Insert the cable with the connector
towards the NFC board (A) inside the
display support, and make it exit
from the hole located near the
bracket curve.
Adhere the liquid anti-penetration
adhesive on the upper plate of the
display bracket, where the micro USB
cap will be positioned.
UNITY MINI_INSTALLATION MANUAL
REV 1.0
2016.11.28
32/43
