Installation guide for hydraulic information panel type: 8980-12V/8980-24V
Installasjons veiledning for hydraulisk informasjonspanel type: 8980-12V/8980-24V
Installationsanleitung für hydraulische Informationspanele, Typ: 8980-12V/8980-24V
Important!This panel will only work with SidePower hydraulic systems and 5 lead control cable
system. The panel is waterproof from the front end when correctly installed. However,
you must ensure that they can never be submerged in water as this might cause a
shortcircuit.
Viktig !
Dette panelet fungerer bare med SidePower hydrauliske systemer og 5 leders
kontroll kabel system. Panelet er vanntett i fronten når det er korrekt installert.
Men, det må aldri stå slik att det er under vann da dette kan gi en kortslutning.
Achtung!
Das Panel funktioniert nur mit hydraulischen SidePower Systemen und einem
Kabelstrang mit 5 Leitungen. Das Panel ist bei korrektem Einbau an der Vorderseite
wasserdicht. Trotzdem muß sichergestellt sein, daß das Panel nicht unter Wasser
kommt, da dies zu einem Kurzschluß führen kann.

Partslist referring to drawing on next page

Deleliste refererer til tegning på neste side
Teileliste für Zeichnung Seite 2
Ref:
Pcs.
Parts:
1
1 x
Information panel
2
1 x
Gasket
3
4 x
Screws (A4)
4
1 x
Corner clips
We Sleipner Motor AS declare that this information panel complies with health and safety
requirements according to the Directive 89/336/EEC of 23 May 1989 amended by 92/31/EEC
and 93/68/EEC.
Vi Sleipner Motor AS bekrefter att dette informasjonspanelet tilfredstiller krav til helse og
sikkerhet i følge Direktiv 89/336/EEC av 23 mai 1989 med tillegg av 92/31/EEC og 93/68/
EEC.
Sleipner Motor AS garantiert, daß das Informationspanel die Gesundheits- und
Sicherheitsanforderungen entsprechend der Direktive 89/336/EEC vom 23 Mai 1989, Ergänzung
92/31/EEC und 93/68/EEC erfüllen.
Installation guide for SidePower hydraulic information panel. Issue 1. © Sleipner Motor AS 2004
Thruster systems
Deler:
Informasjonspanel
Pakning
Skruer (A4)
Hjørne klips
®
Teile:
Informationspanel
Dichtung
Schrauben (A4)
Eckstück
