Objective: position the white
reflecting strip in the portion of
the additional weight that
covers the additional weight
sensor. For details, follow the
procedure indicated below.
Remove the additional weight
from the guide of the additional
weight and turn it 180°.
Clean the additional weight
carefully (reference right side)
using a cloth on which a
degreaser has been sprayed.
Stick two pieces of the white
reflecting strip along the right
side of the plate, exactly as
shown in the photo.
Cut the extra adhesive at the
end of the plate, using a cutter.
The length of the
white reflecting strip is equal to
the length of the additional
weight slot.
