4 UNITY MINI INSTALLATION
4.1 REAR GUARD REMOVAL
UNITY MINI_INSTALLATION MANUAL
REV 1.0
Remove the two self locked nuts located in the central
part of the right and left rear guard.
TOOL: 13mm articulation extension socket.
Remove the two pulleys to permit the removal of the
side cover and then the rear guard.
TOOL: Allen wrench with an 8mm insert and 17 mm fork
wrench.
2016.11.28
10/43
