PJC211/212/221/222
S-linkControl Panel
SIDE-POWER
Thruster Systems
Installation and user's manual
v 2.0.7
EN
PJC211
PJC212
PJC221
PJC222
SLEIPNER MOTOR AS
N-1612 Fredrikstad
Norway
Tel: +47 69 30 00 60
Fax: +47 69 30 00 70
www.side-power.com
sidepower@sleipner.no
© Sleipner Motor AS 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-linkControl Panel PJC211 and is the answer not in the manual?

Questions and answers

Summary of Contents for Side-Power S-linkControl Panel PJC211

  • Page 1 PJC211/212/221/222 S-linkControl Panel SIDE-POWER Thruster Systems Installation and user’s manual v 2.0.7 PJC211 PJC212 PJC221 PJC222 SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 Fax: +47 69 30 00 70 www.side-power.com sidepower@sleipner.no © Sleipner Motor AS 2014...
  • Page 2: Table Of Contents

    Side-Power products connected void and null. If you are interfac- ing by agreement with Sleipner and through a designated and approved interface, you are still...
  • Page 3: Product Features

    • Plug & play cables with compact connectors • Diagnostics and system setup via panel • Built-in audible alarm “buzzer” • Connector for external “buzzer”/loud audible alarms • Supports Side-Power retractable thrusters with or without Speed Control PJC211 PJC212 PJC221...
  • Page 4: Panel Layout & Functions

    Panel layout & functions PJC-211 Speed control joystick for thruster Information display, see following pages for details. Press both “ON” but- tons simultanously to activate control panel. MENU Press to de-activate control panel or cancel or go back in menu system or MENU mute internal alarm buzzer.
  • Page 5 Panel layout & functions front s_v strek_PJC222.pdf 1 04.11.2010 11:05:34 PJC-221 Speed control joystick for thruster Information display, see following pages for details. Press and hold “ON” button for 1 second to activate control panel. MENU Press to de-activate control panel or cancel or STOP go back in menu system or mute internal alarm buzzer.
  • Page 6: Display In Normal Use

    Display in normal use Status indicators for starboard Status indicators for bow bow thruster. Only shown in thruster. (Port bow thruster BOW-STB a dual bow thruster setup. in a dual bow thruster setup). Battery indicator will be Runtime indicator will be shown shown here in a single DC here in a single DC electric bow electric bow thruster setup.
  • Page 7: Symbols Explanations

    Symbols explanations DC Thrusters: Battery indicator. From 8.5V to 12V for 12V thrusters, 15V to 24V for 24V thrusters Motor temperature indicator. From 70°C/ 158°F to 130°C/266°F. Symbol shown when a DC Thruster is used in a dual bow or dual stern setup: Battery indicator.
  • Page 8 Symbols explanations Thrust power and direction, Bow thruster(s) Input from bow joystick on this panel. The thrust indicator will be shown in this position on a single joystick panel if the thruster is defined as a bow thruster Thrust power and direction, Stern thruster(s) Input from stern joystick on this panel The thrust indicator will be shown in this position on a single joystick panel if the thruster is defined as a stern thruster.
  • Page 9: Alarm Dc System

    Alarms DC System front s_v strek_PJC222.pdf 1 04.11.2010 11:05:34 when there is a problem or a fault, the panel will show this alarm situation by changing LCD display backlight to red color. The panel will also change to show “Alarm Info” on the bottom of the screen, indicating that by pressing the corresponding button below, you will get information about what the problem is (examples below).
  • Page 10: Alarms ( Ac And Hydraulic Thrusters )

    WARNING! HIGH SPEED. STABILIZER NOT ACTIVE! (Only for yachts equipped with a Side-Power Stabilizer system) warning will show when yacht is driven at high speed with stabilizer system inactive. Please refer to the Stabilizer ECU manual for speed settings.
  • Page 11: Menu System

    Menu system front s_v strek_PJC222.pdf 1 04.11.2010 11:05:34 Access menu system by pressing and holding Menu button for 3 seconds. Move around in menus by using joysticks. Follow instructions on the screen and press the buttons below the symbols indicated on LCD screen. STOP MENU PJC 212...
  • Page 12: Menu System - Language - Stabilizer - Default Settings

    A star (*) on each side indicates the laguage set. STABILIZER (Shown only for yachts equipped with a Side-Power Stabilizer system) Press the button below to edit the selected parameter. STABILIZER ON/OFF will start to blink, use joystick to alter value.
  • Page 13: Setup Procedure

    Setup procedure The setup procedure requires knowledge of the serial numer and location of all the S-link devices. Write this down in the form on the last page to have the information at hand when doing a manual setup. At the first startup of a new system, one of the two screens below will be shown: 1.
  • Page 14: Menu System - Setup

