY [ENT]
Push to set the selected item or option.
9 QUICK MENU • RECORDING KEY [QUICK]/[●REC]
z Push to open the Quick Menu window. (p. 12)
z Hold down for 1 second to start or stop the voice recording. (p. 24)
10 MEMORY • SELECT MEMORY WRITE KEY [MR]/[MW]
z Push to enter the Memory mode.
z Hold down for 1 second to open the Memory Write window.
11 VFO/MHz • CLEAR KEY [V/MHz]/[CLEAR]
z Push to enter the VFO mode. (p. 15)
z In the VFO mode, push to select 1 MHz tuning steps. (p. 16)
z In the MENU screen, push to select an upper-tier menu. (p. 10)
z Push to delete an entered character.
12 D-PAD (UP)/(DOWN)/(LEFT)/(RIGHT) KEYS
D-pad()/D-pad()
z Push to change the MAIN band. (p. 13)
z In the MENU screen or the Quick Menu window, push to move the option or value
selector bar up. (p. 10, 12)
z Hold down for 1 second to turn the Dualwatch function ON or OFF. (p. 13)
D-pad()/D-pad()
z Push to select the receive band or the Memory group. (p. 16)
z In the MENU screen, push to select a menu item. (p. 11)
13 VOLUME CONTROL [VOL]
Rotate to adjust the audio level. (p. 3)
14 CONTROL DIAL [DIAL]
z Rotate to select an operating frequency. (p. 15)
z In the Memory mode, rotate to select a Memory channel. (p. 15)
z Rotate to select a setting item or value. (p. 10, p. 12)
z In the Character Entry mode, rotate to enter characters.
15 SPEAKER JACK [
Connect an optional earphone.
Speaker plug: 3.5 mm (1/8 inch)
L Confirm that the receiver is OFF before connecting or disconnecting optional equipment.
16 USB PORT (Type-C) [USB]
Connects to an external power source, a PC, or other USB devices.
L Not compatible with USB Power Delivery.
]
