Case 1
CORRECT POSITION
Case 2
CORRECT POSITION
UNITY MINI_INSTALLATION MANUAL
REV 1.0
Connect the additional weight board (C)
to the additional weight sensor cable
(CABLE C).
Position the additional weight board in
correspondence of the additional weight
support plate.
configurations of the additional weight
support plate are shown to the side as
well as the correct position of the
additional weight board in SELECTION
PRO / SELECTION PRO MED equipment.
2016.11.28
The three possible
