SIDE-POWER
Thruster Systems
Installation and user's manual
GB
Installasjons og brukermanual
N
SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
Tel:
Fax:
v 1.1
+47 69 30 00 60
+47 69 30 00 70
Control Panel
w w w . s i d e - p o w e r . c o m
s i d e p o w e r @ s l e i p n e r. n o
PJC-212
S-link
© Sleipner Motor AS 2011
Advertisement
Table of Contents
Related Manuals for Side-Power PJC-212
Summary of Contents for Side-Power PJC-212
-
Page 1: Control Panel
PJC-212 S-link SIDE-POWER Control Panel Thruster Systems Installation and user's manual Installasjons og brukermanual v 1.1 SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 w w w . s i d e - p o w e r . c o m... -
Page 2: Product Features
PJC-212 ™ Control panel with S-link CAN-bus connection Product features • For proportional thruster control with the new Speed Controlled DC-thrusters • Finger tip control speed control with purpose designed joysticks • Hold - function for easy docking, runs thrusters at selected power • Back-lit LCD display with instant feedback System status Amount of thrust & direction of thrust Thruster temperature Battery supply voltage to thrusters - Monitoring of Automatic Mainswitch (informs if the fuse has blown or the manual override is activated) • Interactive multi-language menus • CAN-Bus communication with thrusters and accessories • Plug & play cables, waterproof and compact connectors • Diagnostics via panel • Built-in audible alarm “buzzer” • Connector for external “buzzer”/loud audible alarms • Supports SR80 & SR100 retractable thrusters with or without Speed Control... -
Page 3: Display In Normal Use
As bars empties battery empties, As bars empties you have less you have less run you have less you have less run power and less time left. power and less time left run time left run time left Indicating amount of thrust set by other control units in the system, i.e additonal PJC-212/211 panels, 8700 Retract panel, input via 8730 S-link external switch interface (remote control, foot switches etc.) If two or more units is set to run the thruster in opposite direction, this information will not be shown. Alarms are ignored for 3 seconds after turning panel SPECIFIC INFORMATION WHEN USED IN A SYSTEM WITH SR-SERIES RETRACTABLE THRUSTERS Symbol shown when the thruster deploys Symbol shown when the thruster retracts PJC-212 1.1 - 2011... -
Page 4: Display When Alarms
MENU If the problem is that the voltage delivered from the batteries are too low for the thruster to be allowed to run, this is shown directly on the display by the battery that is not delivering being replaced by the alarm sign (see example). If the issue is something else, the alarm signal will replace the remaining run time indicator for the thruster / system that is causing the alarm. When using the “HOLD” function, the internal and external (if fitted) buzzer will give the following warning signals: Voltage below 9.3V/17.5V or temperature above 80 (12V/24V system) single beep every 2.4 seconds Voltage below 8.9V/16.3V or temperature above 90 (12V/24V system) two beeps every 2.4 seconds Voltage below 8.5V/15V or temperature above 100 (12V/24V system) red backlight in display and three beeps every 2.4 seconds The last warning signal will also be triggered when operating the thruster with the joysticks, except with no external buzzer output. If one or both of the thrusters goes in alarm state (Voltage below 8 Volts - for both 12 and 24 Volt systems - or temperature above 110 C): continuous beeps, and the “HOLD” function will be cancelled and both thrusters will stop. Temperature needs to go below 100 C before the thruster can be oper- ated again. SPECIFIC ALARMS WHEN USED IN A SYSTEM WITH SR-SERIES RETRACTABLE THRUSTERS Alarm shown when the thruster is obstructed while deploying. The internal buzzer will sound. Buzzer can be muted by pressing the “OFF” button Alarm shown when the thruster is obstructed while retracting. PJC-212 1.1- 2011... -
Page 5: Menu System
