1x2 HDMI SPLITTER
WITH EXTENDER POC
INTRODUCTION
This product is a 1 input to 2 outputs splitter extender kit, it distributes 1 HDMI
input signal to 2 identical signal outputs, extends these signals up to 70 meters.
Supports 4K@30Hz resolution, bi-directional IR passthrough, RS-232 control and
3.5 mm L/R audio output functions. It is suitable for outdoor advertising, studios,
multimedia classrooms, etc.
FEATURES
• Distributes 1 HDMI source to 2 HD displays over network cable simultaneously
• Zero latency transmission
• Supports up to 4K@30Hz resolution, downward complatible
• Transmitter supports one HDMI Loop-out
• Supports CAT6/6a/7 network cables which can transmit 1080p signal up to 70
meter and 4K@30Hz signal up to 40 meter
• Supports power over network cable, only transmitter needs to be powered
• Supports HDR10
• Supports bidirectional IR passthrough (20~60Hz)
• Supports RS-232 command control
• Surge protection, lightning protection, ESD protection

PACKAGE CONTENTS

• Transmitter unit x 1pc • Receiver unit x 2pcs • DC12V/1A x 1pc
• IR Blaster extension cable x 1pc • IR receiver extension cable x 2pcs
• User manual x 1pc • Terminal Block (RS-232) x 1pc • Mounting ear x 2pcs
• Screws x 8pcs
NOTE: above accessories are contented in the regular package for the kit
with transmitter and receiver. If buy HDMI Extender TX or HDMI Extender RX
separately, the package contents would be different.

INSTALLATION REQUIREMENTS

Item
Signal source
Cable
Display device
Description
Devices with HDMI port
(PC, DVD, NVR, etc)
CAT.6/6A/7, following
standard EIA/TIA 568B
TV, projector, etc,
with HDMI port
Requirement
HDMI cable ≤ 5m
CAT6/6A/7 ≤ 70 m
HDMI cable ≤ 5m
