Call from Base Station

Call from Base Station
WHY?
Requirement
HOW?
RESULt1 MIN
IMSI
RESULt2 SN
RESULt3
A
RESULt5 SCM Station class mark
+
D
MTXOFFset ERR Frequency error of mobile transmitter in actual analog TC.
A
MDEMOD DEV Mobile frequency deviation in actual analog TC.
MPOWER PWR Mobile output power in actual analog TC (average value).
RESULt6 ERR Frequency error of mobile transmitter in actual digital TC.
D
RESULt7 PWR Mobile output power in actual digital TC (average value).
RESULt8 DCC Digital color code. Value must be same as entered DVCC.
Test whether the base station sets up a call to the
mobile.
Proper call setup is a requirement for further tests.
The mobile is not in an analog or digital traffic channel.
In any other case drop the call with
The mobile is not in test mode.
Make the general test preparations.
Press in the basic test mask.
{CELL.}
Lift the handset when the mobile rings or the "Call
Received" indicator symbol lights up. Then the mobile is
handed off to the selected analog or digital traffic chan-
nel. Now the display will show the test results.
Test Results
Received mobile station identification (MIN or IMSI).
1st line: Serial number of mobile (hexadecimal code).
2nd line: Serial number of mobile (decimal code).
1st character: power class
(1 = high, 2 = medium, 3 = low, 4 = very low)
2nd character: transmit mode
(blank = continuous, D = discontinuous)
3rd character: RF bandwidth
(blank = 20 MHz, E = extended = 25 MHz)
4th character: mobile type
(0 = analog mobile; 1 = IS-136 mobile)
Power must correspond to entered power level (see appendix).
Power must correspond to entered power level (see appendix).
IS-136 MS
.
{RELEASE}
10-19
