Side-Power 8950G Installation Manual

Single control panels

Advertisement

SIDEPOWER
Thrusters
Installation guide for single control panels types: 8950G & 8960G
Installasjons veiledning for kontroll panel typer: 8950G & 8960G
Installationsanleitung für Steuerpanele, Typ: 8950G & 8960G
Important !
These panels will only work with Sidepower electric thrusters with a built in electronic
control box and a 4/5 lead control cable system. These panels are waterproof from the front
end when correctly installed. However, you must ensure that they can never be submerged
in water as this might cause a shortcircuit and thereby causing the thruster to start unintededly.
Viktig !
Disse kontroll panel fungerer bare med Sidepower elektriske trustere med integrert
elektronisk kontroll boks og 4/5 leders kontroll kabel system. Disse panelene er vantette
fra fronten når de er korrekt installert. Men, de må aldri stå slik att de er under vann da dette
kan gi en kortslutning som kan føre til selvstarting av trusteren.
Wichtig !
Die Panels funktionieren nur mit elektrischen Sidepower Systemen mit integrierter
elektronischer Kontrolleinheit und einem Kabelstrang mit 4/5 Leitungen. Die Panels sind
bei korrektem Einbau an der Vorderseite wasserdicht. Trotzdem muß sichergestellt sein,
daß das Panel nicht unter Wasser kommt, da dies zu einem Kurzschluß führen kann.
Hierdurch kann es zu einem unbeabsichtigten Start des Thrusters kommen.
We Sleipner Motor AS declare that these control panels complies with health and safety require-
ments according to the Directive 89/336/EEC of 23 May 1989 amended by 92/31/EEC and 93/68/EEC.
Vi Sleipner Motor AS bekrefter att disse kontroll panel tilfredstiller krav til helse og sikkerhet i
følge Direktiv 89/336/EEC av 23 mai 1989 med tillegg av 92/31/EEC og 93/68/EEC.
Sleipner Motor AS garantiert, daß die Panels die Gesundheits- und Sicherheitsanforderungen
Partslist referring to drawing on next page
Deleliste refererer til tegning på neste side
Teileliste für Zeichnung Seite 2
Ref:
Pcs.
Parts:
1
1 x
Control panel
2
1 x
Gasket
3
4 x
Screws (A4)
4
4 x
Corner clips
Installation guide for Sidepower single control panels. Issue 5. © Sleipner Motor AS 2007
Deler:
Kontrollpanel
Pakning
Skruer (A4)
Hjørne klips
Teile:
Steuerpanel
Dichtung
Schraube (A4)
Eckstück
Page 1