    Menu system - SETUP SETUP Move between menu items with the (stern) joystick. Press the button below to select the highlighted menu entry. Press the button below to return to the previous menu. Setup Setting done under SETUP will be sent to all other panels in the system. (Default in systems without stabilizers) SYSTEM DEVICES...
  • Page 15 Menu system - SETUP 1.2 Pump Control (PTO Mounted Pump) Values: Auto(default)/Always ON/Not Available when «Pump Control» is set to «Auto», the system will automatically control load sharing between two PTO pumps by deactivating the second PTO pump when not needed (two PTO pumps/control valves required) to reduce heat generation in the system and save fuel/energy.
  • Page 16 Menu system - SETUP 1.8 Thruster Stern (only available for PHC024 with FW V1.105 or higher) Values: without Bypass Valve (default)/with Bypass Valve All 513mm (20inch) tunnel and 610mm (24inch) tunnel thrusters, are SETUP supplied with hydraulic bypass/crossover valve and must be set to “with Bypass Valve”.
  • Page 17: Pdc 201

    Menu system - SETUP AC system - Setup 2. PDC 201 (SAC Controller) Setup Press the button below to return to the previous menu. Press the button below to edit the selected parameter. (Default in systems without stabilizers) Parameter value will start to blink, use joystick to alter value. Press the button below to save edited parameter to device Press the button below...
  • Page 18: Main Switch

    Menu system - SETUP DC system and device- Setup 4. MAIN SWITCH SETUP Press the button below to return to the previous menu. Press the button below to edit the selected parameter. Parameter value will start to blink, use joystick to alter value. (Default in systems without stabilizers) Press the button below...
  • Page 19: Ppc800, Sr150 000, Sr61242

    Menu system - SETUP 5.2 Direction Values: Normal (default)/Inverted Switches between Normal and Inverted running direction for the thruster SETUP (Default in systems without stabilizers) 5.3 Function Values: SR(V/L) ON/OFF, SRP 80/100, SRVP 130-210, SEP 30-240, SRVP 80/100, SRH, SRHP Setup the control unit behaviour - SR(V) ON/OFF: Retract thruster without speed controller (PPC800/PHC-024), SR61242 or SR150000.
  • Page 20: Rcrs-1

    Menu system - SETUP 6. RCRS-1 (S-Link Radio Remote Receiver) Move between parameters with the (stern) joystick. SETUP Press the button below to return to the previous menu. Press the button below to edit the selected parameter. (Default in systems Parameter value will start to blink, use joystick to alter value.
  • Page 21: Hold Calibration

    Menu system - SETUP HOLD CALIBRATION Calibrates the HOLD-function to get balanced SETUP thrust from the bow and stern thruster. Incomplete. the Hold-button represents 1/6 if the calibrated value. (Default in systems without stabilizers) To start calibration, press the “+”-Hold button in the desired direction. For a first time calibration, the thrusters will start at 70%.
  • Page 22: Menu System - Info

    Menu system - INFO INFO • Move between menu items with the (stern) joystick. • Press the button below to select the highlighted menu entry. • Press the button below to return to the previous menu. INFO THRUSTER INFO Display info about the thusters in the system. The number of thrusters/controllers found is shown in the upper right corner of the display.
  • Page 23: Menu System - Panel Setup

    Menu system - PANEL SETUP PANEL SETUP • Move between parameters with the (stern) joystick. • Press the button below to return to the previous menu. • Press the button below to edit the selected parameter. PANEL • Parameter value will start to blink, use joystick to alter value. •...
  • Page 24: Alarm Descriptions

    Alarm descriptions Alarm Auto Errors shown in display Description Action code Reset Motor Overcurrent Motor current over 1400A. Thruster must be serviced by authorized personnel, reset or PPC800 power OFF/ON. Motortemp has been over Motor cool down below 115°C/239°F Motor Overtemp 130°C/266°F.
  • Page 25 Alarm descriptions Alarm Auto Errors shown in display Description Action code Reset Actuator Fault Actuator not getting any power. Check actuator connection or power to actuator. Reset alarm in alarm menu on PJC 211/212/221/222 or recycle power. Pos.Sensor Fault Retract position sensor fail. Check position sensor cables and for sensor damage.
  • Page 26: Technical Specifications

    Technical specifications Description Minimum Maximum Units Comment Input voltage Volt DC Powered from S-Link Current Voltage External Alarm Buzzer Voltage Volt DC External Alarm Buzzzer Current Internally fused Description Value Operating temperature -10 to + 60 degrees C. Storage temperature -20 to + 70 degrees C.
  • Page 27: S-Link System Example

    S-link system example PJC211/212/221/222 version 2.0.7 - Sept 2014...
  • Page 28: Measurements

    Measurements           PJC211/212/221/222 version 2.0.7 - Sept 2014 ...
  • Page 29: Connections

    Connections Connections for optional external buzzer/audible alarm. External alarm/buzzer connection (S-link) Supply +12V / 24V DC Internal fuse/relay External alarm buzzer 12V / 24V DC - max 0,5A PJC211/212/221/222 version 2.0.7 - Sept 2014...
  • Page 30 Note type, location and serial numbers Fill in the type, location and serial numbers of the S-link devices installed. Keeping this as a reference will make the setup procedure easier! S-link device Location Serial number (ie Thruster, AMS, PPC800 etc) (Bow, Bow-STB, Stern, Stern-STB) PJC211/212/221/222 version 2.0.7 - Sept 2014...
  • Page 31: Notes

    Notes PJC211/212/221/222 version 2.0.7 - Sept 2014...
  • Page 32: O. Box

    Worldwide sales and service www.side-power.com SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 Fax:+47 69 30 00 70 www.side-power.com sidepower@sleipner.no...
