Connect the additional weight
sensor cable (CABLE C) and the
weight stack sensor cable
(CABLE D) to the weight stack
sensor bar.
Connection of the
cables to the weight stack
sensor bar: the connection
shown in red should be avoided,
as the contacts present in the
sensor bar are very small and
can be easily bent/damaged.
Reposition the additional weight
along the two guides of the
additional weight.
The white reflecting
strip of the additional weight
must cover the additional
weight sensor.
