SIDEPOWER
Thrusters
Installation guide for dual joystick control panel type: 8940G
Installasjons veiledning for dobbel joystick kontroll panel type: 8940G
Installationsanleitung für dualpanel mit Joystick, Typ: 8940G
Important !
This panel will only work with Sidepower electric thrusters with a built in electronic control box
and a 4/5 lead control cable system. These panels are waterproof from the front end when
correctly installed. However, you must ensure that they can never be submerged in water as this
might cause a shortcircuit and thereby causing the thruster to start unintededly.
Viktig !
Dette kontroll panel fungerer bare med Sidepower elektriske trustere med integrert
elektronisk kontroll boks og 4/5 leders kontroll kabel system. Disse panelene er vantette fra
fronten når de er korrekt installert. Men, de må aldri stå slik att de er under vann da dette kan gi
en kortslutning som kan føre til selvstarting av trusteren.
Wichtig !
Das Panel funktioniert nur mit elektrischen Sidepower Systemen mit integrierter elektronischer
Kontrolleinheit und einem Kabelstrang mit 4/5 Leitungen, und ist bei korrektem Einbau an der
Vorderseite wasserdicht. Trotzdem muß sichergestellt sein, daß das Panel nicht unter Wasser
kommt, da dies zu einem Kurzschluß führen kann. Hierdurch kann es zu einem unbeabsichtigten
Start des Thrusters kommen.
We Sleipner Motor AS declare that these control panels complies with health and safety requirements
according to the Directive 89/336/EEC of 23 May 1989 amended by 92/31/EEC and 93/68/EEC.
Vi Sleipner Motor AS bekrefter att disse kontroll panel tilfredstiller krav til helse og sikkerhet i
følge Direktiv 89/336/EEC av 23 mai 1989 med tillegg av 92/31/EEC og 93/68/EEC.
Sleipner Motor AS garantiert, daß die Panels die Gesundheits- und Sicherheitsanforderungen entsprechend
der Direktive 89/336/EEC vom 23 Mai 1989, Ergänzung 92/31/EEC und 93/68/EEC erfüllen.
Partslist referring to drawing on next page
Deleliste refererer til tegning på neste side
Teileliste für Zeichnung Seite 2
Ref:
Pcs.
Parts:
1
1 x
Control panel
2
1 x
Gasket
3
4 x
Screws (A4)
4
4 x
Corner clips
Installation guide for Sidepower dual joystick control panel. Issue 2. © Sleipner Motor AS 2007
Deler:
Kontrollpanel
Pakning
Skruer (A4)
Hjørne klips
Teile:
Steuerpanel
Dichtung
Schraube (A4)
Eckstück
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Side-Power 8940G
Summary of Contents for Side-Power 8940G
- Page 1 SIDEPOWER Thrusters Installation guide for dual joystick control panel type: 8940G Installasjons veiledning for dobbel joystick kontroll panel type: 8940G Installationsanleitung für dualpanel mit Joystick, Typ: 8940G Important ! This panel will only work with Sidepower electric thrusters with a built in electronic control box and a 4/5 lead control cable system.
- Page 2 Thrusters SIDEPOWER Installation: Find a comfortable position for the panel where it does not obstruct or are obstructed by other controls. Use the enclosed cut-out pattern to mark the area. Cut out the circular area as shown on pattern. If the front surface around your cut out is jaggered or chipped, use a sealant to assist the gasket. Put the gasket (2) in its designated track in the back face of the panel (1).
