• Do not modify and alter the product and any accessories! Do not use any damaged parts. • Keep enough space around all devices for a good ventilation and free motion and to avoid damages. • Do not unplug the device when it is in using, keep distance from flammable and explosive devices. • Power supply: DC 5V, usage only the supplied power unit, do not use the power supply if it is damaged. WWW.TECHLY.COM...
④ ④ The yellow jack input the video signal, the red VIDEO L/R and the white jack input the audio signal - right and left channel 720/1080P Switch the resolution to 720p or 1080p HDMI Output HDMI signal DC 5V Input DC5V power InStAllAtIon reqUIreMentS Source devices • Source device with RCA jacks, such as VCD/DVD player, STB etc. Display devices • Display device with HDMI input, such as SDTV, HDTV, projector etc. WWW.TECHLY.COM...
A: 1) Check and make sure the power supply and all cables are connected well. 2) Check and make sure there is AV signal input and you've chosen the right HDMI signal channel. q: Why does the output image have the snow point or unclear? A: Change an HDMI cable or use a shorter HDMI cable for testing. WWW.TECHLY.COM...
A/V connector RCA female 1a Contact discharge level 3 Protection Electrostatic protection 1b Air discharge level of the whole machine level 3 Standard: IEC61000-4-2 Working temperature 0° 60° (32°F to 140°F) -10° 70° operating Storage temperature (-4°F to 158°F) environment Humidity (non- 0° 90% relative condensing) humidity 61.50 (W) × 55.00 (D) Dimensions × 20.00 (H) mm body Housing Properties Color Black Weight 37.5 g WWW.TECHLY.COM...
Page 6
This product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collections system for these products in compliance with EU Directive WEEE. With the CE sign, Techly ensures that the product is ® conformed to the basic European standards and directives. WWW.TECHLY.COM...
• Non installare il prodotto in luoghi soggetti a vibrazioni o oscillazioni. • Non modificare o alterare il prodotto e i suoi accessori! Non utilizzare parti danneggiate. • Mantenere sufficiente spazio attorno alla periferica per garantire una buona ventilazione, permettere una maggiore libertà di movimento ed evitare danni. WWW.TECHLY.COM...
DellA conFeZIone Verificare che nella confezione siano inclusi i seguenti elementi: • Mini Convertitore AV a HDMI • Manuale d’istruzione • Alimentatore DC5V/1A DeScrIZIone PAnnello ① ① ② ② ③ ③ ④ ④ Il jack giallo immette il segnale video, il jack VIDEO L/R rosso e quello bianco immettono il segnale audio - canale destro e sinistro 720/1080P Commuta la risoluzione da 720p a 1080p HDMI Uscita segnale HDMI DC5V Ingresso alimentazione DC 5V WWW.TECHLY.COM...
D: Perché lo schermo non presenta alcuna immagine in uscita? R: 1) Questo convertitore AV a HDMI consente di controllare e assicurarsi che l'alimentatore e tutti i cavi siano ben collegati. 2) Controllare e assicurarsi che ci sia il segnale AV in ingresso e c he sia stato scelto il canale HDMI corretto. D: Perché l'immagine in uscita presenta dei puntini bianchi o non è chiara? R: Provare a sostituire il cavo HDMI o usare un cavo HDMI più corto. WWW.TECHLY.COM...
Page 10
3 Protezione livello di 1b Livello di scarico elettrostatica dell'intero protezione dell'aria 3 dispositivo Standard: IEC61000-4-2 Temperatura 0° 60° (32°F a 140°F) d’esercizio Informazioni Temperatura di -10° 70° ambientali stoccaggio (-4°F to 158°F) Umidità (senza 0° 90% umidità condensa) relativa 61.50 (P) x 55.00 (L) x Dimensioni 20.00 (A) mm caratteristiche Alloggiamento alloggiamento Colore Nero Peso 37.5 g WWW.TECHLY.COM...
Page 11
Contattate le autorità locali competenti per ottenere informazioni in merito allo smaltimento corretto della presente apparecchiatura. Con il marchio CE, Techly garantisce che il prodotto e ® conforme alle norme e direttive europee richieste. WWW.TECHLY.COM...
Page 12
All rights reserved. All trademarks and trade names are those of their respective owners. TECHLY® - Viale Europa 33 33077 Sacile (PN) - Italy WWW.TECHLY.COM...
