Position the weight stack sensor bar in
the bottom of the guide of the additional
weight.
The distance from the bottom
between the end of the guide of the
additional weight and the weight stack
sensor bar must be 4 cm – 1.57''.
Fasten the weight stack sensor bar to the
guide of the additional weight.
TOOL: small tip Phillips screwdriver.
Return the additional weight support
plate to its original position.
The cables must pass below
the two guides of the additional weight.
Insert the o-ring in the plastic block
extracted from the guide of the additional
weight that holds the weight stack sensor
(reference upper part of the guard).