Type 1: Retract SR61242 (SR80/100) with PPC800, both devices needs to be set to Type 1. WHEN INSTALLING A RETRACT THRUSTER WITH SPEED CONTROL (PPC800), DO NOT TRY TO RUN THE THRUSTER UNTIL YOU HAVE COMPLETED THE ENTIRE SETUP PROCEDURE CORRECTLY! This is to prevent damage to the thruster caused by running the thruster while the retract mechanism is not fully opened. OK: Saves changes and quit editing. Select: Switch between Location, Retract and Retract settings. Cancel: Cancel operation without saving changes. Cancel: Returns to “SETUP” –menu. PJC-212 1.1 - 2011... - Page 6 Move: Moves the selected thruster assignment from bow to stern/stern to bow OK: Saves changes and returns to SETUP-menu Any changes made will be relayed to all other installed panels (Firmware 1.007 or newer) HOLD CALIBRATION Calibrates the HOLD-function to get balanced thrust from the bow and stern thruster. Start: Starts calibration. An instruction explaining the calibration procedure will be shown on the display. In some languages it will be necessary to press “More” to read the complete instructions. Press port or starboard “HOLD”-button for calibration in the desired direction This will make both thrusters run in the selected direc- tion. Adjust amount of bow thrust with bow joystick and stern thrust with the stern joystick until a balanced thrust is achieved OK: Saves the calibration setup and returns to “SETUP”- menu Cancel: Returns to “SETUP”-menu without saving changes Any changes made will be relayed to all other installed panels (Firmware 1.007 or newer) RADIO REMOTE SETUP Adjusts the amount of thrust which the ON/OFF remote control will run at. Use joysticks to adjust applied thrust OK: Saves changes and returns to “SETUP”-menu Cancel: Returns to “SETUP”-menu without saving changes Any changes made will be relayed to 8730 INTERFACE units with Firmware 1.203 or newer PJC-212 1.1- 2011...
-
Page 7: Default Settings
2nd & 3rd screens: Bow and stern thruster information - Motor temperature - Speed controller (PPC800) temperature - Actual voltage - Thrust percentage it is running at - Current consumption & watt at present. More: Changes to next information page Cancel: Returns to main menu DEFAULT SETTINGS Reset all settings to factory default - follow instructions on screen Start: Resets system to default factory settings DEFAULT Cancel: Returns to main menu without changes PANEL SETUP BACKLIGHT LEVEL PANEL Set level of panel backlight in daylight mode, 1-5 NIGHTLIGHT - COLOR Select color of backlight in nightlight mode: GREEN, BLUE, RED, WHITE NIGHTLIGHT - LEVEL Set level of panel backlight in daylight mode, 1-3 TIMER AUTO OFF Set the time from last use to auto panel shutdown. Set from 5-60 minutes in 5 minute steps or OFF (panel will not turn off automatically) OK: Saves changes and returns to main menu Cancel: Returns to main menu without saving changes PJC-212 1.1 - 2011... -
Page 8: Error Message Overview
Communiction No communication with Check S-link and power connections Fail device Power Failure No power Check power connections Fuse Blown Fuse blown Replace fuse in main switch Manual Main switch manually Pull main switch to cancel manual Override overridden override Deploy Retract obstructed Turn off all panels. Go for lower obstructed while deploying speed/deeper water and retry. Retract Retract obstructed Turn panel on and manually over- obstructed while retracting ride main switch. Remove obstruc- tion and try again. Power Fail Actuator not getting Check actuator connection or power Actuator any power. to actuator. PJC-212 1.1- 2011... - Page 9 Sample S-link system PJC-212 1.1 - 2011...
- Page 10 Connections for optional external buzzer/audible alarm External alarm/buzzer connection (S-link) Supply +12V / 24V DC Internal fuse/relay External alarm buzzer 12V / 24V DC - max 0,5A PJC-212 1.1- 2011...
- Page 11 Measurements PJC-212 1.1 - 2011...
-
Page 12: Service Centres
Fax: +44 1364 649 399 www.imtra.com Fax: +385 51 704 600 andy@sleipner.co.uk side-power@imtra.com acyachting@gmail.com Sleipner Motor AS • P. O. Box 519, N-1612 Fredrikstad • Norway Tel: +47 69 30 00 60 • Fax: +47 69 30 00 70 • sidepower@sleipner.no • www.side-power.com...
